[Yuken] — EFCG-03 10Ω Proportional Flow Control Valve with built-in check valve (E series, 20.6 MPa, size 03)
Family ID: YK-EFCG-03
10Ω Series Proportional Electro-Hydraulic Flow Control Valves. E-series current-driven valve: set flow changes continuously in proportion to the input current, so system flow can be remotely controlled from a power amplifier; pressure- and temperature-compensated, so set flow is unaffected by load pressure or oil temperature; built-in check valve. Suited to shock-free start/stop/speed-change of actuators. Use with a dedicated Yuken power amplifier. Sub-plate mounting, valve size 03. Max operating pressure 20.6 MPa, max adjustable flow 60 / 125 L/min, rated current 780 mA. Internal/external pilot. Coil resistance 10Ω.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| EFCG-03-60-51 | EFCG-03 10ohm Flow Control +Check (E), 60L/min, Internal pilot | Yuken | Type: Proportional Flow Control Valve (E series, current-driven, 10Ω) with built-in Check | Series: EFCG | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 60 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 130 L/min | Pilot: Internal pilot | Rated Current: 780 mA | Pressure/Temperature compensated: Yes | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51 | ||
| EFCG-03-60-E-51 | EFCG-03 10ohm Flow Control +Check (E), 60L/min, External pilot | Yuken | Type: Proportional Flow Control Valve (E series, current-driven, 10Ω) with built-in Check | Series: EFCG | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 60 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 130 L/min | Pilot: External pilot | Rated Current: 780 mA | Pressure/Temperature compensated: Yes | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51 | ||
| EFCG-03-125-51 | EFCG-03 10ohm Flow Control +Check (E), 125L/min, Internal pilot | Yuken | Type: Proportional Flow Control Valve (E series, current-driven, 10Ω) with built-in Check | Series: EFCG | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 125 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 130 L/min | Pilot: Internal pilot | Rated Current: 780 mA | Pressure/Temperature compensated: Yes | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51 | ||
| EFCG-03-125-E-51 | EFCG-03 10ohm Flow Control +Check (E), 125L/min, External pilot | Yuken | Type: Proportional Flow Control Valve (E series, current-driven, 10Ω) with built-in Check | Series: EFCG | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 125 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 130 L/min | Pilot: External pilot | Rated Current: 780 mA | Pressure/Temperature compensated: Yes | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 10 kg | Design No.: 51 |
