[Yuken] — EHFCG-03 Proportional Flow Control Valve with built-in check valve (20.6 MPa, size 03)
Family ID: YK-EHFCG-03
Proportional Electro-Hydraulic Flow Control (and Check) Valves. Remotely controls system flow proportionally to the input voltage; pressure- and temperature-compensated so the set flow is unaffected by load pressure or oil temperature . Built-in check valve. Sub-plate mounting, valve size 03. Max operating pressure 20.6 MPa, max adjustable flow 60 / 125 L/min, min adjustable flow 1 L/min. Internal- and external-pilot (E) versions. Coil resistance 10Ω, supply DC24V (28W max).
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| EHFCG-03-60-50 | EHFCG-03 Flow Control +Check, 60L/min, Internal pilot | Yuken | Type: Proportional Flow Control Valve with built-in Check | Series: EHFCG | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 60 L/min | Min Adjustable Flow: 1 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 130 L/min | Pilot: Internal pilot | Pressure/Temperature compensated: Yes | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFCG-03-60-E-50 | EHFCG-03 Flow Control +Check, 60L/min, External pilot | Yuken | Type: Proportional Flow Control Valve with built-in Check | Series: EHFCG | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 60 L/min | Min Adjustable Flow: 1 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 130 L/min | Pilot: External pilot | Pressure/Temperature compensated: Yes | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFCG-03-125-50 | EHFCG-03 Flow Control +Check, 125L/min, Internal pilot | Yuken | Type: Proportional Flow Control Valve with built-in Check | Series: EHFCG | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 125 L/min | Min Adjustable Flow: 1 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 130 L/min | Pilot: Internal pilot | Pressure/Temperature compensated: Yes | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHFCG-03-125-E-50 | EHFCG-03 Flow Control +Check, 125L/min, External pilot | Yuken | Type: Proportional Flow Control Valve with built-in Check | Series: EHFCG | Mounting: Sub-plate (G) | Valve Size: 03 | Max Adjustable Flow: 125 L/min | Min Adjustable Flow: 1 L/min | Max Pressure: 20.6 MPa | Free Flow (check): 130 L/min | Pilot: External pilot | Pressure/Temperature compensated: Yes | Coil: 10Ω, DC24V | Design No.: 50 |
