[Yuken] — EHDG-01-C Proportional Pilot Relief Valve (24.5 MPa, 1.0–15.7 MPa adj. range, size 01)
Family ID: YK-EHDG-01-C
Proportional Electro-Hydraulic Pilot Relief Valves. Pressure adjustment range C: 1.0–15.7 MPa. Max. operating pressure 24.5 MPa. Max. flow 2 L/min. Min. flow 0.3 L/min. Coil resistance 10Ω. Supply DC24V (28W max). Sub-plate mounting. Valve size 01. Open-loop, sensor-equipped (S) and closed-loop (L) control versions; optional built-in safety valve.
20 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| EHDG-01-C-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: General purpose | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01-C-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: General purpose | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01-C-1-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: General purpose | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01-C-1-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: General purpose | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-1-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-1-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01-C-S-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop + built-in sensor, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: General purpose | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop + built-in sensor | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01-C-S-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop + built-in sensor, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: General purpose | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop + built-in sensor | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01-C-S-1-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop + built-in sensor, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: General purpose | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop + built-in sensor | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01-C-S-1-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop + built-in sensor, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: General purpose | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop + built-in sensor | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-S-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop + built-in sensor, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop + built-in sensor | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-S-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop + built-in sensor, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop + built-in sensor | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-S-1-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop + built-in sensor, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop + built-in sensor | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-S-1-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Open loop + built-in sensor, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Open loop + built-in sensor | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-L-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Closed loop, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Closed loop | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-L-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Closed loop, Without safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Closed loop | Safety Valve: Without safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-L-1-PNT13-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Closed loop, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Closed loop | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: No P–B line orifice | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHDG-01V-C-L-1-PNT13M10-50 | EHDG-01 Pilot Relief, C 1.0–15.7 MPa, Closed loop, Built-in safety valve | Yuken | Type: Proportional Pilot Relief Valve | Series: EHDG | Mounting: Sub-plate (G) | Valve Size: 01 | Usage: Relief-valve vent control | Pressure Adj. Range: C (1.0–15.7 MPa) | Control: Closed loop | Safety Valve: Built-in safety valve | P-line Orifice: PN (none, standard) | T-line Orifice: T13 (standard for C) | P-B line Orifice: Standard P–B line orifice (M10) | Max Pressure: 24.5 MPa | Max Flow: 2 L/min | Coil: 10Ω, DC24V | Design No.: 50 |
