[Yuken] — EHRBG-10 Proportional Relieving & Reducing Valve (24.5 MPa, max 250 L/min, size 10)
Family ID: YK-EHRBG-10
Proportional Electro-Hydraulic Relieving and Reducing Valves. Integrates the compact high-performance EH-series 1/8 proportional pilot relief valve with a relief-built-in reducing valve; controls system pressure proportionally to input voltage with good response on pressure drop even at large flow. Sub-plate mounting, valve size 10. Max operating pressure 24.5 MPa, max flow 250 L/min, max relief flow 15 L/min. Pressure adjustment range B: 0.9–6.9 MPa / C: 1.2–13.7 MPa / H: 1.5–20.6 MPa. Coil resistance 10Ω, supply DC24V (28W max). Open-loop and sensor-equipped (S) versions.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| EHRBG-10-B-50 | EHRBG-10 Relieving/Reducing, B 0.9–6.9 MPa, Open loop, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve | Series: EHRBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Pressure Adj. Range: B (0.9–6.9 MPa) | Max Pressure: 6.9 MPa | Control: Open loop | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHRBG-10-B-S-50 | EHRBG-10 Relieving/Reducing, B 0.9–6.9 MPa, Open loop + built-in sensor, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve | Series: EHRBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Pressure Adj. Range: B (0.9–6.9 MPa) | Max Pressure: 6.9 MPa | Control: Open loop + built-in sensor | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHRBG-10-C-50 | EHRBG-10 Relieving/Reducing, C 1.2–13.7 MPa, Open loop, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve | Series: EHRBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Pressure Adj. Range: C (1.2–13.7 MPa) | Max Pressure: 13.7 MPa | Control: Open loop | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHRBG-10-C-S-50 | EHRBG-10 Relieving/Reducing, C 1.2–13.7 MPa, Open loop + built-in sensor, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve | Series: EHRBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Pressure Adj. Range: C (1.2–13.7 MPa) | Max Pressure: 13.7 MPa | Control: Open loop + built-in sensor | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHRBG-10-H-50 | EHRBG-10 Relieving/Reducing, H 1.5–20.6 MPa, Open loop, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve | Series: EHRBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Pressure Adj. Range: H (1.5–20.6 MPa) | Max Pressure: 20.6 MPa | Control: Open loop | Coil: 10Ω, DC24V | Design No.: 50 | ||
| EHRBG-10-H-S-50 | EHRBG-10 Relieving/Reducing, H 1.5–20.6 MPa, Open loop + built-in sensor, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve | Series: EHRBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Pressure Adj. Range: H (1.5–20.6 MPa) | Max Pressure: 20.6 MPa | Control: Open loop + built-in sensor | Coil: 10Ω, DC24V | Design No.: 50 |
