[Yuken] — ERBG-10 Proportional Relieving & Reducing Valve (E series, 24.5 MPa, max 250 L/min, size 10)
Family ID: YK-ERBG-10
Proportional Electro-Hydraulic Relieving and Reducing Valves. E-series current-driven valve integrating the compact high-performance 1/8 proportional pilot relief valve with a relief-built-in reducing valve; controls system pressure proportionally to the input current, with good response on pressure drop even at large load flow. Use together with a dedicated Yuken power amplifier. Sub-plate mounting, valve size 10. Max operating pressure 24.5 MPa, max flow 250 L/min, max relief flow 15 L/min. Secondary pressure adjustment range B: 0.9–6.9 MPa / C: 1.2–13.7 MPa / H: 1.5–20.6 MPa. Coil resistance 10Ω, hysteresis 3%.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| ERBG-10-B-51 | ERBG-10 Relieving/Reducing (E), B 0.9–6.9 MPa, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Secondary Pressure Adj. Range: B (0.9–6.9 MPa) | Max Pressure: 6.9 MPa | Rated Current: 800 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 13.5 kg | Design No.: 51 | ||
| ERBG-10-C-51 | ERBG-10 Relieving/Reducing (E), C 1.2–13.7 MPa, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Secondary Pressure Adj. Range: C (1.2–13.7 MPa) | Max Pressure: 13.7 MPa | Rated Current: 800 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 13.5 kg | Design No.: 51 | ||
| ERBG-10-H-51 | ERBG-10 Relieving/Reducing (E), H 1.5–20.6 MPa, max 250 L/min | Yuken | Type: Proportional Relieving and Reducing Valve (E series, current-driven) | Series: ERBG | Mounting: Sub-plate (G) | Valve Size: 10 | Max Flow: 250 L/min | Max Relief Flow: 15 L/min | Secondary Pressure Adj. Range: H (1.5–20.6 MPa) | Max Pressure: 20.6 MPa | Rated Current: 950 mA | Coil: 10Ω | Drive: Current input (use with dedicated power amplifier) | Mass: 13.5 kg | Design No.: 51 |
