[Yuken] — Flow Control and Check Valve (FCG)
Family ID: YUK-FC-FCG
Flow Control Valves · Flow Control and Check Valves. Max. operating pressure: 14 MPa (size 01) / 21 MPa (02–10). Max. adjustable flow: 4/8 (01) / 30 (02) / 125 (03) / 250 (06) / 500 (10) L/min. Digital scale (except size 01). Pressure-compensated piston opening adjustment (-N) available. Built-in check valve for free reverse flow.
12 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| FCG-01-4-11 | Flow Control and Check Valve FCG-01-4 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | ||
| FCG-01-4-N-11 | Flow Control and Check Valve FCG-01-4-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 4 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | ||
| FCG-01-8-11 | Flow Control and Check Valve FCG-01-8 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | ||
| FCG-01-8-N-11 | Flow Control and Check Valve FCG-01-8-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 01 | Max. Adjustable Flow: 8 L/min | Min. Adjustable Flow: 0.02 (0.04 at ≥7 MPa) L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 14 MPa | Mass: 1.3 kg | Design No.: 11 | ||
| FCG-02-30-30 | Flow Control and Check Valve FCG-02-30 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30 | ||
| FCG-02-30-N-30 | Flow Control and Check Valve FCG-02-30-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 02 | Max. Adjustable Flow: 30 L/min | Min. Adjustable Flow: 0.05 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 3.8 kg | Design No.: 30 | ||
| FCG-03-125-30 | Flow Control and Check Valve FCG-03-125 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30 | ||
| FCG-03-125-N-30 | Flow Control and Check Valve FCG-03-125-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 03 | Max. Adjustable Flow: 125 L/min | Min. Adjustable Flow: 0.2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 7.9 kg | Design No.: 30 | ||
| FCG-06-250-30 | Flow Control and Check Valve FCG-06-250 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30 | ||
| FCG-06-250-N-30 | Flow Control and Check Valve FCG-06-250-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 06 | Max. Adjustable Flow: 250 L/min | Min. Adjustable Flow: 2 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 23 kg | Design No.: 30 | ||
| FCG-10-500-30 | Flow Control and Check Valve FCG-10-500 | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: No | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30 | ||
| FCG-10-500-N-30 | Flow Control and Check Valve FCG-10-500-N | Yuken | Type: Flow Control and Check Valve | Mounting: Sub-plate | Valve Size: 10 | Max. Adjustable Flow: 500 L/min | Min. Adjustable Flow: 4 L/min | Pressure-Compensated Piston Opening Adj.: Yes (-N) | Check Valve: Yes (free reverse flow) | Max. Operating Pressure: 21 MPa | Mass: 52 kg | Design No.: 30 |
