Yuken — LB Series Relief Logic Valve (ISO 7368 Cartridge)
Family ID: YUK-GLOG-LB
Relief Logic Valves (LB). ISO 7368 cartridge. Sizes 16/25/32/50, max 31.5 MPa, pressure adjustment 0.5–31.5 MPa, rated 125–1200 L/min. Cover forms: standard / vent control (Z1, Z2). High-vent (V) option. Abbreviated catalog — details by inquiry.
12 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| LB-16-10 | Relief logic, standard, size 16 | Yuken | Type: Relief logic (Standard) | Size: 16 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 125 L/min | Max Pressure: 31.5 MPa | Design: -10 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-25-10 | Relief logic, standard, size 25 | Yuken | Type: Relief logic (Standard) | Size: 25 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 250 L/min | Max Pressure: 31.5 MPa | Design: -10 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-32-11 | Relief logic, standard, size 32 | Yuken | Type: Relief logic (Standard) | Size: 32 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 500 L/min | Max Pressure: 31.5 MPa | Design: -11 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-50-11 | Relief logic, standard, size 50 | Yuken | Type: Relief logic (Standard) | Size: 50 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 1200 L/min | Max Pressure: 31.5 MPa | Design: -11 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-16-Z1-10 | Relief logic, vent control (z1 port), size 16 | Yuken | Type: Relief logic (Vent control (Z1 port)) | Size: 16 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 125 L/min | Max Pressure: 31.5 MPa | Design: -10 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-25-Z1-10 | Relief logic, vent control (z1 port), size 25 | Yuken | Type: Relief logic (Vent control (Z1 port)) | Size: 25 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 250 L/min | Max Pressure: 31.5 MPa | Design: -10 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-32-Z1-11 | Relief logic, vent control (z1 port), size 32 | Yuken | Type: Relief logic (Vent control (Z1 port)) | Size: 32 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 500 L/min | Max Pressure: 31.5 MPa | Design: -11 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-50-Z1-11 | Relief logic, vent control (z1 port), size 50 | Yuken | Type: Relief logic (Vent control (Z1 port)) | Size: 50 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 1200 L/min | Max Pressure: 31.5 MPa | Design: -11 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-16-Z2-10 | Relief logic, vent control (z2 port), size 16 | Yuken | Type: Relief logic (Vent control (Z2 port)) | Size: 16 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 125 L/min | Max Pressure: 31.5 MPa | Design: -10 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-25-Z2-10 | Relief logic, vent control (z2 port), size 25 | Yuken | Type: Relief logic (Vent control (Z2 port)) | Size: 25 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 250 L/min | Max Pressure: 31.5 MPa | Design: -10 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-32-Z2-11 | Relief logic, vent control (z2 port), size 32 | Yuken | Type: Relief logic (Vent control (Z2 port)) | Size: 32 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 500 L/min | Max Pressure: 31.5 MPa | Design: -11 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry | ||
| LB-50-Z2-11 | Relief logic, vent control (z2 port), size 50 | Yuken | Type: Relief logic (Vent control (Z2 port)) | Size: 50 | Pressure Adjustment: 0.5–31.5 MPa | Rated Flow: 1200 L/min | Max Pressure: 31.5 MPa | Design: -11 | High-vent (RFQ): V option — for faster unload→onload switching | Note: Abbreviated catalog — detailed specs by inquiry |
