![[Yuken] — One Way Restrictor (SRCT/SRCG-03/06/10)](https://img.prosourcemro.com/2026/05/002-39-1024x942.png)
Restrictors
Yuken
[Yuken] — One Way Restrictor (SRCT/SRCG-03/06/10)
Family ID: YUK-FC-SRC
Restrictors · One Way Restrictors. Max. operating pressure: 25 MPa. Rated flow: 30 (03) / 85 (06) / 230 (10) L/min (at 0.3 MPa drop). Threaded (T) / sub-plate (G) mounting. Controlled flow one way, free reverse flow.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| SRCT-03-50 | One Way Restrictor SRCT-03, Threaded | Yuken | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 1.5 kg | Design No.: 50 | ||
| SRCT-06-50 | One Way Restrictor SRCT-06, Threaded | Yuken | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 3.8 kg | Design No.: 50 | ||
| SRCT-10-50 | One Way Restrictor SRCT-10, Threaded | Yuken | Type: One Way Restrictor | Mounting: Threaded | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 9.1 kg | Design No.: 50 | ||
| SRCG-03-50 | One Way Restrictor SRCG-03, Sub-plate | Yuken | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 03 | Rated Flow: 30 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 2.5 kg | Design No.: 50 | ||
| SRCG-06-50 | One Way Restrictor SRCG-06, Sub-plate | Yuken | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 06 | Rated Flow: 85 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 3.9 kg | Design No.: 50 | ||
| SRCG-10-50 | One Way Restrictor SRCG-10, Sub-plate | Yuken | Type: One Way Restrictor | Mounting: Sub-plate | Valve Size: 10 | Rated Flow: 230 L/min (at 0.3 MPa drop) | Max. Operating Pressure: 25 MPa | Reverse Flow: Free (check valve) | Mass: 7.5 kg | Design No.: 50 |
