[Yuken] — Throttle and Check Module (TC2G-01/03)
Family ID: YUK-FC-TC2
Throttle and Check Module. Used as pilot check valve for solenoid/pilot operated directional valves. Flow: 30 (01) / 80 (03) L/min. Max. operating pressure: 25 MPa. Gasket mounting. Meter-out (no symbol) / meter-in (-A) on size 03.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| TC2G-01-40 | Throttle and Check Module TC2G-01-40 | Yuken | Type: Throttle and Check Module | Mounting: Gasket | Valve Size: 01 | Circuit: — | Flow: 30 L/min | Max. Operating Pressure: 25 MPa | Mass: 0.65 kg | Design No.: 40 | ||
| TC2G-03-40 | Throttle and Check Module TC2G-03-40 | Yuken | Type: Throttle and Check Module | Mounting: Gasket | Valve Size: 03 | Circuit: Meter-out | Flow: 80 L/min | Max. Operating Pressure: 25 MPa | Mass: 1.8 kg | Design No.: 40 | ||
| TC2G-03-A-40 | Throttle and Check Module TC2G-03-A-40 | Yuken | Type: Throttle and Check Module | Mounting: Gasket | Valve Size: 03 | Circuit: -A (Meter-in) | Flow: 80 L/min | Max. Operating Pressure: 25 MPa | Mass: 1.8 kg | Design No.: 40 |
