[Yuken] — Pressure Monitoring System (DP/SJT)
Family ID: YUK-PC-PS-MON
Pressure Monitoring System — Digital Pressure Monitors (DP) and Pressure Sensors (SJT). Monitor input 0–4.5V / 0–19.6 MPa (DP20), 0–34.3 MPa (DP35). Output: 2× open collector, 40V·100 mA. 2-channel HI/LO 4-point independent setting. Sensor rated pressure 0–20 MPa (SJT20) / 0–35 MPa (SJT35), output 0.5–4.5V, supply DC 5.0±0.5V. System configuration: consult Yuken (RFQ).
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| DP20-10 | Digital Pressure Monitor DP20 | Yuken | Type: Digital Pressure Monitor | Input: 0–4.5V / 0–19.6 MPa | Output: 2× open collector, 40V·100 mA | Setting: 2-channel HI/LO, 4-point independent | Options (RFQ): consult Yuken | ||
| DP35-10 | Digital Pressure Monitor DP35 | Yuken | Type: Digital Pressure Monitor | Input: 0–4.5V / 0–34.3 MPa | Output: 2× open collector, 40V·100 mA | Setting: 2-channel HI/LO, 4-point independent | Options (RFQ): consult Yuken | ||
| SJT20-02-10 | Pressure Sensor SJT20 | Yuken | Type: Pressure Sensor | Rated Pressure: 0–20 MPa | Output: 0.5–4.5V | Supply: DC 5.0±0.5V | ||
| SJT35-02-10 | Pressure Sensor SJT35 | Yuken | Type: Pressure Sensor | Rated Pressure: 0–35 MPa | Output: 0.5–4.5V | Supply: DC 5.0±0.5V |
