[Yuken] — Semiconductor Pressure Switch (JT-02)
Family ID: YUK-PC-PS-JT02
Semiconductor Type Pressure Switches. Pressure setting range 0.1–35 MPa (model dependent). Open collector output (photocoupler isolated), DC 35V max 100 mA. Supply DC 10–28V, consumption ≤10 mA. Protection IP54 (standard) / IP65 (protective cover -S). Operating temp −20 to +70°C. Repeatability approx. 0.5%. Mass 175 g.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| JT-02-35-11 | Semiconductor Pressure Switch JT-02-35, set 0.1–3.5 MPa | Yuken | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 0.1–3.5 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11 | ||
| JT-02-35-S-11 | Semiconductor Pressure Switch JT-02-35-S, set 0.1–3.5 MPa, protective cover | Yuken | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 0.1–3.5 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11 | ||
| JT-02-100-11 | Semiconductor Pressure Switch JT-02-100, set 1–10 MPa | Yuken | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 1–10 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11 | ||
| JT-02-100-S-11 | Semiconductor Pressure Switch JT-02-100-S, set 1–10 MPa, protective cover | Yuken | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 10 MPa | Withstand Pressure: 20 MPa | Pressure Setting Range: 1–10 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11 | ||
| JT-02-200-11 | Semiconductor Pressure Switch JT-02-200, set 2–20 MPa | Yuken | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 20 MPa | Withstand Pressure: 40 MPa | Pressure Setting Range: 2–20 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11 | ||
| JT-02-200-S-11 | Semiconductor Pressure Switch JT-02-200-S, set 2–20 MPa, protective cover | Yuken | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 20 MPa | Withstand Pressure: 40 MPa | Pressure Setting Range: 2–20 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11 | ||
| JT-02-350-11 | Semiconductor Pressure Switch JT-02-350, set 3.5–35 MPa | Yuken | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 35 MPa | Withstand Pressure: 50 MPa | Pressure Setting Range: 3.5–35 MPa | Protective Cover: No (IP54) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP54 | Mass: 175 g | Design No.: 11 | ||
| JT-02-350-S-11 | Semiconductor Pressure Switch JT-02-350-S, set 3.5–35 MPa, protective cover | Yuken | Type: Semiconductor Type Pressure Switch | Max. Operating Pressure: 35 MPa | Withstand Pressure: 50 MPa | Pressure Setting Range: 3.5–35 MPa | Protective Cover: Yes (-S) (IP65) | Output: Open collector, photocoupler isolated, DC 35V / 100 mA | Supply: DC 10–28V, ≤10 mA | Response: 1.5 ms (no damper) / 20 ms (with damper) | Protection: IP65 | Mass: 175 g | Design No.: 11 |
