Apex Dynamics AF Precision Planetary Gearboxes (Frame 042-075A)

APEX Dynamics AF series high precision, high speed inline planetary gearboxes for servo motors, frame sizes 042 to 075A.

Key features

Full order code: size - 3-digit ratio - output shaft S1/S2/S3 - backlash P0/P1/P2, then / motor make and model
Ordering example AF075-010-S1-P1 / SIEMENS 1FT6 041-4AF71; motor adapter is specified by motor model, not by code
Single-stage ratios 3-10 and two-stage ratios 12-100; A frames (060A, 075A, 100A, 140A) are two-stage only
Micro backlash P0 down to <=1 arcmin (1-stage, frames 075-220); P1 <=3/5 and P2 <=5/7 arcmin (1/2-stage)
Output shafts: S1 smooth, S2 with key, S3 DIN 5480 spline (S3 not offered on AF042)
IP67 protection, lubricated for life, any mounting position, emergency stop torque 3x nominal

Specifications

Gearbox type	Inline planetary, square flange output
Efficiency	1-stage >=97%, 2-stage >=94%
Max. acceleration torque T2B	60% of emergency stop torque T2NOT
Emergency stop torque T2NOT	3x nominal output torque
Protection	IP67
Operating temperature	-10 to +90 C
Lubrication	Lubricant, lubricated for life
Mounting position	All directions
Motor input	Specify motor make and model when ordering
Nominal input speed n1N	5,000 rpm (042-060A), 4,000 rpm (075-075A)
Torsional rigidity	3-14 Nm/arcmin
Source	APEX Dynamics AF/AFR catalog, p. 2-6, 11-12

AF042-003-S1-P1		Frame: 042 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-003-S1-P2		Frame: 042 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-003-S2-P1		Frame: 042 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-003-S2-P2		Frame: 042 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-004-S1-P1		Frame: 042 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-004-S1-P2		Frame: 042 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-004-S2-P1		Frame: 042 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-004-S2-P2		Frame: 042 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-005-S1-P1		Frame: 042 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
AF042-005-S1-P2		Frame: 042 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
AF042-005-S2-P1		Frame: 042 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
AF042-005-S2-P2		Frame: 042 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
AF042-006-S1-P1		Frame: 042 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-006-S1-P2		Frame: 042 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-006-S2-P1		Frame: 042 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-006-S2-P2		Frame: 042 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-007-S1-P1		Frame: 042 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-007-S1-P2		Frame: 042 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-007-S2-P1		Frame: 042 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-007-S2-P2		Frame: 042 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-008-S1-P1		Frame: 042 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
AF042-008-S1-P2		Frame: 042 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
AF042-008-S2-P1		Frame: 042 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
AF042-008-S2-P2		Frame: 042 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
AF042-009-S1-P1		Frame: 042 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-009-S1-P2		Frame: 042 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-009-S2-P1		Frame: 042 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-009-S2-P2		Frame: 042 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-010-S1-P1		Frame: 042 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-010-S1-P2		Frame: 042 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-010-S2-P1		Frame: 042 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-010-S2-P2		Frame: 042 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-012-S1-P1		Frame: 042 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-012-S1-P2		Frame: 042 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-012-S2-P1		Frame: 042 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-012-S2-P2		Frame: 042 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-015-S1-P1		Frame: 042 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-015-S1-P2		Frame: 042 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-015-S2-P1		Frame: 042 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-015-S2-P2		Frame: 042 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-016-S1-P1		Frame: 042 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-016-S1-P2		Frame: 042 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-016-S2-P1		Frame: 042 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-016-S2-P2		Frame: 042 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-020-S1-P1		Frame: 042 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-020-S1-P2		Frame: 042 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-020-S2-P1		Frame: 042 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-020-S2-P2		Frame: 042 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-025-S1-P1		Frame: 042 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
AF042-025-S1-P2		Frame: 042 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
AF042-025-S2-P1		Frame: 042 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
AF042-025-S2-P2		Frame: 042 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
AF042-028-S1-P1		Frame: 042 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-028-S1-P2		Frame: 042 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-028-S2-P1		Frame: 042 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-028-S2-P2		Frame: 042 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-030-S1-P1		Frame: 042 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-030-S1-P2		Frame: 042 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-030-S2-P1		Frame: 042 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-030-S2-P2		Frame: 042 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-032-S1-P1		Frame: 042 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
AF042-032-S1-P2		Frame: 042 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
AF042-032-S2-P1		Frame: 042 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
AF042-032-S2-P2		Frame: 042 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
AF042-035-S1-P1		Frame: 042 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-035-S1-P2		Frame: 042 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-035-S2-P1		Frame: 042 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-035-S2-P2		Frame: 042 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-040-S1-P1		Frame: 042 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
AF042-040-S1-P2		Frame: 042 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
AF042-040-S2-P1		Frame: 042 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
AF042-040-S2-P2		Frame: 042 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
AF042-045-S1-P1		Frame: 042 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-045-S1-P2		Frame: 042 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-045-S2-P1		Frame: 042 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-045-S2-P2		Frame: 042 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-050-S1-P1		Frame: 042 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
AF042-050-S1-P2		Frame: 042 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
AF042-050-S2-P1		Frame: 042 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
AF042-050-S2-P2		Frame: 042 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
AF042-060-S1-P1		Frame: 042 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-060-S1-P2		Frame: 042 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
AF042-060-S2-P1		Frame: 042 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-060-S2-P2		Frame: 042 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
AF042-070-S1-P1		Frame: 042 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-070-S1-P2		Frame: 042 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
AF042-070-S2-P1		Frame: 042 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-070-S2-P2		Frame: 042 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
AF042-080-S1-P1		Frame: 042 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
AF042-080-S1-P2		Frame: 042 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
AF042-080-S2-P1		Frame: 042 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
AF042-080-S2-P2		Frame: 042 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
AF042-090-S1-P1		Frame: 042 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-090-S1-P2		Frame: 042 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-090-S2-P1		Frame: 042 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-090-S2-P2		Frame: 042 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-100-S1-P1		Frame: 042 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-100-S1-P2		Frame: 042 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
AF042-100-S2-P1		Frame: 042 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF042-100-S2-P2		Frame: 042 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
AF060-003-S1-P1		Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-003-S1-P2		Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-003-S2-P1		Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-003-S2-P2		Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-003-S3-P1		Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-003-S3-P2		Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-004-S1-P1		Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-004-S1-P2		Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-004-S2-P1		Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-004-S2-P2		Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-004-S3-P1		Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-004-S3-P2		Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-005-S1-P1		Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060-005-S1-P2		Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060-005-S2-P1		Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060-005-S2-P2		Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060-005-S3-P1		Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060-005-S3-P2		Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060-006-S1-P1		Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-006-S1-P2		Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-006-S2-P1		Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-006-S2-P2		Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-006-S3-P1		Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-006-S3-P2		Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-007-S1-P1		Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-007-S1-P2		Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-007-S2-P1		Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-007-S2-P2		Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-007-S3-P1		Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-007-S3-P2		Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-008-S1-P1		Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060-008-S1-P2		Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060-008-S2-P1		Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060-008-S2-P2		Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060-008-S3-P1		Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060-008-S3-P2		Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060-009-S1-P1		Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-009-S1-P2		Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-009-S2-P1		Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-009-S2-P2		Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-009-S3-P1		Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-009-S3-P2		Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-010-S1-P1		Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-010-S1-P2		Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-010-S2-P1		Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-010-S2-P2		Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-010-S3-P1		Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-010-S3-P2		Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-012-S1-P1		Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-012-S1-P2		Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-012-S2-P1		Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-012-S2-P2		Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-012-S3-P1		Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-012-S3-P2		Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-015-S1-P1		Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-015-S1-P2		Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-015-S2-P1		Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-015-S2-P2		Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-015-S3-P1		Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-015-S3-P2		Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-016-S1-P1		Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-016-S1-P2		Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-016-S2-P1		Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-016-S2-P2		Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-016-S3-P1		Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-016-S3-P2		Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-020-S1-P1		Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-020-S1-P2		Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-020-S2-P1		Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-020-S2-P2		Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-020-S3-P1		Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-020-S3-P2		Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-025-S1-P1		Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060-025-S1-P2		Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060-025-S2-P1		Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060-025-S2-P2		Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060-025-S3-P1		Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060-025-S3-P2		Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060-028-S1-P1		Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-028-S1-P2		Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-028-S2-P1		Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-028-S2-P2		Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-028-S3-P1		Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-028-S3-P2		Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-030-S1-P1		Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-030-S1-P2		Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-030-S2-P1		Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-030-S2-P2		Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-030-S3-P1		Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-030-S3-P2		Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-032-S1-P1		Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060-032-S1-P2		Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060-032-S2-P1		Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060-032-S2-P2		Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060-032-S3-P1		Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060-032-S3-P2		Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060-035-S1-P1		Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-035-S1-P2		Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-035-S2-P1		Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-035-S2-P2		Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-035-S3-P1		Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-035-S3-P2		Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-040-S1-P1		Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060-040-S1-P2		Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060-040-S2-P1		Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060-040-S2-P2		Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060-040-S3-P1		Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060-040-S3-P2		Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060-045-S1-P1		Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-045-S1-P2		Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-045-S2-P1		Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-045-S2-P2		Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-045-S3-P1		Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-045-S3-P2		Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-050-S1-P1		Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060-050-S1-P2		Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060-050-S2-P1		Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060-050-S2-P2		Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060-050-S3-P1		Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060-050-S3-P2		Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060-060-S1-P1		Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-060-S1-P2		Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060-060-S2-P1		Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-060-S2-P2		Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060-060-S3-P1		Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-060-S3-P2		Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060-070-S1-P1		Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-070-S1-P2		Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060-070-S2-P1		Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-070-S2-P2		Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060-070-S3-P1		Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-070-S3-P2		Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060-080-S1-P1		Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060-080-S1-P2		Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060-080-S2-P1		Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060-080-S2-P2		Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060-080-S3-P1		Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060-080-S3-P2		Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060-090-S1-P1		Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-090-S1-P2		Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-090-S2-P1		Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-090-S2-P2		Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-090-S3-P1		Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-090-S3-P2		Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-100-S1-P1		Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-100-S1-P2		Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060-100-S2-P1		Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-100-S2-P2		Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060-100-S3-P1		Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060-100-S3-P2		Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060A-012-S1-P1		Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-012-S1-P2		Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-012-S2-P1		Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-012-S2-P2		Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-012-S3-P1		Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-012-S3-P2		Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-015-S1-P1		Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060A-015-S1-P2		Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060A-015-S2-P1		Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060A-015-S2-P2		Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060A-015-S3-P1		Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060A-015-S3-P2		Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060A-016-S1-P1		Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-016-S1-P2		Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-016-S2-P1		Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-016-S2-P2		Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-016-S3-P1		Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-016-S3-P2		Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-020-S1-P1		Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-020-S1-P2		Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-020-S2-P1		Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-020-S2-P2		Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-020-S3-P1		Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-020-S3-P2		Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-025-S1-P1		Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060A-025-S1-P2		Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060A-025-S2-P1		Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060A-025-S2-P2		Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060A-025-S3-P1		Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060A-025-S3-P2		Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060A-028-S1-P1		Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-028-S1-P2		Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-028-S2-P1		Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-028-S2-P2		Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-028-S3-P1		Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-028-S3-P2		Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-030-S1-P1		Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060A-030-S1-P2		Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060A-030-S2-P1		Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060A-030-S2-P2		Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060A-030-S3-P1		Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060A-030-S3-P2		Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060A-032-S1-P1		Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060A-032-S1-P2		Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060A-032-S2-P1		Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060A-032-S2-P2		Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060A-032-S3-P1		Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060A-032-S3-P2		Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060A-035-S1-P1		Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-035-S1-P2		Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-035-S2-P1		Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-035-S2-P2		Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-035-S3-P1		Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-035-S3-P2		Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-040-S1-P1		Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060A-040-S1-P2		Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060A-040-S2-P1		Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060A-040-S2-P2		Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060A-040-S3-P1		Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060A-040-S3-P2		Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060A-045-S1-P1		Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060A-045-S1-P2		Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060A-045-S2-P1		Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060A-045-S2-P2		Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060A-045-S3-P1		Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060A-045-S3-P2		Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060A-050-S1-P1		Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060A-050-S1-P2		Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
AF060A-050-S2-P1		Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060A-050-S2-P2		Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
AF060A-050-S3-P1		Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060A-050-S3-P2		Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
AF060A-060-S1-P1		Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060A-060-S1-P2		Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
AF060A-060-S2-P1		Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060A-060-S2-P2		Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
AF060A-060-S3-P1		Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060A-060-S3-P2		Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
AF060A-070-S1-P1		Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-070-S1-P2		Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
AF060A-070-S2-P1		Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-070-S2-P2		Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
AF060A-070-S3-P1		Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-070-S3-P2		Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
AF060A-080-S1-P1		Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060A-080-S1-P2		Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
AF060A-080-S2-P1		Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060A-080-S2-P2		Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
AF060A-080-S3-P1		Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060A-080-S3-P2		Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
AF060A-090-S1-P1		Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060A-090-S1-P2		Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060A-090-S2-P1		Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060A-090-S2-P2		Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060A-090-S3-P1		Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060A-090-S3-P2		Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060A-100-S1-P1		Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060A-100-S1-P2		Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
AF060A-100-S2-P1		Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060A-100-S2-P2		Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
AF060A-100-S3-P1		Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF060A-100-S3-P2		Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
AF075-003-S1-P0		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
AF075-003-S1-P1		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
AF075-003-S1-P2		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
AF075-003-S2-P0		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
AF075-003-S2-P1		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
AF075-003-S2-P2		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
AF075-003-S3-P0		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
AF075-003-S3-P1		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
AF075-003-S3-P2		Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
AF075-004-S1-P0		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-004-S1-P1		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-004-S1-P2		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-004-S2-P0		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-004-S2-P1		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-004-S2-P2		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-004-S3-P0		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-004-S3-P1		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-004-S3-P2		Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-005-S1-P0		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075-005-S1-P1		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075-005-S1-P2		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075-005-S2-P0		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075-005-S2-P1		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075-005-S2-P2		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075-005-S3-P0		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075-005-S3-P1		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075-005-S3-P2		Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075-006-S1-P0		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075-006-S1-P1		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075-006-S1-P2		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075-006-S2-P0		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075-006-S2-P1		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075-006-S2-P2		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075-006-S3-P0		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075-006-S3-P1		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075-006-S3-P2		Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075-007-S1-P0		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-007-S1-P1		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-007-S1-P2		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-007-S2-P0		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-007-S2-P1		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-007-S2-P2		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-007-S3-P0		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-007-S3-P1		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-007-S3-P2		Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-008-S1-P0		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-008-S1-P1		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-008-S1-P2		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-008-S2-P0		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-008-S2-P1		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-008-S2-P2		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-008-S3-P0		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-008-S3-P1		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-008-S3-P2		Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-009-S1-P0		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-009-S1-P1		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-009-S1-P2		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-009-S2-P0		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-009-S2-P1		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-009-S2-P2		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-009-S3-P0		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-009-S3-P1		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-009-S3-P2		Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-010-S1-P0		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-010-S1-P1		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-010-S1-P2		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-010-S2-P0		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-010-S2-P1		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-010-S2-P2		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-010-S3-P0		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-010-S3-P1		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-010-S3-P2		Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-012-S1-P1		Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-012-S1-P2		Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-012-S2-P1		Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-012-S2-P2		Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-012-S3-P1		Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-012-S3-P2		Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-015-S1-P1		Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
AF075-015-S1-P2		Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
AF075-015-S2-P1		Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
AF075-015-S2-P2		Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
AF075-015-S3-P1		Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
AF075-015-S3-P2		Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
AF075-016-S1-P1		Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-016-S1-P2		Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-016-S2-P1		Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-016-S2-P2		Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-016-S3-P1		Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-016-S3-P2		Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-020-S1-P1		Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-020-S1-P2		Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-020-S2-P1		Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-020-S2-P2		Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-020-S3-P1		Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-020-S3-P2		Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-025-S1-P1		Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075-025-S1-P2		Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075-025-S2-P1		Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075-025-S2-P2		Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075-025-S3-P1		Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075-025-S3-P2		Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075-028-S1-P1		Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-028-S1-P2		Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-028-S2-P1		Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-028-S2-P2		Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-028-S3-P1		Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-028-S3-P2		Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-030-S1-P1		Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075-030-S1-P2		Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075-030-S2-P1		Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075-030-S2-P2		Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075-030-S3-P1		Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075-030-S3-P2		Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075-032-S1-P1		Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-032-S1-P2		Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-032-S2-P1		Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-032-S2-P2		Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-032-S3-P1		Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-032-S3-P2		Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-035-S1-P1		Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-035-S1-P2		Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-035-S2-P1		Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-035-S2-P2		Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-035-S3-P1		Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-035-S3-P2		Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-040-S1-P1		Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-040-S1-P2		Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-040-S2-P1		Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-040-S2-P2		Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-040-S3-P1		Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-040-S3-P2		Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-045-S1-P1		Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-045-S1-P2		Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-045-S2-P1		Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-045-S2-P2		Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-045-S3-P1		Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-045-S3-P2		Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-050-S1-P1		Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075-050-S1-P2		Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075-050-S2-P1		Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075-050-S2-P2		Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075-050-S3-P1		Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075-050-S3-P2		Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075-060-S1-P1		Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075-060-S1-P2		Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075-060-S2-P1		Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075-060-S2-P2		Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075-060-S3-P1		Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075-060-S3-P2		Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075-070-S1-P1		Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-070-S1-P2		Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075-070-S2-P1		Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-070-S2-P2		Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075-070-S3-P1		Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-070-S3-P2		Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075-080-S1-P1		Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-080-S1-P2		Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075-080-S2-P1		Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-080-S2-P2		Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075-080-S3-P1		Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-080-S3-P2		Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075-090-S1-P1		Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-090-S1-P2		Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-090-S2-P1		Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-090-S2-P2		Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-090-S3-P1		Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-090-S3-P2		Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-100-S1-P1		Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-100-S1-P2		Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075-100-S2-P1		Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-100-S2-P2		Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075-100-S3-P1		Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075-100-S3-P2		Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075A-012-S1-P1		Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-012-S1-P2		Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-012-S2-P1		Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-012-S2-P2		Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-012-S3-P1		Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-012-S3-P2		Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-015-S1-P1		Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
AF075A-015-S1-P2		Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
AF075A-015-S2-P1		Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
AF075A-015-S2-P2		Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
AF075A-015-S3-P1		Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
AF075A-015-S3-P2		Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
AF075A-016-S1-P1		Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-016-S1-P2		Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-016-S2-P1		Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-016-S2-P2		Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-016-S3-P1		Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-016-S3-P2		Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-020-S1-P1		Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-020-S1-P2		Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-020-S2-P1		Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-020-S2-P2		Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-020-S3-P1		Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-020-S3-P2		Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-025-S1-P1		Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075A-025-S1-P2		Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075A-025-S2-P1		Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075A-025-S2-P2		Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075A-025-S3-P1		Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075A-025-S3-P2		Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075A-028-S1-P1		Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-028-S1-P2		Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-028-S2-P1		Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-028-S2-P2		Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-028-S3-P1		Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-028-S3-P2		Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-030-S1-P1		Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075A-030-S1-P2		Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075A-030-S2-P1		Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075A-030-S2-P2		Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075A-030-S3-P1		Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075A-030-S3-P2		Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075A-032-S1-P1		Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075A-032-S1-P2		Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075A-032-S2-P1		Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075A-032-S2-P2		Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075A-032-S3-P1		Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075A-032-S3-P2		Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075A-035-S1-P1		Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-035-S1-P2		Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-035-S2-P1		Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-035-S2-P2		Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-035-S3-P1		Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-035-S3-P2		Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-040-S1-P1		Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075A-040-S1-P2		Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075A-040-S2-P1		Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075A-040-S2-P2		Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075A-040-S3-P1		Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075A-040-S3-P2		Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075A-045-S1-P1		Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075A-045-S1-P2		Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075A-045-S2-P1		Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075A-045-S2-P2		Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075A-045-S3-P1		Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075A-045-S3-P2		Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075A-050-S1-P1		Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075A-050-S1-P2		Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
AF075A-050-S2-P1		Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075A-050-S2-P2		Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
AF075A-050-S3-P1		Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075A-050-S3-P2		Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
AF075A-060-S1-P1		Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075A-060-S1-P2		Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
AF075A-060-S2-P1		Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075A-060-S2-P2		Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
AF075A-060-S3-P1		Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075A-060-S3-P2		Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
AF075A-070-S1-P1		Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-070-S1-P2		Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
AF075A-070-S2-P1		Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-070-S2-P2		Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
AF075A-070-S3-P1		Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-070-S3-P2		Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
AF075A-080-S1-P1		Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075A-080-S1-P2		Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
AF075A-080-S2-P1		Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075A-080-S2-P2		Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
AF075A-080-S3-P1		Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075A-080-S3-P2		Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
AF075A-090-S1-P1		Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075A-090-S1-P2		Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075A-090-S2-P1		Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075A-090-S2-P2		Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075A-090-S3-P1		Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075A-090-S3-P2		Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075A-100-S1-P1		Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075A-100-S1-P2		Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
AF075A-100-S2-P1		Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075A-100-S2-P2		Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
AF075A-100-S3-P1		Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
AF075A-100-S3-P2		Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm

Planetary GearboxesApex Dynamics

628 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Apex Dynamics AF Precision Planetary Gearboxes (Frame 042-075A)

Brand Apex Dynamics·Planetary Gearboxes

Available part numbers (628)

AF042-003-S1-P1, AF042-003-S1-P2, AF042-003-S2-P1, AF042-003-S2-P2, AF042-004-S1-P1, AF042-004-S1-P2, AF042-004-S2-P1, AF042-004-S2-P2, AF042-005-S1-P1, AF042-005-S1-P2 + 618 more — see full table ↓

How to order

Send the Apex Dynamics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	AF042-003-S1-P1	Frame: 042 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-003-S1-P2	Frame: 042 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-003-S2-P1	Frame: 042 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-003-S2-P2	Frame: 042 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-004-S1-P1	Frame: 042 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-004-S1-P2	Frame: 042 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-004-S2-P1	Frame: 042 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-004-S2-P2	Frame: 042 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-005-S1-P1	Frame: 042 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
	AF042-005-S1-P2	Frame: 042 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
	AF042-005-S2-P1	Frame: 042 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
	AF042-005-S2-P2	Frame: 042 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
	AF042-006-S1-P1	Frame: 042 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-006-S1-P2	Frame: 042 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-006-S2-P1	Frame: 042 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-006-S2-P2	Frame: 042 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-007-S1-P1	Frame: 042 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-007-S1-P2	Frame: 042 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-007-S2-P1	Frame: 042 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-007-S2-P2	Frame: 042 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-008-S1-P1	Frame: 042 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
	AF042-008-S1-P2	Frame: 042 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
	AF042-008-S2-P1	Frame: 042 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
	AF042-008-S2-P2	Frame: 042 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
	AF042-009-S1-P1	Frame: 042 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-009-S1-P2	Frame: 042 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-009-S2-P1	Frame: 042 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-009-S2-P2	Frame: 042 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-010-S1-P1	Frame: 042 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-010-S1-P2	Frame: 042 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-010-S2-P1	Frame: 042 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-010-S2-P2	Frame: 042 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-012-S1-P1	Frame: 042 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-012-S1-P2	Frame: 042 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-012-S2-P1	Frame: 042 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-012-S2-P2	Frame: 042 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-015-S1-P1	Frame: 042 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-015-S1-P2	Frame: 042 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-015-S2-P1	Frame: 042 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-015-S2-P2	Frame: 042 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-016-S1-P1	Frame: 042 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-016-S1-P2	Frame: 042 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-016-S2-P1	Frame: 042 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-016-S2-P2	Frame: 042 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-020-S1-P1	Frame: 042 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-020-S1-P2	Frame: 042 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-020-S2-P1	Frame: 042 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-020-S2-P2	Frame: 042 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-025-S1-P1	Frame: 042 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
	AF042-025-S1-P2	Frame: 042 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
	AF042-025-S2-P1	Frame: 042 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
	AF042-025-S2-P2	Frame: 042 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
	AF042-028-S1-P1	Frame: 042 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-028-S1-P2	Frame: 042 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-028-S2-P1	Frame: 042 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-028-S2-P2	Frame: 042 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-030-S1-P1	Frame: 042 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-030-S1-P2	Frame: 042 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-030-S2-P1	Frame: 042 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-030-S2-P2	Frame: 042 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-032-S1-P1	Frame: 042 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
	AF042-032-S1-P2	Frame: 042 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
	AF042-032-S2-P1	Frame: 042 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
	AF042-032-S2-P2	Frame: 042 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
	AF042-035-S1-P1	Frame: 042 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-035-S1-P2	Frame: 042 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-035-S2-P1	Frame: 042 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-035-S2-P2	Frame: 042 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-040-S1-P1	Frame: 042 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
	AF042-040-S1-P2	Frame: 042 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
	AF042-040-S2-P1	Frame: 042 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
	AF042-040-S2-P2	Frame: 042 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
	AF042-045-S1-P1	Frame: 042 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-045-S1-P2	Frame: 042 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-045-S2-P1	Frame: 042 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-045-S2-P2	Frame: 042 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-050-S1-P1	Frame: 042 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
	AF042-050-S1-P2	Frame: 042 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 22 Nm
	AF042-050-S2-P1	Frame: 042 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
	AF042-050-S2-P2	Frame: 042 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 22 Nm
	AF042-060-S1-P1	Frame: 042 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-060-S1-P2	Frame: 042 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 20 Nm
	AF042-060-S2-P1	Frame: 042 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-060-S2-P2	Frame: 042 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 20 Nm
	AF042-070-S1-P1	Frame: 042 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-070-S1-P2	Frame: 042 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 19 Nm
	AF042-070-S2-P1	Frame: 042 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-070-S2-P2	Frame: 042 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 19 Nm
	AF042-080-S1-P1	Frame: 042 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
	AF042-080-S1-P2	Frame: 042 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 17 Nm
	AF042-080-S2-P1	Frame: 042 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
	AF042-080-S2-P2	Frame: 042 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 17 Nm
	AF042-090-S1-P1	Frame: 042 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-090-S1-P2	Frame: 042 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-090-S2-P1	Frame: 042 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-090-S2-P2	Frame: 042 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-100-S1-P1	Frame: 042 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-100-S1-P2	Frame: 042 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 14 Nm
	AF042-100-S2-P1	Frame: 042 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF042-100-S2-P2	Frame: 042 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 14 Nm
	AF060-003-S1-P1	Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-003-S1-P2	Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-003-S2-P1	Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-003-S2-P2	Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-003-S3-P1	Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-003-S3-P2	Frame: 060 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-004-S1-P1	Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-004-S1-P2	Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-004-S2-P1	Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-004-S2-P2	Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-004-S3-P1	Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-004-S3-P2	Frame: 060 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-005-S1-P1	Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060-005-S1-P2	Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060-005-S2-P1	Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060-005-S2-P2	Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060-005-S3-P1	Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060-005-S3-P2	Frame: 060 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060-006-S1-P1	Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-006-S1-P2	Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-006-S2-P1	Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-006-S2-P2	Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-006-S3-P1	Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-006-S3-P2	Frame: 060 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-007-S1-P1	Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-007-S1-P2	Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-007-S2-P1	Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-007-S2-P2	Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-007-S3-P1	Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-007-S3-P2	Frame: 060 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-008-S1-P1	Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060-008-S1-P2	Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060-008-S2-P1	Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060-008-S2-P2	Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060-008-S3-P1	Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060-008-S3-P2	Frame: 060 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060-009-S1-P1	Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-009-S1-P2	Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-009-S2-P1	Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-009-S2-P2	Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-009-S3-P1	Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-009-S3-P2	Frame: 060 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-010-S1-P1	Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-010-S1-P2	Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-010-S2-P1	Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-010-S2-P2	Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-010-S3-P1	Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-010-S3-P2	Frame: 060 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-012-S1-P1	Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-012-S1-P2	Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-012-S2-P1	Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-012-S2-P2	Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-012-S3-P1	Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-012-S3-P2	Frame: 060 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-015-S1-P1	Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-015-S1-P2	Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-015-S2-P1	Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-015-S2-P2	Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-015-S3-P1	Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-015-S3-P2	Frame: 060 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-016-S1-P1	Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-016-S1-P2	Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-016-S2-P1	Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-016-S2-P2	Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-016-S3-P1	Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-016-S3-P2	Frame: 060 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-020-S1-P1	Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-020-S1-P2	Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-020-S2-P1	Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-020-S2-P2	Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-020-S3-P1	Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-020-S3-P2	Frame: 060 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-025-S1-P1	Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060-025-S1-P2	Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060-025-S2-P1	Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060-025-S2-P2	Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060-025-S3-P1	Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060-025-S3-P2	Frame: 060 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060-028-S1-P1	Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-028-S1-P2	Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-028-S2-P1	Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-028-S2-P2	Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-028-S3-P1	Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-028-S3-P2	Frame: 060 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-030-S1-P1	Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-030-S1-P2	Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-030-S2-P1	Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-030-S2-P2	Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-030-S3-P1	Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-030-S3-P2	Frame: 060 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-032-S1-P1	Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060-032-S1-P2	Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060-032-S2-P1	Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060-032-S2-P2	Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060-032-S3-P1	Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060-032-S3-P2	Frame: 060 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060-035-S1-P1	Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-035-S1-P2	Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-035-S2-P1	Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-035-S2-P2	Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-035-S3-P1	Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-035-S3-P2	Frame: 060 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-040-S1-P1	Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060-040-S1-P2	Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060-040-S2-P1	Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060-040-S2-P2	Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060-040-S3-P1	Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060-040-S3-P2	Frame: 060 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060-045-S1-P1	Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-045-S1-P2	Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-045-S2-P1	Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-045-S2-P2	Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-045-S3-P1	Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-045-S3-P2	Frame: 060 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-050-S1-P1	Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060-050-S1-P2	Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060-050-S2-P1	Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060-050-S2-P2	Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060-050-S3-P1	Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060-050-S3-P2	Frame: 060 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060-060-S1-P1	Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-060-S1-P2	Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060-060-S2-P1	Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-060-S2-P2	Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060-060-S3-P1	Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-060-S3-P2	Frame: 060 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060-070-S1-P1	Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-070-S1-P2	Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060-070-S2-P1	Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-070-S2-P2	Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060-070-S3-P1	Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-070-S3-P2	Frame: 060 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060-080-S1-P1	Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060-080-S1-P2	Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060-080-S2-P1	Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060-080-S2-P2	Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060-080-S3-P1	Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060-080-S3-P2	Frame: 060 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060-090-S1-P1	Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-090-S1-P2	Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-090-S2-P1	Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-090-S2-P2	Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-090-S3-P1	Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-090-S3-P2	Frame: 060 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-100-S1-P1	Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-100-S1-P2	Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060-100-S2-P1	Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-100-S2-P2	Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060-100-S3-P1	Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060-100-S3-P2	Frame: 060 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060A-012-S1-P1	Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-012-S1-P2	Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-012-S2-P1	Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-012-S2-P2	Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-012-S3-P1	Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-012-S3-P2	Frame: 060A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-015-S1-P1	Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060A-015-S1-P2	Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060A-015-S2-P1	Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060A-015-S2-P2	Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060A-015-S3-P1	Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060A-015-S3-P2	Frame: 060A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060A-016-S1-P1	Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-016-S1-P2	Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-016-S2-P1	Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-016-S2-P2	Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-016-S3-P1	Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-016-S3-P2	Frame: 060A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-020-S1-P1	Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-020-S1-P2	Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-020-S2-P1	Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-020-S2-P2	Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-020-S3-P1	Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-020-S3-P2	Frame: 060A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-025-S1-P1	Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060A-025-S1-P2	Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060A-025-S2-P1	Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060A-025-S2-P2	Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060A-025-S3-P1	Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060A-025-S3-P2	Frame: 060A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060A-028-S1-P1	Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-028-S1-P2	Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-028-S2-P1	Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-028-S2-P2	Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-028-S3-P1	Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-028-S3-P2	Frame: 060A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-030-S1-P1	Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060A-030-S1-P2	Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060A-030-S2-P1	Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060A-030-S2-P2	Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060A-030-S3-P1	Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060A-030-S3-P2	Frame: 060A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060A-032-S1-P1	Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060A-032-S1-P2	Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060A-032-S2-P1	Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060A-032-S2-P2	Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060A-032-S3-P1	Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060A-032-S3-P2	Frame: 060A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060A-035-S1-P1	Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-035-S1-P2	Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-035-S2-P1	Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-035-S2-P2	Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-035-S3-P1	Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-035-S3-P2	Frame: 060A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-040-S1-P1	Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060A-040-S1-P2	Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060A-040-S2-P1	Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060A-040-S2-P2	Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060A-040-S3-P1	Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060A-040-S3-P2	Frame: 060A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060A-045-S1-P1	Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060A-045-S1-P2	Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060A-045-S2-P1	Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060A-045-S2-P2	Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060A-045-S3-P1	Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060A-045-S3-P2	Frame: 060A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060A-050-S1-P1	Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060A-050-S1-P2	Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 60 Nm
	AF060A-050-S2-P1	Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060A-050-S2-P2	Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 60 Nm
	AF060A-050-S3-P1	Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060A-050-S3-P2	Frame: 060A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 60 Nm
	AF060A-060-S1-P1	Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060A-060-S1-P2	Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 55 Nm
	AF060A-060-S2-P1	Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060A-060-S2-P2	Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 55 Nm
	AF060A-060-S3-P1	Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060A-060-S3-P2	Frame: 060A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 55 Nm
	AF060A-070-S1-P1	Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-070-S1-P2	Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 50 Nm
	AF060A-070-S2-P1	Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-070-S2-P2	Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 50 Nm
	AF060A-070-S3-P1	Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-070-S3-P2	Frame: 060A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 50 Nm
	AF060A-080-S1-P1	Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060A-080-S1-P2	Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 45 Nm
	AF060A-080-S2-P1	Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060A-080-S2-P2	Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 45 Nm
	AF060A-080-S3-P1	Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060A-080-S3-P2	Frame: 060A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 45 Nm
	AF060A-090-S1-P1	Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060A-090-S1-P2	Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060A-090-S2-P1	Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060A-090-S2-P2	Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060A-090-S3-P1	Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060A-090-S3-P2	Frame: 060A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060A-100-S1-P1	Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060A-100-S1-P2	Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 40 Nm
	AF060A-100-S2-P1	Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060A-100-S2-P2	Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 40 Nm
	AF060A-100-S3-P1	Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF060A-100-S3-P2	Frame: 060A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 40 Nm
	AF075-003-S1-P0	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
	AF075-003-S1-P1	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
	AF075-003-S1-P2	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
	AF075-003-S2-P0	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
	AF075-003-S2-P1	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
	AF075-003-S2-P2	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
	AF075-003-S3-P0	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
	AF075-003-S3-P1	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
	AF075-003-S3-P2	Frame: 075 \| Ratio i: 3 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
	AF075-004-S1-P0	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-004-S1-P1	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-004-S1-P2	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-004-S2-P0	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-004-S2-P1	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-004-S2-P2	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-004-S3-P0	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-004-S3-P1	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-004-S3-P2	Frame: 075 \| Ratio i: 4 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-005-S1-P0	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075-005-S1-P1	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075-005-S1-P2	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075-005-S2-P0	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075-005-S2-P1	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075-005-S2-P2	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075-005-S3-P0	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075-005-S3-P1	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075-005-S3-P2	Frame: 075 \| Ratio i: 5 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075-006-S1-P0	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075-006-S1-P1	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075-006-S1-P2	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075-006-S2-P0	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075-006-S2-P1	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075-006-S2-P2	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075-006-S3-P0	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075-006-S3-P1	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075-006-S3-P2	Frame: 075 \| Ratio i: 6 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075-007-S1-P0	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-007-S1-P1	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-007-S1-P2	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-007-S2-P0	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-007-S2-P1	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-007-S2-P2	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-007-S3-P0	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-007-S3-P1	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-007-S3-P2	Frame: 075 \| Ratio i: 7 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-008-S1-P0	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-008-S1-P1	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-008-S1-P2	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-008-S2-P0	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-008-S2-P1	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-008-S2-P2	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-008-S3-P0	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-008-S3-P1	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-008-S3-P2	Frame: 075 \| Ratio i: 8 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-009-S1-P0	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-009-S1-P1	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-009-S1-P2	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-009-S2-P0	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-009-S2-P1	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-009-S2-P2	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-009-S3-P0	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-009-S3-P1	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-009-S3-P2	Frame: 075 \| Ratio i: 9 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-010-S1-P0	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-010-S1-P1	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-010-S1-P2	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-010-S2-P0	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-010-S2-P1	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-010-S2-P2	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-010-S3-P0	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P0 <=1 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-010-S3-P1	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P1 <=3 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-010-S3-P2	Frame: 075 \| Ratio i: 10 \| Stages: 1 \| Backlash: P2 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-012-S1-P1	Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-012-S1-P2	Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-012-S2-P1	Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-012-S2-P2	Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-012-S3-P1	Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-012-S3-P2	Frame: 075 \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-015-S1-P1	Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
	AF075-015-S1-P2	Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
	AF075-015-S2-P1	Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
	AF075-015-S2-P2	Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
	AF075-015-S3-P1	Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
	AF075-015-S3-P2	Frame: 075 \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
	AF075-016-S1-P1	Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-016-S1-P2	Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-016-S2-P1	Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-016-S2-P2	Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-016-S3-P1	Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-016-S3-P2	Frame: 075 \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-020-S1-P1	Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-020-S1-P2	Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-020-S2-P1	Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-020-S2-P2	Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-020-S3-P1	Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-020-S3-P2	Frame: 075 \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-025-S1-P1	Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075-025-S1-P2	Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075-025-S2-P1	Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075-025-S2-P2	Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075-025-S3-P1	Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075-025-S3-P2	Frame: 075 \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075-028-S1-P1	Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-028-S1-P2	Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-028-S2-P1	Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-028-S2-P2	Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-028-S3-P1	Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-028-S3-P2	Frame: 075 \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-030-S1-P1	Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075-030-S1-P2	Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075-030-S2-P1	Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075-030-S2-P2	Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075-030-S3-P1	Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075-030-S3-P2	Frame: 075 \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075-032-S1-P1	Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-032-S1-P2	Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-032-S2-P1	Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-032-S2-P2	Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-032-S3-P1	Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-032-S3-P2	Frame: 075 \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-035-S1-P1	Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-035-S1-P2	Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-035-S2-P1	Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-035-S2-P2	Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-035-S3-P1	Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-035-S3-P2	Frame: 075 \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-040-S1-P1	Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-040-S1-P2	Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-040-S2-P1	Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-040-S2-P2	Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-040-S3-P1	Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-040-S3-P2	Frame: 075 \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-045-S1-P1	Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-045-S1-P2	Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-045-S2-P1	Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-045-S2-P2	Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-045-S3-P1	Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-045-S3-P2	Frame: 075 \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-050-S1-P1	Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075-050-S1-P2	Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075-050-S2-P1	Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075-050-S2-P2	Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075-050-S3-P1	Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075-050-S3-P2	Frame: 075 \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075-060-S1-P1	Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075-060-S1-P2	Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075-060-S2-P1	Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075-060-S2-P2	Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075-060-S3-P1	Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075-060-S3-P2	Frame: 075 \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075-070-S1-P1	Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-070-S1-P2	Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075-070-S2-P1	Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-070-S2-P2	Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075-070-S3-P1	Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-070-S3-P2	Frame: 075 \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075-080-S1-P1	Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-080-S1-P2	Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075-080-S2-P1	Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-080-S2-P2	Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075-080-S3-P1	Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-080-S3-P2	Frame: 075 \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075-090-S1-P1	Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-090-S1-P2	Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-090-S2-P1	Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-090-S2-P2	Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-090-S3-P1	Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-090-S3-P2	Frame: 075 \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-100-S1-P1	Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-100-S1-P2	Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075-100-S2-P1	Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-100-S2-P2	Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075-100-S3-P1	Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075-100-S3-P2	Frame: 075 \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075A-012-S1-P1	Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-012-S1-P2	Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-012-S2-P1	Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-012-S2-P2	Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-012-S3-P1	Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-012-S3-P2	Frame: 075A \| Ratio i: 12 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-015-S1-P1	Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
	AF075A-015-S1-P2	Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 130 Nm
	AF075A-015-S2-P1	Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
	AF075A-015-S2-P2	Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 130 Nm
	AF075A-015-S3-P1	Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
	AF075A-015-S3-P2	Frame: 075A \| Ratio i: 15 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 130 Nm
	AF075A-016-S1-P1	Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-016-S1-P2	Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-016-S2-P1	Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-016-S2-P2	Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-016-S3-P1	Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-016-S3-P2	Frame: 075A \| Ratio i: 16 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-020-S1-P1	Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-020-S1-P2	Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-020-S2-P1	Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-020-S2-P2	Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-020-S3-P1	Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-020-S3-P2	Frame: 075A \| Ratio i: 20 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-025-S1-P1	Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075A-025-S1-P2	Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075A-025-S2-P1	Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075A-025-S2-P2	Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075A-025-S3-P1	Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075A-025-S3-P2	Frame: 075A \| Ratio i: 25 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075A-028-S1-P1	Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-028-S1-P2	Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-028-S2-P1	Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-028-S2-P2	Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-028-S3-P1	Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-028-S3-P2	Frame: 075A \| Ratio i: 28 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-030-S1-P1	Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075A-030-S1-P2	Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075A-030-S2-P1	Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075A-030-S2-P2	Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075A-030-S3-P1	Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075A-030-S3-P2	Frame: 075A \| Ratio i: 30 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075A-032-S1-P1	Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075A-032-S1-P2	Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075A-032-S2-P1	Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075A-032-S2-P2	Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075A-032-S3-P1	Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075A-032-S3-P2	Frame: 075A \| Ratio i: 32 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075A-035-S1-P1	Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-035-S1-P2	Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-035-S2-P1	Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-035-S2-P2	Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-035-S3-P1	Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-035-S3-P2	Frame: 075A \| Ratio i: 35 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-040-S1-P1	Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075A-040-S1-P2	Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075A-040-S2-P1	Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075A-040-S2-P2	Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075A-040-S3-P1	Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075A-040-S3-P2	Frame: 075A \| Ratio i: 40 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075A-045-S1-P1	Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075A-045-S1-P2	Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075A-045-S2-P1	Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075A-045-S2-P2	Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075A-045-S3-P1	Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075A-045-S3-P2	Frame: 075A \| Ratio i: 45 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075A-050-S1-P1	Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075A-050-S1-P2	Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 160 Nm
	AF075A-050-S2-P1	Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075A-050-S2-P2	Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 160 Nm
	AF075A-050-S3-P1	Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075A-050-S3-P2	Frame: 075A \| Ratio i: 50 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 160 Nm
	AF075A-060-S1-P1	Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075A-060-S1-P2	Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 150 Nm
	AF075A-060-S2-P1	Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075A-060-S2-P2	Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 150 Nm
	AF075A-060-S3-P1	Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075A-060-S3-P2	Frame: 075A \| Ratio i: 60 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 150 Nm
	AF075A-070-S1-P1	Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-070-S1-P2	Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 140 Nm
	AF075A-070-S2-P1	Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-070-S2-P2	Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 140 Nm
	AF075A-070-S3-P1	Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-070-S3-P2	Frame: 075A \| Ratio i: 70 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 140 Nm
	AF075A-080-S1-P1	Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075A-080-S1-P2	Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 120 Nm
	AF075A-080-S2-P1	Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075A-080-S2-P2	Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 120 Nm
	AF075A-080-S3-P1	Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075A-080-S3-P2	Frame: 075A \| Ratio i: 80 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 120 Nm
	AF075A-090-S1-P1	Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075A-090-S1-P2	Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075A-090-S2-P1	Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075A-090-S2-P2	Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075A-090-S3-P1	Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075A-090-S3-P2	Frame: 075A \| Ratio i: 90 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075A-100-S1-P1	Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075A-100-S1-P2	Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S1 smooth \| Nominal torque T2N: 100 Nm
	AF075A-100-S2-P1	Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075A-100-S2-P2	Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S2 keyed \| Nominal torque T2N: 100 Nm
	AF075A-100-S3-P1	Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P1 <=5 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm
	AF075A-100-S3-P2	Frame: 075A \| Ratio i: 100 \| Stages: 2 \| Backlash: P2 <=7 arcmin \| Output shaft: S3 DIN 5480 spline \| Nominal torque T2N: 100 Nm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Motors & Gearheads →

Item added to your cart

Apex Dynamics AF Precision Planetary Gearboxes (Frame 042-075A)
