CKD Air Tank for Air Booster AT2 Series

CKD Air Tank for Air Booster AT2 Series

Stainless steel air tank used together with the ABP2 air booster to store boosted compressed air.

Key features

  • Two capacities: 5 L and 10 L, Rc3/8 connection, maximum working pressure 0.99 MPa

Specifications

Port size Rc3/8
Max. working pressure (MPa) 0.99
Proof pressure (MPa) 1.5
Ambient temperature (°C) 0 to 50
Material Stainless steel
AT2-05S Capacity (L): 5 | Port size: Rc3/8 | Max. working pressure (MPa): 0.99 | Proof pressure (MPa): 1.5 | Ambient temperature (°C): 0 to 50 | Material: Stainless steel | Mass (kg): 7.3
AT2-10S Capacity (L): 10 | Port size: Rc3/8 | Max. working pressure (MPa): 0.99 | Proof pressure (MPa): 1.5 | Ambient temperature (°C): 0 to 50 | Material: Stainless steel | Mass (kg): 10.5
Air TanksCKD
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD Air Tank for Air Booster AT2 Series

Brand CKD·Air Tanks

Available part numbers (2)

AT2-05S, AT2-10S

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AT2-05SCapacity (L): 5 | Port size: Rc3/8 | Max. working pressure (MPa): 0.99 | Proof pressure (MPa): 1.5 | Ambient temperature (°C): 0 to 50 | Material: Stainless steel | Mass (kg): 7.3
AT2-10SCapacity (L): 10 | Port size: Rc3/8 | Max. working pressure (MPa): 0.99 | Proof pressure (MPa): 1.5 | Ambient temperature (°C): 0 to 50 | Material: Stainless steel | Mass (kg): 10.5
