CKD Super Dryer Modular SDM4000 Series (Large-Flow Membrane Air Dryer)

CKD Super Dryer Modular SDM4000 Series (Large-Flow Membrane Air Dryer)

Large-flow polymer membrane air dryer built from connected membrane modules on a header, handling compressors up to 75 kW with one unit.

Key features

  • No electrical power required, making it suitable for explosion-proof areas
  • Models with 6 or more modules are floor-standing

Specifications

Inlet pressure 0.7 MPa
Inlet pressure range (MPa) 0.4-1.5
SDM4050-2-A07 Modules: 2 | Outlet atmospheric dew point (C): -20 | Inlet air flow (m3/min ANR): 1.36 | Outlet air flow (m3/min ANR): 1.14 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-2-A07 Modules: 2 | Outlet atmospheric dew point (C): -20 | Inlet air flow (m3/min ANR): 2.20 | Outlet air flow (m3/min ANR): 1.86 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-3-A07 Modules: 3 | Outlet atmospheric dew point (C): -20 | Inlet air flow (m3/min ANR): 3.30 | Outlet air flow (m3/min ANR): 2.79 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4050-6-A07 Modules: 6 | Outlet atmospheric dew point (C): -20 | Inlet air flow (m3/min ANR): 4.08 | Outlet air flow (m3/min ANR): 3.42 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-6-A07 Modules: 6 | Outlet atmospheric dew point (C): -20 | Inlet air flow (m3/min ANR): 6.60 | Outlet air flow (m3/min ANR): 5.58 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4100-6-A07 Modules: 6 | Outlet atmospheric dew point (C): -20 | Inlet air flow (m3/min ANR): 9.20 | Outlet air flow (m3/min ANR): 7.76 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4100-8-A07 Modules: 8 | Outlet atmospheric dew point (C): -20 | Inlet air flow (m3/min ANR): 12.40 | Outlet air flow (m3/min ANR): 10.48 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4050-2-B07 Modules: 2 | Outlet atmospheric dew point (C): -40 | Inlet air flow (m3/min ANR): 0.82 | Outlet air flow (m3/min ANR): 0.60 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-2-B07 Modules: 2 | Outlet atmospheric dew point (C): -40 | Inlet air flow (m3/min ANR): 1.30 | Outlet air flow (m3/min ANR): 0.96 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-3-B07 Modules: 3 | Outlet atmospheric dew point (C): -40 | Inlet air flow (m3/min ANR): 1.95 | Outlet air flow (m3/min ANR): 1.44 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4100-3-B07 Modules: 3 | Outlet atmospheric dew point (C): -40 | Inlet air flow (m3/min ANR): 2.67 | Outlet air flow (m3/min ANR): 1.95 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-6-B07 Modules: 6 | Outlet atmospheric dew point (C): -40 | Inlet air flow (m3/min ANR): 3.90 | Outlet air flow (m3/min ANR): 2.88 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-10-B07 Modules: 10 | Outlet atmospheric dew point (C): -40 | Inlet air flow (m3/min ANR): 6.50 | Outlet air flow (m3/min ANR): 4.80 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4050-2-C07 Modules: 2 | Outlet atmospheric dew point (C): -60 | Inlet air flow (m3/min ANR): 0.50 | Outlet air flow (m3/min ANR): 0.28 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-2-C07 Modules: 2 | Outlet atmospheric dew point (C): -60 | Inlet air flow (m3/min ANR): 0.76 | Outlet air flow (m3/min ANR): 0.42 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-3-C07 Modules: 3 | Outlet atmospheric dew point (C): -60 | Inlet air flow (m3/min ANR): 1.14 | Outlet air flow (m3/min ANR): 0.63 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4100-3-C07 Modules: 3 | Outlet atmospheric dew point (C): -60 | Inlet air flow (m3/min ANR): 1.65 | Outlet air flow (m3/min ANR): 0.93 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-8-C07 Modules: 8 | Outlet atmospheric dew point (C): -60 | Inlet air flow (m3/min ANR): 3.04 | Outlet air flow (m3/min ANR): 1.68 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
SDM4075-10-C07 Modules: 10 | Outlet atmospheric dew point (C): -60 | Inlet air flow (m3/min ANR): 3.80 | Outlet air flow (m3/min ANR): 2.10 | Inlet pressure: 0.7 MPa | Inlet pressure range (MPa): 0.4-1.5
