Diatop Dry Asphalt / Green Concrete Blades (DAH)

Diatop Dry Asphalt / Green Concrete Blades (DAH)

Laser-welded diamond blades for dry cutting of asphalt and green concrete with handheld saws or low-power flat saws of 25 HP or less.

Key features

  • Designed for fast cutting and long life; best choice for medium-size work
  • Undercut protection by TCT inserts, deep segments or slanted segments. 12 in and 14 in sizes are for high-speed handheld saws
  • Premium, Supreme and Ultra quality available

Specifications

Segment Height 7, 8, 10 mm (.275, .315, .394 in)
Arbor 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH3028 Diameter: 300 mm (12 in) | Segment Thickness: 2.8 mm (.110 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH3032 Diameter: 300 mm (12 in) | Segment Thickness: 3.2 mm (.125 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH3532 Diameter: 350 mm (14 in) | Segment Thickness: 3.2 mm (.125 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH4032 Diameter: 400 mm (16 in) | Segment Thickness: 3.2 mm (.125 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH4536 Diameter: 450 mm (18 in) | Segment Thickness: 3.6 mm (.141 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH5040 Diameter: 500 mm (20 in) | Segment Thickness: 4.0 mm (.155 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
Diamond Saw BladesDiatop
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Diatop Dry Asphalt / Green Concrete Blades (DAH)

Brand Diatop·Diamond Saw Blades

Available part numbers (6)

DAH3028, DAH3032, DAH3532, DAH4032, DAH4536, DAH5040

How to order

Send the Diatop part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
DAH3028Diameter: 300 mm (12 in) | Segment Thickness: 2.8 mm (.110 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH3032Diameter: 300 mm (12 in) | Segment Thickness: 3.2 mm (.125 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH3532Diameter: 350 mm (14 in) | Segment Thickness: 3.2 mm (.125 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH4032Diameter: 400 mm (16 in) | Segment Thickness: 3.2 mm (.125 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH4536Diameter: 450 mm (18 in) | Segment Thickness: 3.6 mm (.141 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
DAH5040Diameter: 500 mm (20 in) | Segment Thickness: 4.0 mm (.155 in) | Segment Height: 7, 8, 10 mm (.275, .315, .394 in) | Arbor: 25.4 mm (1 in)-20 with drive pin (20 mm available for 12 in)
