Diatop Xpress Core Cutting Blade for Natural Rocks

Diatop Xpress Core Cutting Blade for Natural Rocks

Silver-brazed wet core cutting blade with patterned diamond technology for cutting cores of very hard natural rocks.

Key features

  • Evenly distributed diamonds give faster cutting and longer life than a conventional random diamond mix
  • Bonds from extremely soft to soft match rock categories Type 2 to Type 5; fewer segments are recommended for fastest cutting
  • Bore hole 25.4 mm (1"); pin holes on request

Specifications

Segment Length 10 mm
Bore 25.4 mm
XCXF 302810 D x T (inch): 12 x .110 in | D x T (mm): 300 x 2.8 mm | Segment Length: 10 mm | Category of Rocks: Type 5 | Number of Segments: 19 | Bond Hardness: Extremely soft | Bore: 25.4 mm
XCXF 352810 D x T (inch): 14 x .110 in | D x T (mm): 350 x 2.8 mm | Segment Length: 10 mm | Category of Rocks: Type 5 | Number of Segments: 23 | Bond Hardness: Extremely soft | Bore: 25.4 mm
XCX 302810 D x T (inch): 12 x .110 in | D x T (mm): 300 x 2.8 mm | Segment Length: 10 mm | Category of Rocks: Type 5 | Number of Segments: 21 | Bond Hardness: Extremely soft | Bore: 25.4 mm
XCX 352810 D x T (inch): 14 x .110 in | D x T (mm): 350 x 2.8 mm | Segment Length: 10 mm | Category of Rocks: Type 5 | Number of Segments: 25 | Bond Hardness: Extremely soft | Bore: 25.4 mm
XCV 302810 D x T (inch): 12 x .110 in | D x T (mm): 300 x 2.8 mm | Segment Length: 10 mm | Category of Rocks: Type 3,4 | Number of Segments: 21 | Bond Hardness: Very soft | Bore: 25.4 mm
XCV 352810 D x T (inch): 14 x .110 in | D x T (mm): 350 x 2.8 mm | Segment Length: 10 mm | Category of Rocks: Type 3,4 | Number of Segments: 25 | Bond Hardness: Very soft | Bore: 25.4 mm
XCS 302810 D x T (inch): 12 x .110 in | D x T (mm): 300 x 2.8 mm | Segment Length: 10 mm | Category of Rocks: Type 2 | Number of Segments: 21 | Bond Hardness: Soft | Bore: 25.4 mm
XCS 352810 D x T (inch): 14 x .110 in | D x T (mm): 350 x 2.8 mm | Segment Length: 10 mm | Category of Rocks: Type 2 | Number of Segments: 25 | Bond Hardness: Soft | Bore: 25.4 mm
Core Cutting BladesDiatop
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Diatop Xpress Core Cutting Blade for Natural Rocks

Brand Diatop·Core Cutting Blades

Available part numbers (8)

XCXF 302810, XCXF 352810, XCX 302810, XCX 352810, XCV 302810, XCV 352810, XCS 302810, XCS 352810
