GGM GUD Digital Speed Control Unit for AC Geared Motors (6–180W, Single-phase)

GGM GUD Digital Speed Control Unit for AC Geared Motors (6–180W, Single-phase)

GGM GUD digital speed control unit for AC induction & reversible geared motors, 6–180W.

Key features

  • CW/CCW reversing, 4-step multi-speed, electromagnetic brake control via I/O port; 90–1730 r/min (60Hz)

Specifications

Speed range 90–1730 r/min @60Hz, 90–1430 @50Hz
Direction CW/CCW (front key + I/O)
Multi-speed 4-step (I/O)
Brake electromagnetic (parameter-enabled)
Protection IP20
GUD-U-6 GGM GUD-U-6 digital speed control unit, single-phase AC 100–115V, for 6W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 6W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-15 GGM GUD-U-15 digital speed control unit, single-phase AC 100–115V, for 15W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 15W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-25 GGM GUD-U-25 digital speed control unit, single-phase AC 100–115V, for 25W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 25W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-40 GGM GUD-U-40 digital speed control unit, single-phase AC 100–115V, for 40W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 40W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-60 GGM GUD-U-60 digital speed control unit, single-phase AC 100–115V, for 60W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 60W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-90 GGM GUD-U-90 digital speed control unit, single-phase AC 100–115V, for 90W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 90W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-120 GGM GUD-U-120 digital speed control unit, single-phase AC 100–115V, for 120W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 120W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-150 GGM GUD-U-150 digital speed control unit, single-phase AC 100–115V, for 150W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 150W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-180 GGM GUD-U-180 digital speed control unit, single-phase AC 100–115V, for 180W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 180W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-6 GGM GUD-C-6 digital speed control unit, single-phase AC 220–240V, for 6W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 6W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-15 GGM GUD-C-15 digital speed control unit, single-phase AC 220–240V, for 15W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 15W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-25 GGM GUD-C-25 digital speed control unit, single-phase AC 220–240V, for 25W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 25W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-40 GGM GUD-C-40 digital speed control unit, single-phase AC 220–240V, for 40W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 40W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-60 GGM GUD-C-60 digital speed control unit, single-phase AC 220–240V, for 60W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 60W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-90 GGM GUD-C-90 digital speed control unit, single-phase AC 220–240V, for 90W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 90W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-120 GGM GUD-C-120 digital speed control unit, single-phase AC 220–240V, for 120W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 120W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-150 GGM GUD-C-150 digital speed control unit, single-phase AC 220–240V, for 150W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 150W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-180 GGM GUD-C-180 digital speed control unit, single-phase AC 220–240V, for 180W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 180W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
Speed ControllersGGM
18 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM GUD Digital Speed Control Unit for AC Geared Motors (6–180W, Single-phase)

Brand GGM·Speed Controllers

Available part numbers (18)

GUD-U-6, GUD-U-15, GUD-U-25, GUD-U-40, GUD-U-60, GUD-U-90, GUD-U-120, GUD-U-150, GUD-U-180, GUD-C-6 + 8 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GUD-U-6GGM GUD-U-6 digital speed control unit, single-phase AC 100–115V, for 6W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 6W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-15GGM GUD-U-15 digital speed control unit, single-phase AC 100–115V, for 15W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 15W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-25GGM GUD-U-25 digital speed control unit, single-phase AC 100–115V, for 25W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 25W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-40GGM GUD-U-40 digital speed control unit, single-phase AC 100–115V, for 40W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 40W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-60GGM GUD-U-60 digital speed control unit, single-phase AC 100–115V, for 60W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 60W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-90GGM GUD-U-90 digital speed control unit, single-phase AC 100–115V, for 90W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 90W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-120GGM GUD-U-120 digital speed control unit, single-phase AC 100–115V, for 120W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 120W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-150GGM GUD-U-150 digital speed control unit, single-phase AC 100–115V, for 150W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 150W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-U-180GGM GUD-U-180 digital speed control unit, single-phase AC 100–115V, for 180W motor | Input: 1-ph AC 100–115V 50/60Hz (±10%) | Motor output: 180W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-6GGM GUD-C-6 digital speed control unit, single-phase AC 220–240V, for 6W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 6W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-15GGM GUD-C-15 digital speed control unit, single-phase AC 220–240V, for 15W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 15W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-25GGM GUD-C-25 digital speed control unit, single-phase AC 220–240V, for 25W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 25W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-40GGM GUD-C-40 digital speed control unit, single-phase AC 220–240V, for 40W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 40W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-60GGM GUD-C-60 digital speed control unit, single-phase AC 220–240V, for 60W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 60W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-90GGM GUD-C-90 digital speed control unit, single-phase AC 220–240V, for 90W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 90W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-120GGM GUD-C-120 digital speed control unit, single-phase AC 220–240V, for 120W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 120W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-150GGM GUD-C-150 digital speed control unit, single-phase AC 220–240V, for 150W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 150W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
GUD-C-180GGM GUD-C-180 digital speed control unit, single-phase AC 220–240V, for 180W motor | Input: 1-ph AC 220–240V 50/60Hz (±10%) | Motor output: 180W (induction/reversible) | Speed range: 90–1730 r/min @60Hz, 90–1430 @50Hz | Direction: CW/CCW (front key + I/O) | Multi-speed: 4-step (I/O) | Brake: electromagnetic (parameter-enabled) | Protection: IP20
