GGM K35-3448-T DC Planetary Geared Motor (ø35mm, 7500 rpm class, 12/24V, 1/5–1/721)

GGM K35-3448-T DC Planetary Geared Motor (ø35mm, 7500 rpm class, 12/24V, 1/5–1/721)

GGM K35-3448 series DC planetary geared motor, ø35mm frame, ø6mm shaft, 4-M3 flange (PCD ø26).

Key features

  • T-speed winding (12V/24V), 13 ratios 1/5 to 1/721; 140g
  • Optional 20-pole/10-pulse incremental encoder (-E) available

Specifications

No-load Speed 7500 rpm
Frame ø35mm
Output Shaft ø6mm, 4-M3 flange (PCD ø26)
Type DC planetary geared motor
K35-0005-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/5, 1300 rpm / 0.3 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/5 | Output Speed (max eff.): 1300 rpm | Output Torque (max eff.): 0.3 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 22.1 mm | Type: DC planetary geared motor
K35-0014-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/14, 464 rpm / 0.7 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 464 rpm | Output Torque (max eff.): 0.7 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor
K35-0019-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/19, 342 rpm / 1 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/19 | Output Speed (max eff.): 342 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor
K35-0027-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/27, 240 rpm / 1.4 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/27 | Output Speed (max eff.): 240 rpm | Output Torque (max eff.): 1.4 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor
K35-0051-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/51, 127 rpm / 2.1 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/51 | Output Speed (max eff.): 127 rpm | Output Torque (max eff.): 2.1 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor
K35-0071-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/71, 91 rpm / 2.9 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/71 | Output Speed (max eff.): 91 rpm | Output Torque (max eff.): 2.9 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor
K35-0100-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/100, 65 rpm / 4.1 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/100 | Output Speed (max eff.): 65 rpm | Output Torque (max eff.): 4.1 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor
K35-0139-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/139, 46 rpm / 5.7 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/139 | Output Speed (max eff.): 46 rpm | Output Torque (max eff.): 5.7 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor
K35-0189-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/189, 34 rpm / 6.2 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/189 | Output Speed (max eff.): 34 rpm | Output Torque (max eff.): 6.2 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0264-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/264, 24 rpm / 8.6 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/264 | Output Speed (max eff.): 24 rpm | Output Torque (max eff.): 8.6 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0369-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/369, 17 rpm / 12 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/369 | Output Speed (max eff.): 17 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0516-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/516, 12 rpm / 12 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/516 | Output Speed (max eff.): 12 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0721-KD3448T1 GGM K35-3448-T DC 12V planetary geared motor, ratio 1/721, 9 rpm / 12 kgf·cm @ max eff. | Motor: KD3448T1 | Voltage: DC 12V | Gear Ratio: 1/721 | Output Speed (max eff.): 9 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 730 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0005-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/5, 1300 rpm / 0.3 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/5 | Output Speed (max eff.): 1300 rpm | Output Torque (max eff.): 0.3 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 22.1 mm | Type: DC planetary geared motor
K35-0014-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/14, 464 rpm / 0.7 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 464 rpm | Output Torque (max eff.): 0.7 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor
K35-0019-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/19, 342 rpm / 1 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/19 | Output Speed (max eff.): 342 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor
K35-0027-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/27, 240 rpm / 1.4 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/27 | Output Speed (max eff.): 240 rpm | Output Torque (max eff.): 1.4 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 28.5 mm | Type: DC planetary geared motor
K35-0051-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/51, 127 rpm / 2.1 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/51 | Output Speed (max eff.): 127 rpm | Output Torque (max eff.): 2.1 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor
K35-0071-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/71, 91 rpm / 2.9 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/71 | Output Speed (max eff.): 91 rpm | Output Torque (max eff.): 2.9 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor
K35-0100-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/100, 65 rpm / 4.1 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/100 | Output Speed (max eff.): 65 rpm | Output Torque (max eff.): 4.1 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor
K35-0139-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/139, 46 rpm / 5.7 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/139 | Output Speed (max eff.): 46 rpm | Output Torque (max eff.): 5.7 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 34.9 mm | Type: DC planetary geared motor
K35-0189-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/189, 34 rpm / 6.2 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/189 | Output Speed (max eff.): 34 rpm | Output Torque (max eff.): 6.2 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0264-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/264, 24 rpm / 8.6 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/264 | Output Speed (max eff.): 24 rpm | Output Torque (max eff.): 8.6 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0369-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/369, 17 rpm / 12 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/369 | Output Speed (max eff.): 17 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0516-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/516, 12 rpm / 12 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/516 | Output Speed (max eff.): 12 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
K35-0721-KD3448T2 GGM K35-3448-T DC 24V planetary geared motor, ratio 1/721, 9 rpm / 12 kgf·cm @ max eff. | Motor: KD3448T2 | Voltage: DC 24V | Gear Ratio: 1/721 | Output Speed (max eff.): 9 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7500 rpm | Stall Torque: 700 gf·cm | Frame: ø35mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø26) | Gearhead Length L: 41.3 mm | Type: DC planetary geared motor
DCGGM
26 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM K35-3448-T DC Planetary Geared Motor (ø35mm, 7500 rpm class, 12/24V, 1/5–1/721)

Brand GGM·DC

Available part numbers (26)

K35-0005-KD3448T1, K35-0014-KD3448T1, K35-0019-KD3448T1, K35-0027-KD3448T1, K35-0051-KD3448T1, K35-0071-KD3448T1, K35-0100-KD3448T1, K35-0139-KD3448T1, K35-0189-KD3448T1, K35-0264-KD3448T1 + 16 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
