• Brushless DC Motors K35 BLDC Planetary Gearmotor KB3640S2-T (Ø35, DC 24V, 1/5–1/721, with Brake)
1 1

Brushless DC Motors K35 BLDC Planetary Gearmotor KB3640S2-T (Ø35, DC 24V, 1/5–1/721, with Brake)

Brushless DC Motors K35 BLDC Planetary Gearmotor KB3640S2-T (Ø35, DC 24V, 1/5–1/721, with Brake)

GGM K35 Ø35 BLDC planetary gearmotor KB3640S2-T, DC 24V, 13 gear ratios from 1/5 to 1/721. integrated brake and FG tacho feedback (6 pulses/rev), 300 mm leads (no-PCB control), PWM speed control (GUN-type controller), max output torque 12 kgf·cm, output rotates same direction as motor.

K35-0005-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/5, 780 rpm / 1.1 kgf·cm (DC 24V) | Gear Ratio: 1/5 | Output Speed: 780 rpm (at max. eff.) | Output Torque: 1.1 kgf·cm
K35-0014-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/14, 278 rpm / 2.9 kgf·cm (DC 24V) | Gear Ratio: 1/14 | Output Speed: 278 rpm (at max. eff.) | Output Torque: 2.9 kgf·cm
K35-0019-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/19, 205 rpm / 3.9 kgf·cm (DC 24V) | Gear Ratio: 1/19 | Output Speed: 205 rpm (at max. eff.) | Output Torque: 3.9 kgf·cm
K35-0027-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/27, 144 rpm / 5.6 kgf·cm (DC 24V) | Gear Ratio: 1/27 | Output Speed: 144 rpm (at max. eff.) | Output Torque: 5.6 kgf·cm
K35-0051-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/51, 76 rpm / 9.5 kgf·cm (DC 24V) | Gear Ratio: 1/51 | Output Speed: 76 rpm (at max. eff.) | Output Torque: 9.5 kgf·cm
K35-0071-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/71, 55 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/71 | Output Speed: 55 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0100-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/100, 39 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/100 | Output Speed: 39 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0139-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/139, 28 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/139 | Output Speed: 28 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0189-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/189, 21 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/189 | Output Speed: 21 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0264-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/264, 15 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/264 | Output Speed: 15 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0369-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/369, 10.5 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/369 | Output Speed: 10.5 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0516-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/516, 7.6 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/516 | Output Speed: 7.6 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0721-KB3640S2-T K35 BLDC gearmotor KB3640S2-T, 1/721, 5.4 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/721 | Output Speed: 5.4 rpm (at max. eff.) | Output Torque: 12 kgf·cm
Brushless DC Motors
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Brushless DC Motors K35 BLDC Planetary Gearmotor KB3640S2-T (Ø35, DC 24V, 1/5–1/721, with Brake)

Brand Brushless DC Motors

Available part numbers (13)

K35-0005-KB3640S2-T, K35-0014-KB3640S2-T, K35-0019-KB3640S2-T, K35-0027-KB3640S2-T, K35-0051-KB3640S2-T, K35-0071-KB3640S2-T, K35-0100-KB3640S2-T, K35-0139-KB3640S2-T, K35-0189-KB3640S2-T, K35-0264-KB3640S2-T + 3 more — see full table ↓

How to order

Send the Brushless DC Motors part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
K35-0005-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/5, 780 rpm / 1.1 kgf·cm (DC 24V) | Gear Ratio: 1/5 | Output Speed: 780 rpm (at max. eff.) | Output Torque: 1.1 kgf·cm
K35-0014-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/14, 278 rpm / 2.9 kgf·cm (DC 24V) | Gear Ratio: 1/14 | Output Speed: 278 rpm (at max. eff.) | Output Torque: 2.9 kgf·cm
K35-0019-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/19, 205 rpm / 3.9 kgf·cm (DC 24V) | Gear Ratio: 1/19 | Output Speed: 205 rpm (at max. eff.) | Output Torque: 3.9 kgf·cm
K35-0027-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/27, 144 rpm / 5.6 kgf·cm (DC 24V) | Gear Ratio: 1/27 | Output Speed: 144 rpm (at max. eff.) | Output Torque: 5.6 kgf·cm
K35-0051-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/51, 76 rpm / 9.5 kgf·cm (DC 24V) | Gear Ratio: 1/51 | Output Speed: 76 rpm (at max. eff.) | Output Torque: 9.5 kgf·cm
K35-0071-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/71, 55 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/71 | Output Speed: 55 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0100-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/100, 39 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/100 | Output Speed: 39 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0139-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/139, 28 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/139 | Output Speed: 28 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0189-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/189, 21 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/189 | Output Speed: 21 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0264-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/264, 15 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/264 | Output Speed: 15 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0369-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/369, 10.5 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/369 | Output Speed: 10.5 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0516-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/516, 7.6 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/516 | Output Speed: 7.6 rpm (at max. eff.) | Output Torque: 12 kgf·cm
K35-0721-KB3640S2-TK35 BLDC gearmotor KB3640S2-T, 1/721, 5.4 rpm / 12 kgf·cm (DC 24V) | Gear Ratio: 1/721 | Output Speed: 5.4 rpm (at max. eff.) | Output Torque: 12 kgf·cm
