GGM K6H□B Solid-Shaft Gearhead (for K6 30W Brushless Motor Unit, ø10 solid, 1/5~1/200)

GGM K6H□B Solid-Shaft Gearhead (for K6 30W Brushless Motor Unit, ø10 solid, 1/5~1/200)

GGM K6H□B inline solid-shaft gearhead for K6 30W brushless AC/DC motor units, with ø10 keyed output shaft and □60 flange (ø70 P.C.D).

Key features

  • Deceleration ratios 1/5 to 1/200 (8 steps), allowed output torque up to 6 N·m, 81–90% efficiency; motor sold separately

Specifications

Type Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit)
Allowed Thrust Load 40 N
Output Shaft ø10 solid, key type
Flange □60, P.C.D ø70
K6H5B GGM K6H□B inline solid-shaft gearhead, ratio 1/5, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/5 | Output Speed Range: 20~600 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.45 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 100 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included)
K6H10B GGM K6H□B inline solid-shaft gearhead, ratio 1/10, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/10 | Output Speed Range: 10~300 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.9 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included)
K6H15B GGM K6H□B inline solid-shaft gearhead, ratio 1/15, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/15 | Output Speed Range: 6.7~200 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.4 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included)
K6H20B GGM K6H□B inline solid-shaft gearhead, ratio 1/20, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/20 | Output Speed Range: 5~150 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.8 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included)
K6H30B GGM K6H□B inline solid-shaft gearhead, ratio 1/30, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/30 | Output Speed Range: 3.3~100 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 2.6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included)
K6H50B GGM K6H□B inline solid-shaft gearhead, ratio 1/50, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/50 | Output Speed Range: 2~60 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 4.3 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included)
K6H100B GGM K6H□B inline solid-shaft gearhead, ratio 1/100, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/100 | Output Speed Range: 1~30 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included)
K6H200B GGM K6H□B inline solid-shaft gearhead, ratio 1/200, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/200 | Output Speed Range: 0.5~15 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 81% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×60 (set included)
GearheadsGGM
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM K6H□B Solid-Shaft Gearhead (for K6 30W Brushless Motor Unit, ø10 solid, 1/5~1/200)

Brand GGM·Gearheads

Available part numbers (8)

K6H5B, K6H10B, K6H15B, K6H20B, K6H30B, K6H50B, K6H100B, K6H200B

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
K6H5BGGM K6H□B inline solid-shaft gearhead, ratio 1/5, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/5 | Output Speed Range: 20~600 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.45 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 100 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included)
K6H10BGGM K6H□B inline solid-shaft gearhead, ratio 1/10, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/10 | Output Speed Range: 10~300 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.9 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included)
K6H15BGGM K6H□B inline solid-shaft gearhead, ratio 1/15, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/15 | Output Speed Range: 6.7~200 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.4 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included)
K6H20BGGM K6H□B inline solid-shaft gearhead, ratio 1/20, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/20 | Output Speed Range: 5~150 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.8 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 90% | Allowed Overhang Load: 150 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×50 (set included)
K6H30BGGM K6H□B inline solid-shaft gearhead, ratio 1/30, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/30 | Output Speed Range: 3.3~100 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 2.6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included)
K6H50BGGM K6H□B inline solid-shaft gearhead, ratio 1/50, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/50 | Output Speed Range: 2~60 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 4.3 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included)
K6H100BGGM K6H□B inline solid-shaft gearhead, ratio 1/100, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/100 | Output Speed Range: 1~30 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 86% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×55 (set included)
K6H200BGGM K6H□B inline solid-shaft gearhead, ratio 1/200, ø10 keyed shaft, for K6 30W brushless motor unit | Type: Inline Solid-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/200 | Output Speed Range: 0.5~15 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 81% | Allowed Overhang Load: 200 N (at 10mm from shaft end) | Allowed Thrust Load: 40 N | Output Shaft: ø10 solid, key type | Flange: □60, P.C.D ø70 | Fixing Bolt: M4 P0.7×60 (set included)
