GGM K6H□BTH Flat Hollow-Shaft Gearhead (for K6 30W Brushless Motor Unit, ø12 hollow, 1/5~1/200)

GGM K6H□BTH Flat Hollow-Shaft Gearhead (for K6 30W Brushless Motor Unit, ø12 hollow, 1/5~1/200)

GGM K6H□BTH flat hollow-shaft gearhead for K6 30W brushless AC/DC motor units, with ø12 hollow output bore (H8), ø54 pilot flange and M5×65 fixing bolt set (included).

Key features

  • Deceleration ratios 1/5 to 1/200 (8 steps), allowed output torque up to 17 N·m, 80–85% efficiency; motor sold separately

Specifications

Type Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit)
Allowed Thrust Load 200 N
Output Shaft ø12 hollow bore (H8), key type
Flange ø54 (h7), P.C.D ø70
Fixing Bolt M5 P0.8×65 (set included)
K6H5BTH GGM K6H□BTH flat hollow-shaft gearhead, ratio 1/5, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/5 | Output Speed Range: 20~600 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.4 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 80% | Allowed Overhang Load: 450 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H10BTH GGM K6H□BTH flat hollow-shaft gearhead, ratio 1/10, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/10 | Output Speed Range: 10~300 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.85 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 450 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H15BTH GGM K6H□BTH flat hollow-shaft gearhead, ratio 1/15, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/15 | Output Speed Range: 6.7~200 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.3 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H20BTH GGM K6H□BTH flat hollow-shaft gearhead, ratio 1/20, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/20 | Output Speed Range: 5~150 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.7 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H30BTH GGM K6H□BTH flat hollow-shaft gearhead, ratio 1/30, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/30 | Output Speed Range: 3.3~100 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 2.6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H50BTH GGM K6H□BTH flat hollow-shaft gearhead, ratio 1/50, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/50 | Output Speed Range: 2~60 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 4.3 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H100BTH GGM K6H□BTH flat hollow-shaft gearhead, ratio 1/100, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/100 | Output Speed Range: 1~30 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 8.5 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H200BTH GGM K6H□BTH flat hollow-shaft gearhead, ratio 1/200, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/200 | Output Speed Range: 0.5~15 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 17 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
GearheadsGGM
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM K6H□BTH Flat Hollow-Shaft Gearhead (for K6 30W Brushless Motor Unit, ø12 hollow, 1/5~1/200)

Brand GGM·Gearheads

Available part numbers (8)

K6H5BTH, K6H10BTH, K6H15BTH, K6H20BTH, K6H30BTH, K6H50BTH, K6H100BTH, K6H200BTH

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
K6H5BTHGGM K6H□BTH flat hollow-shaft gearhead, ratio 1/5, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/5 | Output Speed Range: 20~600 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.4 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 80% | Allowed Overhang Load: 450 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H10BTHGGM K6H□BTH flat hollow-shaft gearhead, ratio 1/10, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/10 | Output Speed Range: 10~300 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 0.85 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 450 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H15BTHGGM K6H□BTH flat hollow-shaft gearhead, ratio 1/15, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/15 | Output Speed Range: 6.7~200 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.3 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H20BTHGGM K6H□BTH flat hollow-shaft gearhead, ratio 1/20, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/20 | Output Speed Range: 5~150 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 1.7 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H30BTHGGM K6H□BTH flat hollow-shaft gearhead, ratio 1/30, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/30 | Output Speed Range: 3.3~100 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 2.6 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H50BTHGGM K6H□BTH flat hollow-shaft gearhead, ratio 1/50, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/50 | Output Speed Range: 2~60 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 4.3 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H100BTHGGM K6H□BTH flat hollow-shaft gearhead, ratio 1/100, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/100 | Output Speed Range: 1~30 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 8.5 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
K6H200BTHGGM K6H□BTH flat hollow-shaft gearhead, ratio 1/200, ø12 hollow bore, for K6 30W brushless motor unit | Type: Flat Hollow-Shaft Gearhead (for K6 Brushless Motor Unit) | Deceleration Ratio: 1/200 | Output Speed Range: 0.5~15 r/min (with K6BH 100-3000 r/min motor) | Allowed Output Torque: 17 N·m (K6 30W brushless, AC type) | Gearhead Efficiency: 85% | Allowed Overhang Load: 500 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø12 hollow bore (H8), key type | Flange: ø54 (h7), P.C.D ø70 | Fixing Bolt: M5 P0.8×65 (set included)
