GGM K9G Gearhead for □90 40W Geared Motors (□90mm, 1/3–1/200 + Decimal, Cap 10 N·m, ø12 Keyed Shaft)

GGM K9G Gearhead for □90 40W Geared Motors (□90mm, 1/3–1/200 + Decimal, Cap 10 N·m, ø12 Keyed Shaft)

GGM K9G parallel-shaft gearhead for □90mm 40W GGM geared motors (induction, reversible, brake, speed-control), sold separately from the motor. 24 gear ratios 1/3–1/200 plus decimal gearhead K9G10BX (1/10), ø12 (h7) keyed output shaft, max permissible torque 10 N·m / 100 kgf·cm.

Specifications

Max Permissible Torque 10 N·m / 100 kgf·cm
K9G3B GGM K9G gearhead K9G3B — ratio 1/3, output 500/600 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/3 | Output Speed: 500 rpm @50Hz / 600 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G3.6B GGM K9G gearhead K9G3.6B — ratio 1/3.6, output 416/500 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm @50Hz / 500 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G5B GGM K9G gearhead K9G5B — ratio 1/5, output 300/360 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/5 | Output Speed: 300 rpm @50Hz / 360 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G6B GGM K9G gearhead K9G6B — ratio 1/6, output 250/300 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/6 | Output Speed: 250 rpm @50Hz / 300 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G7.5B GGM K9G gearhead K9G7.5B — ratio 1/7.5, output 200/240 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm @50Hz / 240 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G9B GGM K9G gearhead K9G9B — ratio 1/9, output 166/200 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/9 | Output Speed: 166 rpm @50Hz / 200 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G10B GGM K9G gearhead K9G10B — ratio 1/10, output 150/180 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/10 | Output Speed: 150 rpm @50Hz / 180 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G12.5B GGM K9G gearhead K9G12.5B — ratio 1/12.5, output 120/144 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm @50Hz / 144 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G15B GGM K9G gearhead K9G15B — ratio 1/15, output 100/120 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/15 | Output Speed: 100 rpm @50Hz / 120 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G18B GGM K9G gearhead K9G18B — ratio 1/18, output 83/100 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/18 | Output Speed: 83 rpm @50Hz / 100 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G20B GGM K9G gearhead K9G20B — ratio 1/20, output 75/90 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/20 | Output Speed: 75 rpm @50Hz / 90 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G25B GGM K9G gearhead K9G25B — ratio 1/25, output 60/72 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/25 | Output Speed: 60 rpm @50Hz / 72 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G30B GGM K9G gearhead K9G30B — ratio 1/30, output 50/60 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/30 | Output Speed: 50 rpm @50Hz / 60 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G36B GGM K9G gearhead K9G36B — ratio 1/36, output 41/50 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/36 | Output Speed: 41 rpm @50Hz / 50 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G40B GGM K9G gearhead K9G40B — ratio 1/40, output 37/45 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/40 | Output Speed: 37 rpm @50Hz / 45 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G50B GGM K9G gearhead K9G50B — ratio 1/50, output 30/36 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/50 | Output Speed: 30 rpm @50Hz / 36 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G60B GGM K9G gearhead K9G60B — ratio 1/60, output 25/30 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/60 | Output Speed: 25 rpm @50Hz / 30 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G75B GGM K9G gearhead K9G75B — ratio 1/75, output 20/24 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/75 | Output Speed: 20 rpm @50Hz / 24 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G90B GGM K9G gearhead K9G90B — ratio 1/90, output 16/20 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/90 | Output Speed: 16 rpm @50Hz / 20 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G100B GGM K9G gearhead K9G100B — ratio 1/100, output 15/18 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/100 | Output Speed: 15 rpm @50Hz / 18 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G120B GGM K9G gearhead K9G120B — ratio 1/120, output 12.5/15 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/120 | Output Speed: 12.5 rpm @50Hz / 15 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G150B GGM K9G gearhead K9G150B — ratio 1/150, output 10/12 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/150 | Output Speed: 10 rpm @50Hz / 12 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G180B GGM K9G gearhead K9G180B — ratio 1/180, output 8.3/10 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm @50Hz / 10 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G200B GGM K9G gearhead K9G200B — ratio 1/200, output 7.5/9 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/200 | Output Speed: 7.5 rpm @50Hz / 9 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G10BX GGM K9G decimal gearhead K9G10BX — 1/10 sub-ratio, □90mm | Type: Decimal Gearhead | Gear Ratio: 1/10 (sub-ratio) | Max Permissible Torque: 10 N·m / 100 kgf·cm | Note: Installed between motor and gearhead for ratios finer than 1/3
GearheadsGGM
25 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM K9G Gearhead for □90 40W Geared Motors (□90mm, 1/3–1/200 + Decimal, Cap 10 N·m, ø12 Keyed Shaft)

Brand GGM·Gearheads

Available part numbers (25)

K9G3B, K9G3.6B, K9G5B, K9G6B, K9G7.5B, K9G9B, K9G10B, K9G12.5B, K9G15B, K9G18B + 15 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
K9G3BGGM K9G gearhead K9G3B — ratio 1/3, output 500/600 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/3 | Output Speed: 500 rpm @50Hz / 600 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G3.6BGGM K9G gearhead K9G3.6B — ratio 1/3.6, output 416/500 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm @50Hz / 500 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G5BGGM K9G gearhead K9G5B — ratio 1/5, output 300/360 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/5 | Output Speed: 300 rpm @50Hz / 360 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G6BGGM K9G gearhead K9G6B — ratio 1/6, output 250/300 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/6 | Output Speed: 250 rpm @50Hz / 300 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G7.5BGGM K9G gearhead K9G7.5B — ratio 1/7.5, output 200/240 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm @50Hz / 240 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G9BGGM K9G gearhead K9G9B — ratio 1/9, output 166/200 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/9 | Output Speed: 166 rpm @50Hz / 200 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G10BGGM K9G gearhead K9G10B — ratio 1/10, output 150/180 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/10 | Output Speed: 150 rpm @50Hz / 180 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G12.5BGGM K9G gearhead K9G12.5B — ratio 1/12.5, output 120/144 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm @50Hz / 144 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G15BGGM K9G gearhead K9G15B — ratio 1/15, output 100/120 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/15 | Output Speed: 100 rpm @50Hz / 120 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G18BGGM K9G gearhead K9G18B — ratio 1/18, output 83/100 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/18 | Output Speed: 83 rpm @50Hz / 100 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G20BGGM K9G gearhead K9G20B — ratio 1/20, output 75/90 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/20 | Output Speed: 75 rpm @50Hz / 90 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G25BGGM K9G gearhead K9G25B — ratio 1/25, output 60/72 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/25 | Output Speed: 60 rpm @50Hz / 72 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G30BGGM K9G gearhead K9G30B — ratio 1/30, output 50/60 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/30 | Output Speed: 50 rpm @50Hz / 60 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G36BGGM K9G gearhead K9G36B — ratio 1/36, output 41/50 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/36 | Output Speed: 41 rpm @50Hz / 50 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G40BGGM K9G gearhead K9G40B — ratio 1/40, output 37/45 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/40 | Output Speed: 37 rpm @50Hz / 45 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G50BGGM K9G gearhead K9G50B — ratio 1/50, output 30/36 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/50 | Output Speed: 30 rpm @50Hz / 36 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G60BGGM K9G gearhead K9G60B — ratio 1/60, output 25/30 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/60 | Output Speed: 25 rpm @50Hz / 30 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G75BGGM K9G gearhead K9G75B — ratio 1/75, output 20/24 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/75 | Output Speed: 20 rpm @50Hz / 24 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G90BGGM K9G gearhead K9G90B — ratio 1/90, output 16/20 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/90 | Output Speed: 16 rpm @50Hz / 20 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G100BGGM K9G gearhead K9G100B — ratio 1/100, output 15/18 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/100 | Output Speed: 15 rpm @50Hz / 18 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G120BGGM K9G gearhead K9G120B — ratio 1/120, output 12.5/15 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/120 | Output Speed: 12.5 rpm @50Hz / 15 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G150BGGM K9G gearhead K9G150B — ratio 1/150, output 10/12 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/150 | Output Speed: 10 rpm @50Hz / 12 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G180BGGM K9G gearhead K9G180B — ratio 1/180, output 8.3/10 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm @50Hz / 10 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G200BGGM K9G gearhead K9G200B — ratio 1/200, output 7.5/9 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft) | Gear Ratio: 1/200 | Output Speed: 7.5 rpm @50Hz / 9 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 10 N·m / 100 kgf·cm
K9G10BXGGM K9G decimal gearhead K9G10BX — 1/10 sub-ratio, □90mm | Type: Decimal Gearhead | Gear Ratio: 1/10 (sub-ratio) | Max Permissible Torque: 10 N·m / 100 kgf·cm | Note: Installed between motor and gearhead for ratios finer than 1/3
