• GGM K9P□BF Gearhead for □90 60–200W Geared Motors (□90mm, 1/3–1/200, 130mm Output Flange, Cap 20 N·m, ø15 Keyed Shaft)
1 1

GGM K9P□BF Gearhead for □90 60–200W Geared Motors (□90mm, 1/3–1/200, 130mm Output Flange, Cap 20 N·m, ø15 Keyed Shaft)

GGM K9P□BF Gearhead for □90 60–200W Geared Motors (□90mm, 1/3–1/200, 130mm Output Flange, Cap 20 N·m, ø15 Keyed Shaft)

GGM K9P-BF parallel-shaft gearhead for □90mm 60–200W GGM geared motors, sold separately.

Key features

  • Same internals as K9P-B with a 130mm output flange (110±0.5, 4-ø8.5 holes + 4-M6 tap). 24 gear ratios 1/3–1/200, ø15 (h7) keyed output shaft, max permissible torque 20 N·m / 200 kgf·cm
  • Shares decimal gearhead K9P10BX

Specifications

Type Gearhead (Parallel Shaft, 130mm Output Flange)
Max Permissible Torque 20 N·m / 200 kgf·cm
K9P3BF GGM K9P gearhead K9P3BF (flange) — ratio 1/3, output 500/600 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/3 | Output Speed: 500 rpm @50Hz / 600 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P3.6BF GGM K9P gearhead K9P3.6BF (flange) — ratio 1/3.6, output 416/500 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm @50Hz / 500 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P5BF GGM K9P gearhead K9P5BF (flange) — ratio 1/5, output 300/360 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/5 | Output Speed: 300 rpm @50Hz / 360 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P6BF GGM K9P gearhead K9P6BF (flange) — ratio 1/6, output 250/300 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/6 | Output Speed: 250 rpm @50Hz / 300 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P7.5BF GGM K9P gearhead K9P7.5BF (flange) — ratio 1/7.5, output 200/240 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm @50Hz / 240 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P9BF GGM K9P gearhead K9P9BF (flange) — ratio 1/9, output 166/200 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/9 | Output Speed: 166 rpm @50Hz / 200 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P10BF GGM K9P gearhead K9P10BF (flange) — ratio 1/10, output 150/180 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/10 | Output Speed: 150 rpm @50Hz / 180 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P12.5BF GGM K9P gearhead K9P12.5BF (flange) — ratio 1/12.5, output 120/144 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm @50Hz / 144 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P15BF GGM K9P gearhead K9P15BF (flange) — ratio 1/15, output 100/120 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/15 | Output Speed: 100 rpm @50Hz / 120 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P18BF GGM K9P gearhead K9P18BF (flange) — ratio 1/18, output 83/100 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/18 | Output Speed: 83 rpm @50Hz / 100 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P20BF GGM K9P gearhead K9P20BF (flange) — ratio 1/20, output 75/90 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/20 | Output Speed: 75 rpm @50Hz / 90 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P25BF GGM K9P gearhead K9P25BF (flange) — ratio 1/25, output 60/72 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/25 | Output Speed: 60 rpm @50Hz / 72 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P30BF GGM K9P gearhead K9P30BF (flange) — ratio 1/30, output 50/60 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/30 | Output Speed: 50 rpm @50Hz / 60 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P36BF GGM K9P gearhead K9P36BF (flange) — ratio 1/36, output 41/50 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/36 | Output Speed: 41 rpm @50Hz / 50 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P40BF GGM K9P gearhead K9P40BF (flange) — ratio 1/40, output 37/45 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/40 | Output Speed: 37 rpm @50Hz / 45 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P50BF GGM K9P gearhead K9P50BF (flange) — ratio 1/50, output 30/36 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/50 | Output Speed: 30 rpm @50Hz / 36 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P60BF GGM K9P gearhead K9P60BF (flange) — ratio 1/60, output 25/30 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/60 | Output Speed: 25 rpm @50Hz / 30 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P75BF GGM K9P gearhead K9P75BF (flange) — ratio 1/75, output 20/24 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/75 | Output Speed: 20 rpm @50Hz / 24 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P90BF GGM K9P gearhead K9P90BF (flange) — ratio 1/90, output 16/20 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/90 | Output Speed: 16 rpm @50Hz / 20 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P100BF GGM K9P gearhead K9P100BF (flange) — ratio 1/100, output 15/18 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/100 | Output Speed: 15 rpm @50Hz / 18 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P120BF GGM K9P gearhead K9P120BF (flange) — ratio 1/120, output 12.5/15 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/120 | Output Speed: 12.5 rpm @50Hz / 15 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P150BF GGM K9P gearhead K9P150BF (flange) — ratio 1/150, output 10/12 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/150 | Output Speed: 10 rpm @50Hz / 12 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P180BF GGM K9P gearhead K9P180BF (flange) — ratio 1/180, output 8.3/10 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm @50Hz / 10 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P200BF GGM K9P gearhead K9P200BF (flange) — ratio 1/200, output 7.5/9 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/200 | Output Speed: 7.5 rpm @50Hz / 9 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
GearheadsGGM
24 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM K9P□BF Gearhead for □90 60–200W Geared Motors (□90mm, 1/3–1/200, 130mm Output Flange, Cap 20 N·m, ø15 Keyed Shaft)

Brand GGM·Gearheads

Available part numbers (24)

K9P3BF, K9P3.6BF, K9P5BF, K9P6BF, K9P7.5BF, K9P9BF, K9P10BF, K9P12.5BF, K9P15BF, K9P18BF + 14 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
K9P3BFGGM K9P gearhead K9P3BF (flange) — ratio 1/3, output 500/600 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/3 | Output Speed: 500 rpm @50Hz / 600 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P3.6BFGGM K9P gearhead K9P3.6BF (flange) — ratio 1/3.6, output 416/500 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/3.6 | Output Speed: 416 rpm @50Hz / 500 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P5BFGGM K9P gearhead K9P5BF (flange) — ratio 1/5, output 300/360 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/5 | Output Speed: 300 rpm @50Hz / 360 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P6BFGGM K9P gearhead K9P6BF (flange) — ratio 1/6, output 250/300 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/6 | Output Speed: 250 rpm @50Hz / 300 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P7.5BFGGM K9P gearhead K9P7.5BF (flange) — ratio 1/7.5, output 200/240 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/7.5 | Output Speed: 200 rpm @50Hz / 240 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P9BFGGM K9P gearhead K9P9BF (flange) — ratio 1/9, output 166/200 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/9 | Output Speed: 166 rpm @50Hz / 200 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P10BFGGM K9P gearhead K9P10BF (flange) — ratio 1/10, output 150/180 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/10 | Output Speed: 150 rpm @50Hz / 180 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P12.5BFGGM K9P gearhead K9P12.5BF (flange) — ratio 1/12.5, output 120/144 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/12.5 | Output Speed: 120 rpm @50Hz / 144 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P15BFGGM K9P gearhead K9P15BF (flange) — ratio 1/15, output 100/120 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/15 | Output Speed: 100 rpm @50Hz / 120 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P18BFGGM K9P gearhead K9P18BF (flange) — ratio 1/18, output 83/100 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/18 | Output Speed: 83 rpm @50Hz / 100 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P20BFGGM K9P gearhead K9P20BF (flange) — ratio 1/20, output 75/90 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/20 | Output Speed: 75 rpm @50Hz / 90 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P25BFGGM K9P gearhead K9P25BF (flange) — ratio 1/25, output 60/72 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/25 | Output Speed: 60 rpm @50Hz / 72 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P30BFGGM K9P gearhead K9P30BF (flange) — ratio 1/30, output 50/60 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/30 | Output Speed: 50 rpm @50Hz / 60 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P36BFGGM K9P gearhead K9P36BF (flange) — ratio 1/36, output 41/50 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/36 | Output Speed: 41 rpm @50Hz / 50 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P40BFGGM K9P gearhead K9P40BF (flange) — ratio 1/40, output 37/45 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/40 | Output Speed: 37 rpm @50Hz / 45 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P50BFGGM K9P gearhead K9P50BF (flange) — ratio 1/50, output 30/36 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/50 | Output Speed: 30 rpm @50Hz / 36 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P60BFGGM K9P gearhead K9P60BF (flange) — ratio 1/60, output 25/30 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/60 | Output Speed: 25 rpm @50Hz / 30 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P75BFGGM K9P gearhead K9P75BF (flange) — ratio 1/75, output 20/24 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/75 | Output Speed: 20 rpm @50Hz / 24 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P90BFGGM K9P gearhead K9P90BF (flange) — ratio 1/90, output 16/20 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/90 | Output Speed: 16 rpm @50Hz / 20 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P100BFGGM K9P gearhead K9P100BF (flange) — ratio 1/100, output 15/18 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/100 | Output Speed: 15 rpm @50Hz / 18 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P120BFGGM K9P gearhead K9P120BF (flange) — ratio 1/120, output 12.5/15 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/120 | Output Speed: 12.5 rpm @50Hz / 15 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P150BFGGM K9P gearhead K9P150BF (flange) — ratio 1/150, output 10/12 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/150 | Output Speed: 10 rpm @50Hz / 12 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P180BFGGM K9P gearhead K9P180BF (flange) — ratio 1/180, output 8.3/10 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/180 | Output Speed: 8.3 rpm @50Hz / 10 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
K9P200BFGGM K9P gearhead K9P200BF (flange) — ratio 1/200, output 7.5/9 rpm (50/60Hz), □90mm | Type: Gearhead (Parallel Shaft, 130mm Output Flange) | Gear Ratio: 1/200 | Output Speed: 7.5 rpm @50Hz / 9 rpm @60Hz (4-pole AC input) | Max Permissible Torque: 20 N·m / 200 kgf·cm
