GGM KA61 Fan-Type Shaded-Pole Motor (□60, 5-min Rated)

GGM KA61 Fan-Type Shaded-Pole Motor (□60, 5-min Rated)

GGM KA61 fan-type shaded-pole AC motor, □60 frame with 20–50mm stator. 5-min Rated-duty, 4–20.9W output, single-phase 100/110V & 220V, 50/60Hz.

Specifications

Type Fan (5-min rated)
Rated speed 2400/2900 rpm
KA6120FU GGM KA6120FU shaded-pole motor, fan type, 20mm stator, single-phase AC 100V/50Hz, 110V/60Hz | Type: Fan (5-min rated) | Stator: 20mm | Voltage: 100V/50Hz, 110V/60Hz | Output: 4.1W/4W (50/60Hz) | Rated torque: 166/135 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 158/119 gf·cm
KA6130FU GGM KA6130FU shaded-pole motor, fan type, 30mm stator, single-phase AC 100V/50Hz, 110V/60Hz | Type: Fan (5-min rated) | Stator: 30mm | Voltage: 100V/50Hz, 110V/60Hz | Output: 9.3W/10.1W (50/60Hz) | Rated torque: 373/337 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 310/257 gf·cm
KA6140FU GGM KA6140FU shaded-pole motor, fan type, 40mm stator, single-phase AC 100V/50Hz, 110V/60Hz | Type: Fan (5-min rated) | Stator: 40mm | Voltage: 100V/50Hz, 110V/60Hz | Output: 13.2W/15.3W (50/60Hz) | Rated torque: 533/512 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 363/302 gf·cm
KA6150FU GGM KA6150FU shaded-pole motor, fan type, 50mm stator, single-phase AC 100V/50Hz, 110V/60Hz | Type: Fan (5-min rated) | Stator: 50mm | Voltage: 100V/50Hz, 110V/60Hz | Output: 20.1W/20.6W (50/60Hz) | Rated torque: 808/685 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 653/539 gf·cm
KA6120FE GGM KA6120FE shaded-pole motor, fan type, 20mm stator, single-phase AC 220V 50/60Hz | Type: Fan (5-min rated) | Stator: 20mm | Voltage: 220V 50/60Hz | Output: 4W/3.9W (50/60Hz) | Rated torque: 162/132 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 159/113 gf·cm
KA6130FE GGM KA6130FE shaded-pole motor, fan type, 30mm stator, single-phase AC 220V 50/60Hz | Type: Fan (5-min rated) | Stator: 30mm | Voltage: 220V 50/60Hz | Output: 9.5W/10.1W (50/60Hz) | Rated torque: 376/338 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 329/251 gf·cm
KA6140FE GGM KA6140FE shaded-pole motor, fan type, 40mm stator, single-phase AC 220V 50/60Hz | Type: Fan (5-min rated) | Stator: 40mm | Voltage: 220V 50/60Hz | Output: 13.6W/15.3W (50/60Hz) | Rated torque: 548/513 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 363/315 gf·cm
KA6150FE GGM KA6150FE shaded-pole motor, fan type, 50mm stator, single-phase AC 220V 50/60Hz | Type: Fan (5-min rated) | Stator: 50mm | Voltage: 220V 50/60Hz | Output: 20.9W/20.4W (50/60Hz) | Rated torque: 881/685 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 669/457 gf·cm
Shaded-Pole MotorsGGM
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KA61 Fan-Type Shaded-Pole Motor (□60, 5-min Rated)

Brand GGM·Shaded-Pole Motors

Available part numbers (8)

KA6120FU, KA6130FU, KA6140FU, KA6150FU, KA6120FE, KA6130FE, KA6140FE, KA6150FE

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KA6120FUGGM KA6120FU shaded-pole motor, fan type, 20mm stator, single-phase AC 100V/50Hz, 110V/60Hz | Type: Fan (5-min rated) | Stator: 20mm | Voltage: 100V/50Hz, 110V/60Hz | Output: 4.1W/4W (50/60Hz) | Rated torque: 166/135 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 158/119 gf·cm
KA6130FUGGM KA6130FU shaded-pole motor, fan type, 30mm stator, single-phase AC 100V/50Hz, 110V/60Hz | Type: Fan (5-min rated) | Stator: 30mm | Voltage: 100V/50Hz, 110V/60Hz | Output: 9.3W/10.1W (50/60Hz) | Rated torque: 373/337 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 310/257 gf·cm
KA6140FUGGM KA6140FU shaded-pole motor, fan type, 40mm stator, single-phase AC 100V/50Hz, 110V/60Hz | Type: Fan (5-min rated) | Stator: 40mm | Voltage: 100V/50Hz, 110V/60Hz | Output: 13.2W/15.3W (50/60Hz) | Rated torque: 533/512 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 363/302 gf·cm
KA6150FUGGM KA6150FU shaded-pole motor, fan type, 50mm stator, single-phase AC 100V/50Hz, 110V/60Hz | Type: Fan (5-min rated) | Stator: 50mm | Voltage: 100V/50Hz, 110V/60Hz | Output: 20.1W/20.6W (50/60Hz) | Rated torque: 808/685 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 653/539 gf·cm
KA6120FEGGM KA6120FE shaded-pole motor, fan type, 20mm stator, single-phase AC 220V 50/60Hz | Type: Fan (5-min rated) | Stator: 20mm | Voltage: 220V 50/60Hz | Output: 4W/3.9W (50/60Hz) | Rated torque: 162/132 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 159/113 gf·cm
KA6130FEGGM KA6130FE shaded-pole motor, fan type, 30mm stator, single-phase AC 220V 50/60Hz | Type: Fan (5-min rated) | Stator: 30mm | Voltage: 220V 50/60Hz | Output: 9.5W/10.1W (50/60Hz) | Rated torque: 376/338 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 329/251 gf·cm
KA6140FEGGM KA6140FE shaded-pole motor, fan type, 40mm stator, single-phase AC 220V 50/60Hz | Type: Fan (5-min rated) | Stator: 40mm | Voltage: 220V 50/60Hz | Output: 13.6W/15.3W (50/60Hz) | Rated torque: 548/513 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 363/315 gf·cm
KA6150FEGGM KA6150FE shaded-pole motor, fan type, 50mm stator, single-phase AC 220V 50/60Hz | Type: Fan (5-min rated) | Stator: 50mm | Voltage: 220V 50/60Hz | Output: 20.9W/20.4W (50/60Hz) | Rated torque: 881/685 gf·cm | Rated speed: 2400/2900 rpm | Start torque: 669/457 gf·cm
