GGM KD3429-E Series DC Motor with Encoder (ø34mm, 12/24V)

GGM KD3429-E Series DC Motor with Encoder (ø34mm, 12/24V)

GGM KD3429 brushed DC motor, ø34mm can, ø3mm shaft, 2-M3 face mount; S/T/P speed grades (12V/24V); body 51.5mm, 90g.

Key features

  • Built-in 20-pole/10-pulse incremental encoder, 6-pin connector (open-collector, Vcc DC 5-24V)

Specifications

Frame ø34mm can
Output Shaft ø3mm, 2-M3 face mount
Type DC motor with incremental encoder
KD3429S1-E GGM KD3429S1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 5200 rpm, max-eff 4500 rpm / 40 gf·cm. | Model: KD3429S1-E | Voltage: DC 12V | No-load Speed: 5200 rpm | Rated Speed (max eff.): 4500 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.3 A | Stall Torque: 360 gf·cm | Stall Current: 1.7 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429S2-E GGM KD3429S2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 5200 rpm, max-eff 4500 rpm / 40 gf·cm. | Model: KD3429S2-E | Voltage: DC 24V | No-load Speed: 5200 rpm | Rated Speed (max eff.): 4500 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.2 A | Stall Torque: 370 gf·cm | Stall Current: 1 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429T1-E GGM KD3429T1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 7500 rpm, max-eff 6500 rpm / 40 gf·cm. | Model: KD3429T1-E | Voltage: DC 12V | No-load Speed: 7500 rpm | Rated Speed (max eff.): 6500 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.5 A | Stall Torque: 420 gf·cm | Stall Current: 3.8 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429T2-E GGM KD3429T2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 7500 rpm, max-eff 6500 rpm / 40 gf·cm. | Model: KD3429T2-E | Voltage: DC 24V | No-load Speed: 7500 rpm | Rated Speed (max eff.): 6500 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.2 A | Stall Torque: 320 gf·cm | Stall Current: 1.2 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429P1-E GGM KD3429P1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 9500 rpm, max-eff 8000 rpm / 80 gf·cm. | Model: KD3429P1-E | Voltage: DC 12V | No-load Speed: 9500 rpm | Rated Speed (max eff.): 8000 rpm | Rated Torque (max eff.): 80 gf·cm | Rated Current (max eff.): 1 A | Stall Torque: 330 gf·cm | Stall Current: 3.8 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429P2-E GGM KD3429P2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 9500 rpm, max-eff 8000 rpm / 40 gf·cm. | Model: KD3429P2-E | Voltage: DC 24V | No-load Speed: 9500 rpm | Rated Speed (max eff.): 8000 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.3 A | Stall Torque: 350 gf·cm | Stall Current: 2 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
DCGGM
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KD3429-E Series DC Motor with Encoder (ø34mm, 12/24V)

Brand GGM·DC

Available part numbers (6)

KD3429S1-E, KD3429S2-E, KD3429T1-E, KD3429T2-E, KD3429P1-E, KD3429P2-E

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KD3429S1-EGGM KD3429S1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 5200 rpm, max-eff 4500 rpm / 40 gf·cm. | Model: KD3429S1-E | Voltage: DC 12V | No-load Speed: 5200 rpm | Rated Speed (max eff.): 4500 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.3 A | Stall Torque: 360 gf·cm | Stall Current: 1.7 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429S2-EGGM KD3429S2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 5200 rpm, max-eff 4500 rpm / 40 gf·cm. | Model: KD3429S2-E | Voltage: DC 24V | No-load Speed: 5200 rpm | Rated Speed (max eff.): 4500 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.2 A | Stall Torque: 370 gf·cm | Stall Current: 1 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429T1-EGGM KD3429T1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 7500 rpm, max-eff 6500 rpm / 40 gf·cm. | Model: KD3429T1-E | Voltage: DC 12V | No-load Speed: 7500 rpm | Rated Speed (max eff.): 6500 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.5 A | Stall Torque: 420 gf·cm | Stall Current: 3.8 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429T2-EGGM KD3429T2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 7500 rpm, max-eff 6500 rpm / 40 gf·cm. | Model: KD3429T2-E | Voltage: DC 24V | No-load Speed: 7500 rpm | Rated Speed (max eff.): 6500 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.2 A | Stall Torque: 320 gf·cm | Stall Current: 1.2 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429P1-EGGM KD3429P1-E DC 12V brushed DC motor with 20-pole/10-pulse encoder, no-load 9500 rpm, max-eff 8000 rpm / 80 gf·cm. | Model: KD3429P1-E | Voltage: DC 12V | No-load Speed: 9500 rpm | Rated Speed (max eff.): 8000 rpm | Rated Torque (max eff.): 80 gf·cm | Rated Current (max eff.): 1 A | Stall Torque: 330 gf·cm | Stall Current: 3.8 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
KD3429P2-EGGM KD3429P2-E DC 24V brushed DC motor with 20-pole/10-pulse encoder, no-load 9500 rpm, max-eff 8000 rpm / 40 gf·cm. | Model: KD3429P2-E | Voltage: DC 24V | No-load Speed: 9500 rpm | Rated Speed (max eff.): 8000 rpm | Rated Torque (max eff.): 40 gf·cm | Rated Current (max eff.): 0.3 A | Stall Torque: 350 gf·cm | Stall Current: 2 A | Frame: ø34mm can | Output Shaft: ø3mm, 2-M3 face mount | Type: DC motor with incremental encoder
