GGM KG5-3429 Geared Motor, KD3429P2 (DC 24V, 35 ratios 1/3–1/3240, ø50 inline)

GGM KG5-3429 Geared Motor, KD3429P2 (DC 24V, 35 ratios 1/3–1/3240, ø50 inline)

GGM KG5-3429 DC geared motor with KD3429P2 brushed motor (DC 24V, no-load 9500 rpm). 35 reduction ratios 1/3–1/3240, ø50 round flange with ø6 coaxial output shaft, output torque up to 10 kgf·cm.

KG5-0003-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/3 | Gear Ratio: 1/3 | Output Speed: 2667 rpm | Output Torque: 0.1 kgf·cm | Gearhead Length: 34 mm
KG5-0005-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/5 | Gear Ratio: 1/5 | Output Speed: 1600 rpm | Output Torque: 0.16 kgf·cm | Gearhead Length: 34 mm
KG5-0010-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/10 | Gear Ratio: 1/10 | Output Speed: 800 rpm | Output Torque: 0.3 kgf·cm | Gearhead Length: 34 mm
KG5-0015-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/15 | Gear Ratio: 1/15 | Output Speed: 533 rpm | Output Torque: 0.44 kgf·cm | Gearhead Length: 34 mm
KG5-0020-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/20 | Gear Ratio: 1/20 | Output Speed: 400 rpm | Output Torque: 0.58 kgf·cm | Gearhead Length: 34 mm
KG5-0025-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/25 | Gear Ratio: 1/25 | Output Speed: 320 rpm | Output Torque: 0.73 kgf·cm | Gearhead Length: 34 mm
KG5-0030-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/30 | Gear Ratio: 1/30 | Output Speed: 267 rpm | Output Torque: 0.87 kgf·cm | Gearhead Length: 34 mm
KG5-0040-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/40 | Gear Ratio: 1/40 | Output Speed: 200 rpm | Output Torque: 1.2 kgf·cm | Gearhead Length: 34 mm
KG5-0050-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/50 | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 1.3 kgf·cm | Gearhead Length: 34 mm
KG5-0060-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/60 | Gear Ratio: 1/60 | Output Speed: 133 rpm | Output Torque: 1.6 kgf·cm | Gearhead Length: 34 mm
KG5-0075-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/75 | Gear Ratio: 1/75 | Output Speed: 107 rpm | Output Torque: 2 kgf·cm | Gearhead Length: 34 mm
KG5-0090-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/90 | Gear Ratio: 1/90 | Output Speed: 88.9 rpm | Output Torque: 2.4 kgf·cm | Gearhead Length: 34 mm
KG5-0100-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/100 | Gear Ratio: 1/100 | Output Speed: 80 rpm | Output Torque: 2.6 kgf·cm | Gearhead Length: 34 mm
KG5-0120-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/120 | Gear Ratio: 1/120 | Output Speed: 66.7 rpm | Output Torque: 3.1 kgf·cm | Gearhead Length: 34 mm
KG5-0150-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/150 | Gear Ratio: 1/150 | Output Speed: 53.3 rpm | Output Torque: 3.5 kgf·cm | Gearhead Length: 46 mm
KG5-0160-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/160 | Gear Ratio: 1/160 | Output Speed: 50 rpm | Output Torque: 3.8 kgf·cm | Gearhead Length: 46 mm
KG5-0180-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/180 | Gear Ratio: 1/180 | Output Speed: 44.4 rpm | Output Torque: 4.2 kgf·cm | Gearhead Length: 46 mm
KG5-0200-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/200 | Gear Ratio: 1/200 | Output Speed: 40 rpm | Output Torque: 4.7 kgf·cm | Gearhead Length: 46 mm
KG5-0210-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/210 | Gear Ratio: 1/210 | Output Speed: 38.1 rpm | Output Torque: 5 kgf·cm | Gearhead Length: 46 mm
KG5-0240-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/240 | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 5.7 kgf·cm | Gearhead Length: 46 mm
KG5-0270-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/270 | Gear Ratio: 1/270 | Output Speed: 29.6 rpm | Output Torque: 6.4 kgf·cm | Gearhead Length: 46 mm
KG5-0300-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/300 | Gear Ratio: 1/300 | Output Speed: 26.7 rpm | Output Torque: 7.1 kgf·cm | Gearhead Length: 46 mm
KG5-0360-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/360 | Gear Ratio: 1/360 | Output Speed: 22.2 rpm | Output Torque: 8.5 kgf·cm | Gearhead Length: 46 mm
KG5-0400-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/400 | Gear Ratio: 1/400 | Output Speed: 20 rpm | Output Torque: 8.5 kgf·cm | Gearhead Length: 46 mm
KG5-0500-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/500 | Gear Ratio: 1/500 | Output Speed: 16 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-0600-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/600 | Gear Ratio: 1/600 | Output Speed: 13.3 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-0750-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/750 | Gear Ratio: 1/750 | Output Speed: 10.7 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-0900-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/900 | Gear Ratio: 1/900 | Output Speed: 8.9 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-1080-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/1080 | Gear Ratio: 1/1080 | Output Speed: 7.4 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-1250-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/1250 | Gear Ratio: 1/1250 | Output Speed: 6.4 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-1500-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/1500 | Gear Ratio: 1/1500 | Output Speed: 5.3 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-1800-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/1800 | Gear Ratio: 1/1800 | Output Speed: 4.4 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-2250-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/2250 | Gear Ratio: 1/2250 | Output Speed: 3.6 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-2700-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/2700 | Gear Ratio: 1/2700 | Output Speed: 3 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-3240-KD3429P2 KG5-3429 KD3429P2 geared motor, 1/3240 | Gear Ratio: 1/3240 | Output Speed: 2.5 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
DCGGM
35 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KG5-3429 Geared Motor, KD3429P2 (DC 24V, 35 ratios 1/3–1/3240, ø50 inline)

Brand GGM·DC

Available part numbers (35)

KG5-0003-KD3429P2, KG5-0005-KD3429P2, KG5-0010-KD3429P2, KG5-0015-KD3429P2, KG5-0020-KD3429P2, KG5-0025-KD3429P2, KG5-0030-KD3429P2, KG5-0040-KD3429P2, KG5-0050-KD3429P2, KG5-0060-KD3429P2 + 25 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KG5-0003-KD3429P2KG5-3429 KD3429P2 geared motor, 1/3 | Gear Ratio: 1/3 | Output Speed: 2667 rpm | Output Torque: 0.1 kgf·cm | Gearhead Length: 34 mm
KG5-0005-KD3429P2KG5-3429 KD3429P2 geared motor, 1/5 | Gear Ratio: 1/5 | Output Speed: 1600 rpm | Output Torque: 0.16 kgf·cm | Gearhead Length: 34 mm
KG5-0010-KD3429P2KG5-3429 KD3429P2 geared motor, 1/10 | Gear Ratio: 1/10 | Output Speed: 800 rpm | Output Torque: 0.3 kgf·cm | Gearhead Length: 34 mm
KG5-0015-KD3429P2KG5-3429 KD3429P2 geared motor, 1/15 | Gear Ratio: 1/15 | Output Speed: 533 rpm | Output Torque: 0.44 kgf·cm | Gearhead Length: 34 mm
KG5-0020-KD3429P2KG5-3429 KD3429P2 geared motor, 1/20 | Gear Ratio: 1/20 | Output Speed: 400 rpm | Output Torque: 0.58 kgf·cm | Gearhead Length: 34 mm
KG5-0025-KD3429P2KG5-3429 KD3429P2 geared motor, 1/25 | Gear Ratio: 1/25 | Output Speed: 320 rpm | Output Torque: 0.73 kgf·cm | Gearhead Length: 34 mm
KG5-0030-KD3429P2KG5-3429 KD3429P2 geared motor, 1/30 | Gear Ratio: 1/30 | Output Speed: 267 rpm | Output Torque: 0.87 kgf·cm | Gearhead Length: 34 mm
KG5-0040-KD3429P2KG5-3429 KD3429P2 geared motor, 1/40 | Gear Ratio: 1/40 | Output Speed: 200 rpm | Output Torque: 1.2 kgf·cm | Gearhead Length: 34 mm
KG5-0050-KD3429P2KG5-3429 KD3429P2 geared motor, 1/50 | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 1.3 kgf·cm | Gearhead Length: 34 mm
KG5-0060-KD3429P2KG5-3429 KD3429P2 geared motor, 1/60 | Gear Ratio: 1/60 | Output Speed: 133 rpm | Output Torque: 1.6 kgf·cm | Gearhead Length: 34 mm
KG5-0075-KD3429P2KG5-3429 KD3429P2 geared motor, 1/75 | Gear Ratio: 1/75 | Output Speed: 107 rpm | Output Torque: 2 kgf·cm | Gearhead Length: 34 mm
KG5-0090-KD3429P2KG5-3429 KD3429P2 geared motor, 1/90 | Gear Ratio: 1/90 | Output Speed: 88.9 rpm | Output Torque: 2.4 kgf·cm | Gearhead Length: 34 mm
KG5-0100-KD3429P2KG5-3429 KD3429P2 geared motor, 1/100 | Gear Ratio: 1/100 | Output Speed: 80 rpm | Output Torque: 2.6 kgf·cm | Gearhead Length: 34 mm
KG5-0120-KD3429P2KG5-3429 KD3429P2 geared motor, 1/120 | Gear Ratio: 1/120 | Output Speed: 66.7 rpm | Output Torque: 3.1 kgf·cm | Gearhead Length: 34 mm
KG5-0150-KD3429P2KG5-3429 KD3429P2 geared motor, 1/150 | Gear Ratio: 1/150 | Output Speed: 53.3 rpm | Output Torque: 3.5 kgf·cm | Gearhead Length: 46 mm
KG5-0160-KD3429P2KG5-3429 KD3429P2 geared motor, 1/160 | Gear Ratio: 1/160 | Output Speed: 50 rpm | Output Torque: 3.8 kgf·cm | Gearhead Length: 46 mm
KG5-0180-KD3429P2KG5-3429 KD3429P2 geared motor, 1/180 | Gear Ratio: 1/180 | Output Speed: 44.4 rpm | Output Torque: 4.2 kgf·cm | Gearhead Length: 46 mm
KG5-0200-KD3429P2KG5-3429 KD3429P2 geared motor, 1/200 | Gear Ratio: 1/200 | Output Speed: 40 rpm | Output Torque: 4.7 kgf·cm | Gearhead Length: 46 mm
KG5-0210-KD3429P2KG5-3429 KD3429P2 geared motor, 1/210 | Gear Ratio: 1/210 | Output Speed: 38.1 rpm | Output Torque: 5 kgf·cm | Gearhead Length: 46 mm
KG5-0240-KD3429P2KG5-3429 KD3429P2 geared motor, 1/240 | Gear Ratio: 1/240 | Output Speed: 33.3 rpm | Output Torque: 5.7 kgf·cm | Gearhead Length: 46 mm
KG5-0270-KD3429P2KG5-3429 KD3429P2 geared motor, 1/270 | Gear Ratio: 1/270 | Output Speed: 29.6 rpm | Output Torque: 6.4 kgf·cm | Gearhead Length: 46 mm
KG5-0300-KD3429P2KG5-3429 KD3429P2 geared motor, 1/300 | Gear Ratio: 1/300 | Output Speed: 26.7 rpm | Output Torque: 7.1 kgf·cm | Gearhead Length: 46 mm
KG5-0360-KD3429P2KG5-3429 KD3429P2 geared motor, 1/360 | Gear Ratio: 1/360 | Output Speed: 22.2 rpm | Output Torque: 8.5 kgf·cm | Gearhead Length: 46 mm
KG5-0400-KD3429P2KG5-3429 KD3429P2 geared motor, 1/400 | Gear Ratio: 1/400 | Output Speed: 20 rpm | Output Torque: 8.5 kgf·cm | Gearhead Length: 46 mm
KG5-0500-KD3429P2KG5-3429 KD3429P2 geared motor, 1/500 | Gear Ratio: 1/500 | Output Speed: 16 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-0600-KD3429P2KG5-3429 KD3429P2 geared motor, 1/600 | Gear Ratio: 1/600 | Output Speed: 13.3 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-0750-KD3429P2KG5-3429 KD3429P2 geared motor, 1/750 | Gear Ratio: 1/750 | Output Speed: 10.7 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-0900-KD3429P2KG5-3429 KD3429P2 geared motor, 1/900 | Gear Ratio: 1/900 | Output Speed: 8.9 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-1080-KD3429P2KG5-3429 KD3429P2 geared motor, 1/1080 | Gear Ratio: 1/1080 | Output Speed: 7.4 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-1250-KD3429P2KG5-3429 KD3429P2 geared motor, 1/1250 | Gear Ratio: 1/1250 | Output Speed: 6.4 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-1500-KD3429P2KG5-3429 KD3429P2 geared motor, 1/1500 | Gear Ratio: 1/1500 | Output Speed: 5.3 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-1800-KD3429P2KG5-3429 KD3429P2 geared motor, 1/1800 | Gear Ratio: 1/1800 | Output Speed: 4.4 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-2250-KD3429P2KG5-3429 KD3429P2 geared motor, 1/2250 | Gear Ratio: 1/2250 | Output Speed: 3.6 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-2700-KD3429P2KG5-3429 KD3429P2 geared motor, 1/2700 | Gear Ratio: 1/2700 | Output Speed: 3 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
KG5-3240-KD3429P2KG5-3429 KD3429P2 geared motor, 1/3240 | Gear Ratio: 1/3240 | Output Speed: 2.5 rpm | Output Torque: 10 kgf·cm | Gearhead Length: 46 mm
