GGM KGF-3448-S2 Worm Geared DC Motor (DC 24V, 5200rpm base, 5 ratios 1/57-1/255, F/R shaft)

GGM KGF-3448-S2 Worm Geared DC Motor (DC 24V, 5200rpm base, 5 ratios 1/57-1/255, F/R shaft)

GGM KGF-3448-S2 worm geared DC motor, DC 24V (5200 rpm base motor). 5 gear ratios 1/57-1/255, output torque up to 12 kgf·cm, ø8 output shaft, 4-M4 mounting.

Key features

  • Output rotation opposite to motor
  • R-Type shaft is standard (F-Type optional)
KGF-0057-KD3448S2 KGF-3448-S2 R-Type worm geared, 1/57, 79rpm, 2.6kgf·cm | Gear Ratio: 1/57 | Output Speed: 79 rpm | Output Torque: 2.6 kgf·cm | Shaft Type: R-Type
KGF-0100-KD3448S2 KGF-3448-S2 R-Type worm geared, 1/100, 45rpm, 4.8kgf·cm | Gear Ratio: 1/100 | Output Speed: 45 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type
KGF-0130-KD3448S2 KGF-3448-S2 R-Type worm geared, 1/130, 34.6rpm, 6.2kgf·cm | Gear Ratio: 1/130 | Output Speed: 34.6 rpm | Output Torque: 6.2 kgf·cm | Shaft Type: R-Type
KGF-0188-KD3448S2 KGF-3448-S2 R-Type worm geared, 1/188, 23.9rpm, 8.8kgf·cm | Gear Ratio: 1/188 | Output Speed: 23.9 rpm | Output Torque: 8.8 kgf·cm | Shaft Type: R-Type
KGF-0255-KD3448S2 KGF-3448-S2 R-Type worm geared, 1/255, 17.6rpm, 12kgf·cm | Gear Ratio: 1/255 | Output Speed: 17.6 rpm | Output Torque: 12 kgf·cm | Shaft Type: R-Type
KGF-0057-KD3448S2-F KGF-3448-S2 F-Type worm geared, 1/57, 79rpm, 2.6kgf·cm | Gear Ratio: 1/57 | Output Speed: 79 rpm | Output Torque: 2.6 kgf·cm | Shaft Type: F-Type
KGF-0100-KD3448S2-F KGF-3448-S2 F-Type worm geared, 1/100, 45rpm, 4.8kgf·cm | Gear Ratio: 1/100 | Output Speed: 45 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type
KGF-0130-KD3448S2-F KGF-3448-S2 F-Type worm geared, 1/130, 34.6rpm, 6.2kgf·cm | Gear Ratio: 1/130 | Output Speed: 34.6 rpm | Output Torque: 6.2 kgf·cm | Shaft Type: F-Type
KGF-0188-KD3448S2-F KGF-3448-S2 F-Type worm geared, 1/188, 23.9rpm, 8.8kgf·cm | Gear Ratio: 1/188 | Output Speed: 23.9 rpm | Output Torque: 8.8 kgf·cm | Shaft Type: F-Type
KGF-0255-KD3448S2-F KGF-3448-S2 F-Type worm geared, 1/255, 17.6rpm, 12kgf·cm | Gear Ratio: 1/255 | Output Speed: 17.6 rpm | Output Torque: 12 kgf·cm | Shaft Type: F-Type
DCGGM
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KGF-3448-S2 Worm Geared DC Motor (DC 24V, 5200rpm base, 5 ratios 1/57-1/255, F/R shaft)

Brand GGM·DC

Available part numbers (10)

KGF-0057-KD3448S2, KGF-0100-KD3448S2, KGF-0130-KD3448S2, KGF-0188-KD3448S2, KGF-0255-KD3448S2, KGF-0057-KD3448S2-F, KGF-0100-KD3448S2-F, KGF-0130-KD3448S2-F, KGF-0188-KD3448S2-F, KGF-0255-KD3448S2-F

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KGF-0057-KD3448S2KGF-3448-S2 R-Type worm geared, 1/57, 79rpm, 2.6kgf·cm | Gear Ratio: 1/57 | Output Speed: 79 rpm | Output Torque: 2.6 kgf·cm | Shaft Type: R-Type
KGF-0100-KD3448S2KGF-3448-S2 R-Type worm geared, 1/100, 45rpm, 4.8kgf·cm | Gear Ratio: 1/100 | Output Speed: 45 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: R-Type
KGF-0130-KD3448S2KGF-3448-S2 R-Type worm geared, 1/130, 34.6rpm, 6.2kgf·cm | Gear Ratio: 1/130 | Output Speed: 34.6 rpm | Output Torque: 6.2 kgf·cm | Shaft Type: R-Type
KGF-0188-KD3448S2KGF-3448-S2 R-Type worm geared, 1/188, 23.9rpm, 8.8kgf·cm | Gear Ratio: 1/188 | Output Speed: 23.9 rpm | Output Torque: 8.8 kgf·cm | Shaft Type: R-Type
KGF-0255-KD3448S2KGF-3448-S2 R-Type worm geared, 1/255, 17.6rpm, 12kgf·cm | Gear Ratio: 1/255 | Output Speed: 17.6 rpm | Output Torque: 12 kgf·cm | Shaft Type: R-Type
KGF-0057-KD3448S2-FKGF-3448-S2 F-Type worm geared, 1/57, 79rpm, 2.6kgf·cm | Gear Ratio: 1/57 | Output Speed: 79 rpm | Output Torque: 2.6 kgf·cm | Shaft Type: F-Type
KGF-0100-KD3448S2-FKGF-3448-S2 F-Type worm geared, 1/100, 45rpm, 4.8kgf·cm | Gear Ratio: 1/100 | Output Speed: 45 rpm | Output Torque: 4.8 kgf·cm | Shaft Type: F-Type
KGF-0130-KD3448S2-FKGF-3448-S2 F-Type worm geared, 1/130, 34.6rpm, 6.2kgf·cm | Gear Ratio: 1/130 | Output Speed: 34.6 rpm | Output Torque: 6.2 kgf·cm | Shaft Type: F-Type
KGF-0188-KD3448S2-FKGF-3448-S2 F-Type worm geared, 1/188, 23.9rpm, 8.8kgf·cm | Gear Ratio: 1/188 | Output Speed: 23.9 rpm | Output Torque: 8.8 kgf·cm | Shaft Type: F-Type
KGF-0255-KD3448S2-FKGF-3448-S2 F-Type worm geared, 1/255, 17.6rpm, 12kgf·cm | Gear Ratio: 1/255 | Output Speed: 17.6 rpm | Output Torque: 12 kgf·cm | Shaft Type: F-Type
