GGM KGH Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/15–1/220)

GGM KGH Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/15–1/220)

GGM KGH gearhead for □60 KA61 shaded-pole general-type motors, 7 gear ratios from 1/15 to 1/220.

Key features

  • F-TYPE standard, body 64×76mm, Ø7.5 output shaft, 4-#8-32 UNC mounting
KGH-0015 KGH gearhead, 1/15, output 160/193 rpm (50/60Hz) | Gear Ratio: 1/15 | Output Speed: 160 rpm (50Hz) / 193 rpm (60Hz)
KGH-0023 KGH gearhead, 1/23, output 104/126 rpm (50/60Hz) | Gear Ratio: 1/23 | Output Speed: 104 rpm (50Hz) / 126 rpm (60Hz)
KGH-0036 KGH gearhead, 1/36, output 67/81 rpm (50/60Hz) | Gear Ratio: 1/36 | Output Speed: 67 rpm (50Hz) / 81 rpm (60Hz)
KGH-0058 KGH gearhead, 1/58, output 41/50 rpm (50/60Hz) | Gear Ratio: 1/58 | Output Speed: 41 rpm (50Hz) / 50 rpm (60Hz)
KGH-0075 KGH gearhead, 1/75, output 32/39 rpm (50/60Hz) | Gear Ratio: 1/75 | Output Speed: 32 rpm (50Hz) / 39 rpm (60Hz)
KGH-0133 KGH gearhead, 1/133, output 18/22 rpm (50/60Hz) | Gear Ratio: 1/133 | Output Speed: 18 rpm (50Hz) / 22 rpm (60Hz)
KGH-0220 KGH gearhead, 1/220, output 11/13 rpm (50/60Hz) | Gear Ratio: 1/220 | Output Speed: 11 rpm (50Hz) / 13 rpm (60Hz)
Shaded-Pole MotorsGGM
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KGH Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/15–1/220)

Brand GGM·Shaded-Pole Motors

Available part numbers (7)

KGH-0015, KGH-0023, KGH-0036, KGH-0058, KGH-0075, KGH-0133, KGH-0220

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KGH-0015KGH gearhead, 1/15, output 160/193 rpm (50/60Hz) | Gear Ratio: 1/15 | Output Speed: 160 rpm (50Hz) / 193 rpm (60Hz)
KGH-0023KGH gearhead, 1/23, output 104/126 rpm (50/60Hz) | Gear Ratio: 1/23 | Output Speed: 104 rpm (50Hz) / 126 rpm (60Hz)
KGH-0036KGH gearhead, 1/36, output 67/81 rpm (50/60Hz) | Gear Ratio: 1/36 | Output Speed: 67 rpm (50Hz) / 81 rpm (60Hz)
KGH-0058KGH gearhead, 1/58, output 41/50 rpm (50/60Hz) | Gear Ratio: 1/58 | Output Speed: 41 rpm (50Hz) / 50 rpm (60Hz)
KGH-0075KGH gearhead, 1/75, output 32/39 rpm (50/60Hz) | Gear Ratio: 1/75 | Output Speed: 32 rpm (50Hz) / 39 rpm (60Hz)
KGH-0133KGH gearhead, 1/133, output 18/22 rpm (50/60Hz) | Gear Ratio: 1/133 | Output Speed: 18 rpm (50Hz) / 22 rpm (60Hz)
KGH-0220KGH gearhead, 1/220, output 11/13 rpm (50/60Hz) | Gear Ratio: 1/220 | Output Speed: 11 rpm (50Hz) / 13 rpm (60Hz)
