GGM KGR5 Gearhead for KA61 Shaded-Pole Motors (□60, 1/124–1/192)

GGM KGR5 Gearhead for KA61 Shaded-Pole Motors (□60, 1/124–1/192)

GGM KGR5 gearhead for □60 KA61 shaded-pole general-type motors, 2 gear ratios (1/124, 1/192); output rotates opposite to motor.

Key features

  • Body 63.5×65.79mm, Ø9.5 shaft with M8 thread, 3-Ø3.6 mounting holes

Specifications

Rotation Opposite to motor
KGR5-0124 KGR5 gearhead, 1/124, output 19.3/23.3 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/124 | Output Speed: 19.3 rpm (50Hz) / 23.3 rpm (60Hz) | Rotation: Opposite to motor
KGR5-0192 KGR5 gearhead, 1/192, output 12.5/15.1 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/192 | Output Speed: 12.5 rpm (50Hz) / 15.1 rpm (60Hz) | Rotation: Opposite to motor
Shaded-Pole MotorsGGM
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KGR5 Gearhead for KA61 Shaded-Pole Motors (□60, 1/124–1/192)

Brand GGM·Shaded-Pole Motors

Available part numbers (2)

KGR5-0124, KGR5-0192

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KGR5-0124KGR5 gearhead, 1/124, output 19.3/23.3 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/124 | Output Speed: 19.3 rpm (50Hz) / 23.3 rpm (60Hz) | Rotation: Opposite to motor
KGR5-0192KGR5 gearhead, 1/192, output 12.5/15.1 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/192 | Output Speed: 12.5 rpm (50Hz) / 15.1 rpm (60Hz) | Rotation: Opposite to motor
