GGM KMF Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/150–1/3140)

GGM KMF Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/150–1/3140)

GGM KMF gearhead for □60 KA61 shaded-pole general-type motors, 13 gear ratios from 1/150 to 1/3140 with output rotating opposite to the motor.

Key features

  • Max permissible output torque 30 kgf·cm, F-TYPE standard, body 69.9×119.1mm, Ø12.7 shaft, 4-M5 mounting

Specifications

Max Permissible Output Torque 30 kgf·cm
Rotation Opposite to motor
KMF-0150 KMF gearhead, 1/150, output 16/19.3 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/150 | Output Speed: 16 rpm (50Hz) / 19.3 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0330 KMF gearhead, 1/330, output 7.3/8.8 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/330 | Output Speed: 7.3 rpm (50Hz) / 8.8 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0500 KMF gearhead, 1/500, output 4.8/5.8 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/500 | Output Speed: 4.8 rpm (50Hz) / 5.8 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0550 KMF gearhead, 1/550, output 4.4/5.3 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/550 | Output Speed: 4.4 rpm (50Hz) / 5.3 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0760 KMF gearhead, 1/760, output 3.2/3.8 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/760 | Output Speed: 3.2 rpm (50Hz) / 3.8 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0850 KMF gearhead, 1/850, output 2.8/3.4 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/850 | Output Speed: 2.8 rpm (50Hz) / 3.4 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0940 KMF gearhead, 1/940, output 2.6/3.1 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/940 | Output Speed: 2.6 rpm (50Hz) / 3.1 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-1410 KMF gearhead, 1/1410, output 1.7/2.1 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/1410 | Output Speed: 1.7 rpm (50Hz) / 2.1 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-1740 KMF gearhead, 1/1740, output 1.4/1.7 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/1740 | Output Speed: 1.4 rpm (50Hz) / 1.7 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-2250 KMF gearhead, 1/2250, output 1.1/1.3 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/2250 | Output Speed: 1.1 rpm (50Hz) / 1.3 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-2360 KMF gearhead, 1/2360, output 1/1.2 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/2360 | Output Speed: 1 rpm (50Hz) / 1.2 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-2610 KMF gearhead, 1/2610, output 0.9/1.1 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/2610 | Output Speed: 0.9 rpm (50Hz) / 1.1 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-3140 KMF gearhead, 1/3140, output 0.8/0.9 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/3140 | Output Speed: 0.8 rpm (50Hz) / 0.9 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
Shaded-Pole MotorsGGM
13 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KMF Gearhead for KA61 Shaded-Pole Motors (□60, F-Type, 1/150–1/3140)

Brand GGM·Shaded-Pole Motors

Available part numbers (13)

KMF-0150, KMF-0330, KMF-0500, KMF-0550, KMF-0760, KMF-0850, KMF-0940, KMF-1410, KMF-1740, KMF-2250 + 3 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KMF-0150KMF gearhead, 1/150, output 16/19.3 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/150 | Output Speed: 16 rpm (50Hz) / 19.3 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0330KMF gearhead, 1/330, output 7.3/8.8 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/330 | Output Speed: 7.3 rpm (50Hz) / 8.8 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0500KMF gearhead, 1/500, output 4.8/5.8 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/500 | Output Speed: 4.8 rpm (50Hz) / 5.8 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0550KMF gearhead, 1/550, output 4.4/5.3 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/550 | Output Speed: 4.4 rpm (50Hz) / 5.3 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0760KMF gearhead, 1/760, output 3.2/3.8 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/760 | Output Speed: 3.2 rpm (50Hz) / 3.8 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0850KMF gearhead, 1/850, output 2.8/3.4 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/850 | Output Speed: 2.8 rpm (50Hz) / 3.4 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-0940KMF gearhead, 1/940, output 2.6/3.1 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/940 | Output Speed: 2.6 rpm (50Hz) / 3.1 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-1410KMF gearhead, 1/1410, output 1.7/2.1 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/1410 | Output Speed: 1.7 rpm (50Hz) / 2.1 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-1740KMF gearhead, 1/1740, output 1.4/1.7 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/1740 | Output Speed: 1.4 rpm (50Hz) / 1.7 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-2250KMF gearhead, 1/2250, output 1.1/1.3 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/2250 | Output Speed: 1.1 rpm (50Hz) / 1.3 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-2360KMF gearhead, 1/2360, output 1/1.2 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/2360 | Output Speed: 1 rpm (50Hz) / 1.2 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-2610KMF gearhead, 1/2610, output 0.9/1.1 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/2610 | Output Speed: 0.9 rpm (50Hz) / 1.1 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
KMF-3140KMF gearhead, 1/3140, output 0.8/0.9 rpm (50/60Hz), reverse rotation | Gear Ratio: 1/3140 | Output Speed: 0.8 rpm (50Hz) / 0.9 rpm (60Hz) | Max Permissible Output Torque: 30 kgf·cm | Rotation: Opposite to motor
