GGM KWC-3429-P1 Worm Geared Motor (DC 12V, 1/25–1/1500)

GGM KWC-3429-P1 Worm Geared Motor (DC 12V, 1/25–1/1500)

GGM KWC round-flange worm geared motor, KD3429P1 base, DC 12V. 19 gear ratios 1/25 to 1/1500, output torque 0.4–6 kgf·cm; ø12 output shaft, P.C.D ø46 flange mount.

KWC-0025-KD3429P1 KWC worm gearhead KD3429P1, 1/25, DC 12V | Gear Ratio: 1/25 | Output Speed: 320 rpm | Output Torque: 0.4 kgf·cm
KWC-0030-KD3429P1 KWC worm gearhead KD3429P1, 1/30, DC 12V | Gear Ratio: 1/30 | Output Speed: 267 rpm | Output Torque: 0.5 kgf·cm
KWC-0050-KD3429P1 KWC worm gearhead KD3429P1, 1/50, DC 12V | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 0.9 kgf·cm
KWC-0060-KD3429P1 KWC worm gearhead KD3429P1, 1/60, DC 12V | Gear Ratio: 1/60 | Output Speed: 133 rpm | Output Torque: 0.9 kgf·cm
KWC-0075-KD3429P1 KWC worm gearhead KD3429P1, 1/75, DC 12V | Gear Ratio: 1/75 | Output Speed: 107 rpm | Output Torque: 1.2 kgf·cm
KWC-0100-KD3429P1 KWC worm gearhead KD3429P1, 1/100, DC 12V | Gear Ratio: 1/100 | Output Speed: 80 rpm | Output Torque: 1.6 kgf·cm
KWC-0125-KD3429P1 KWC worm gearhead KD3429P1, 1/125, DC 12V | Gear Ratio: 1/125 | Output Speed: 64 rpm | Output Torque: 1.9 kgf·cm
KWC-0150-KD3429P1 KWC worm gearhead KD3429P1, 1/150, DC 12V | Gear Ratio: 1/150 | Output Speed: 53 rpm | Output Torque: 2.3 kgf·cm
KWC-0200-KD3429P1 KWC worm gearhead KD3429P1, 1/200, DC 12V | Gear Ratio: 1/200 | Output Speed: 40 rpm | Output Torque: 2.8 kgf·cm
KWC-0250-KD3429P1 KWC worm gearhead KD3429P1, 1/250, DC 12V | Gear Ratio: 1/250 | Output Speed: 32 rpm | Output Torque: 3.5 kgf·cm
KWC-0300-KD3429P1 KWC worm gearhead KD3429P1, 1/300, DC 12V | Gear Ratio: 1/300 | Output Speed: 26.7 rpm | Output Torque: 4.2 kgf·cm
KWC-0375-KD3429P1 KWC worm gearhead KD3429P1, 1/375, DC 12V | Gear Ratio: 1/375 | Output Speed: 21.3 rpm | Output Torque: 5.2 kgf·cm
KWC-0500-KD3429P1 KWC worm gearhead KD3429P1, 1/500, DC 12V | Gear Ratio: 1/500 | Output Speed: 16 rpm | Output Torque: 6 kgf·cm
KWC-0600-KD3429P1 KWC worm gearhead KD3429P1, 1/600, DC 12V | Gear Ratio: 1/600 | Output Speed: 13.3 rpm | Output Torque: 6 kgf·cm
KWC-0750-KD3429P1 KWC worm gearhead KD3429P1, 1/750, DC 12V | Gear Ratio: 1/750 | Output Speed: 10.7 rpm | Output Torque: 6 kgf·cm
KWC-0900-KD3429P1 KWC worm gearhead KD3429P1, 1/900, DC 12V | Gear Ratio: 1/900 | Output Speed: 8.9 rpm | Output Torque: 6 kgf·cm
KWC-1050-KD3429P1 KWC worm gearhead KD3429P1, 1/1050, DC 12V | Gear Ratio: 1/1050 | Output Speed: 7.6 rpm | Output Torque: 6 kgf·cm
KWC-1350-KD3429P1 KWC worm gearhead KD3429P1, 1/1350, DC 12V | Gear Ratio: 1/1350 | Output Speed: 5.9 rpm | Output Torque: 6 kgf·cm
KWC-1500-KD3429P1 KWC worm gearhead KD3429P1, 1/1500, DC 12V | Gear Ratio: 1/1500 | Output Speed: 5.3 rpm | Output Torque: 6 kgf·cm
DCGGM
19 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM KWC-3429-P1 Worm Geared Motor (DC 12V, 1/25–1/1500)

Brand GGM·DC

Available part numbers (19)

KWC-0025-KD3429P1, KWC-0030-KD3429P1, KWC-0050-KD3429P1, KWC-0060-KD3429P1, KWC-0075-KD3429P1, KWC-0100-KD3429P1, KWC-0125-KD3429P1, KWC-0150-KD3429P1, KWC-0200-KD3429P1, KWC-0250-KD3429P1 + 9 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
KWC-0025-KD3429P1KWC worm gearhead KD3429P1, 1/25, DC 12V | Gear Ratio: 1/25 | Output Speed: 320 rpm | Output Torque: 0.4 kgf·cm
KWC-0030-KD3429P1KWC worm gearhead KD3429P1, 1/30, DC 12V | Gear Ratio: 1/30 | Output Speed: 267 rpm | Output Torque: 0.5 kgf·cm
KWC-0050-KD3429P1KWC worm gearhead KD3429P1, 1/50, DC 12V | Gear Ratio: 1/50 | Output Speed: 160 rpm | Output Torque: 0.9 kgf·cm
KWC-0060-KD3429P1KWC worm gearhead KD3429P1, 1/60, DC 12V | Gear Ratio: 1/60 | Output Speed: 133 rpm | Output Torque: 0.9 kgf·cm
KWC-0075-KD3429P1KWC worm gearhead KD3429P1, 1/75, DC 12V | Gear Ratio: 1/75 | Output Speed: 107 rpm | Output Torque: 1.2 kgf·cm
KWC-0100-KD3429P1KWC worm gearhead KD3429P1, 1/100, DC 12V | Gear Ratio: 1/100 | Output Speed: 80 rpm | Output Torque: 1.6 kgf·cm
KWC-0125-KD3429P1KWC worm gearhead KD3429P1, 1/125, DC 12V | Gear Ratio: 1/125 | Output Speed: 64 rpm | Output Torque: 1.9 kgf·cm
KWC-0150-KD3429P1KWC worm gearhead KD3429P1, 1/150, DC 12V | Gear Ratio: 1/150 | Output Speed: 53 rpm | Output Torque: 2.3 kgf·cm
KWC-0200-KD3429P1KWC worm gearhead KD3429P1, 1/200, DC 12V | Gear Ratio: 1/200 | Output Speed: 40 rpm | Output Torque: 2.8 kgf·cm
KWC-0250-KD3429P1KWC worm gearhead KD3429P1, 1/250, DC 12V | Gear Ratio: 1/250 | Output Speed: 32 rpm | Output Torque: 3.5 kgf·cm
KWC-0300-KD3429P1KWC worm gearhead KD3429P1, 1/300, DC 12V | Gear Ratio: 1/300 | Output Speed: 26.7 rpm | Output Torque: 4.2 kgf·cm
KWC-0375-KD3429P1KWC worm gearhead KD3429P1, 1/375, DC 12V | Gear Ratio: 1/375 | Output Speed: 21.3 rpm | Output Torque: 5.2 kgf·cm
KWC-0500-KD3429P1KWC worm gearhead KD3429P1, 1/500, DC 12V | Gear Ratio: 1/500 | Output Speed: 16 rpm | Output Torque: 6 kgf·cm
KWC-0600-KD3429P1KWC worm gearhead KD3429P1, 1/600, DC 12V | Gear Ratio: 1/600 | Output Speed: 13.3 rpm | Output Torque: 6 kgf·cm
KWC-0750-KD3429P1KWC worm gearhead KD3429P1, 1/750, DC 12V | Gear Ratio: 1/750 | Output Speed: 10.7 rpm | Output Torque: 6 kgf·cm
KWC-0900-KD3429P1KWC worm gearhead KD3429P1, 1/900, DC 12V | Gear Ratio: 1/900 | Output Speed: 8.9 rpm | Output Torque: 6 kgf·cm
KWC-1050-KD3429P1KWC worm gearhead KD3429P1, 1/1050, DC 12V | Gear Ratio: 1/1050 | Output Speed: 7.6 rpm | Output Torque: 6 kgf·cm
KWC-1350-KD3429P1KWC worm gearhead KD3429P1, 1/1350, DC 12V | Gear Ratio: 1/1350 | Output Speed: 5.9 rpm | Output Torque: 6 kgf·cm
KWC-1500-KD3429P1KWC worm gearhead KD3429P1, 1/1500, DC 12V | Gear Ratio: 1/1500 | Output Speed: 5.3 rpm | Output Torque: 6 kgf·cm
