GGM NMRV 030 Worm Gear Reducer (hollow ø14 output, input ø12, 1/5~80)

GGM NMRV 030 Worm Gear Reducer (hollow ø14 output, input ø12, 1/5~80)

GGM NMRV 030 worm gear reducer with ø14 hollow bore (h8) output, ø12 input shaft and ø50 mounting flange.

Key features

  • Reduction ratios 1/5 to 1/80 (11 steps); optional single/double output shaft and motor input flange (PAM) available

Specifications

Type Worm Gear Reducer (NMRV series)
Frame NMRV 030
Output ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ)
Input Shaft ø12; motor flange (PAM) — option (RFQ)
Mounting Flange ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots)
Rated Torque by inquiry (RFQ)
NMRV030-5 GGM NMRV 030 worm gear reducer, ratio 1/5, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/5 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-7.5 GGM NMRV 030 worm gear reducer, ratio 1/7.5, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/7.5 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-10 GGM NMRV 030 worm gear reducer, ratio 1/10, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/10 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-15 GGM NMRV 030 worm gear reducer, ratio 1/15, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/15 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-20 GGM NMRV 030 worm gear reducer, ratio 1/20, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/20 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-25 GGM NMRV 030 worm gear reducer, ratio 1/25, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/25 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-30 GGM NMRV 030 worm gear reducer, ratio 1/30, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/30 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-40 GGM NMRV 030 worm gear reducer, ratio 1/40, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/40 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-50 GGM NMRV 030 worm gear reducer, ratio 1/50, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/50 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-60 GGM NMRV 030 worm gear reducer, ratio 1/60, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/60 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-80 GGM NMRV 030 worm gear reducer, ratio 1/80, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/80 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
Worm ReducersGGM
11 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GGM NMRV 030 Worm Gear Reducer (hollow ø14 output, input ø12, 1/5~80)

Brand GGM·Worm Reducers

Available part numbers (11)

NMRV030-5, NMRV030-7.5, NMRV030-10, NMRV030-15, NMRV030-20, NMRV030-25, NMRV030-30, NMRV030-40, NMRV030-50, NMRV030-60 + 1 more — see full table ↓

How to order

Send the GGM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
NMRV030-5GGM NMRV 030 worm gear reducer, ratio 1/5, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/5 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-7.5GGM NMRV 030 worm gear reducer, ratio 1/7.5, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/7.5 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-10GGM NMRV 030 worm gear reducer, ratio 1/10, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/10 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-15GGM NMRV 030 worm gear reducer, ratio 1/15, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/15 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-20GGM NMRV 030 worm gear reducer, ratio 1/20, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/20 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-25GGM NMRV 030 worm gear reducer, ratio 1/25, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/25 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-30GGM NMRV 030 worm gear reducer, ratio 1/30, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/30 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-40GGM NMRV 030 worm gear reducer, ratio 1/40, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/40 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-50GGM NMRV 030 worm gear reducer, ratio 1/50, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/50 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-60GGM NMRV 030 worm gear reducer, ratio 1/60, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/60 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
NMRV030-80GGM NMRV 030 worm gear reducer, ratio 1/80, ø14 hollow bore (h8) output, ø12 input | Type: Worm Gear Reducer (NMRV series) | Frame: NMRV 030 | Reduction Ratio: 1/80 | Output: ø14 hollow bore (h8) (standard); output shaft ø14 h6 (single/both end) — option (RFQ) | Input Shaft: ø12; motor flange (PAM) — option (RFQ) | Mounting Flange: ø50 h8, 4-M6 tap, P.C.D ø65; foot mount (14-ø6.5 U-slots) | Rated Torque: by inquiry (RFQ)
