Inovance H3S Series Economical Compact PLC (32-64 I/O)

Inovance H3S Series Economical Compact PLC (32-64 I/O)

The H3S series is an economical high-performance compact PLC evolved from the H3U, for equipment such as mobile phone assembly, packaging and printing machines.

Key features

  • Eight main units from 16/16 to 32/32 I/O, relay or transistor output
  • 64K steps program and 48K words data capacity
  • 4 x 200 kHz high-speed inputs and 5 x 200 kHz high-speed outputs
  • Ethernet supported; CANlink/CANopen and system time not supported
  • Local expansion with GL10 modules (incl. GL10-4PM/2PH)

Specifications

Program capacity 64K steps
Data capacity 48K words
High-speed inputs 4 x 200 kHz
High-speed outputs 5 x 200 kHz
Ethernet Supported
CAN Not supported
Certification CE
Source Inovance Expansion Module and HMI catalogue 19120152 A01, p. 21
H3S-1616MT-XP Model: H3S-1616MT-XP | I/O: 16 DI / 16 DO | Output: Transistor NPN
H3S-1616MR-XP Model: H3S-1616MR-XP | I/O: 16 DI / 16 DO | Output: Relay
H3S-2416MT-XP Model: H3S-2416MT-XP | I/O: 24 DI / 16 DO | Output: Transistor NPN
H3S-2416MR-XP Model: H3S-2416MR-XP | I/O: 24 DI / 16 DO | Output: Relay
H3S-3624MT Model: H3S-3624MT | I/O: 36 DI / 24 DO | Output: Transistor NPN
H3S-3624MR Model: H3S-3624MR | I/O: 36 DI / 24 DO | Output: Relay
H3S-3232MT Model: H3S-3232MT | I/O: 32 DI / 32 DO | Output: Transistor NPN
H3S-3232MR Model: H3S-3232MR | I/O: 32 DI / 32 DO | Output: Relay
PLCsInovance
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Inovance H3S Series Economical Compact PLC (32-64 I/O)

Brand Inovance·PLCs

Available part numbers (8)

H3S-1616MT-XP, H3S-1616MR-XP, H3S-2416MT-XP, H3S-2416MR-XP, H3S-3624MT, H3S-3624MR, H3S-3232MT, H3S-3232MR

How to order

Send the Inovance part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
H3S-1616MT-XPModel: H3S-1616MT-XP | I/O: 16 DI / 16 DO | Output: Transistor NPN
H3S-1616MR-XPModel: H3S-1616MR-XP | I/O: 16 DI / 16 DO | Output: Relay
H3S-2416MT-XPModel: H3S-2416MT-XP | I/O: 24 DI / 16 DO | Output: Transistor NPN
H3S-2416MR-XPModel: H3S-2416MR-XP | I/O: 24 DI / 16 DO | Output: Relay
H3S-3624MTModel: H3S-3624MT | I/O: 36 DI / 24 DO | Output: Transistor NPN
H3S-3624MRModel: H3S-3624MR | I/O: 36 DI / 24 DO | Output: Relay
H3S-3232MTModel: H3S-3232MT | I/O: 32 DI / 32 DO | Output: Transistor NPN
H3S-3232MRModel: H3S-3232MR | I/O: 32 DI / 32 DO | Output: Relay
