Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| LB11 | Body width: 110 mm | Motor power: 200 W (400 W option) | Lead: 40 mm (50/100 mm options) | Effective travel: 50-2,600 mm | Belt width: 25 mm | Linear guide: 15 x 12.5 - 2 | Max. load H: 20 kg | ||
| LB14H | Body width: 135 mm | Motor power: 200 W / 400 W | Lead: 40/100 mm | Effective travel: 50-3,050 mm | Belt width: 25 mm | Linear guide: 15 x 12.5 - 2 | Max. load H: 25 kg | ||
| LB17H | Body width: 170 mm | Motor power: 400 W | Lead: 40/100 mm | Effective travel: 50-3,050 mm | Belt width: 30 mm | Linear guide: 20 x 15 - 2 | Max. load H: 45 kg | ||
| LB22H | Body width: 220 mm | Motor power: 750 W | Lead: 40/100 mm | Effective travel: 50-3,050 mm (model page: up to 3,500 mm) | Belt width: 50 mm | Linear guide: 23 x 18 - 2 | Max. load H: 85 kg |
Need a different model, or a part not listed here? Send us your parts list →
