Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| LSMB16 | Spline shaft dia.: 16 mm | Rated load C/C0: 7.1 / 12.6 kN | Bearing rated load Cr/C0r: 8.4 / 6.8 kN | Rated torque CT/C0T: 31.4 / 34.3 N·m | Permissible static torque: 67.6 N·m | ||
| LSMB20 | Spline shaft dia.: 20 mm | Rated load C/C0: 10.2 / 17.8 kN | Bearing rated load Cr/C0r: 9.7 / 8.5 kN | Rated torque CT/C0T: 56.9 / 55.9 N·m | Permissible static torque: 118 N·m | ||
| LSMB25 | Spline shaft dia.: 25 mm | Rated load C/C0: 15.2 / 25.8 kN | Bearing rated load Cr/C0r: 13.8 / 13.2 kN | Rated torque CT/C0T: 105 / 103 N·m | Permissible static torque: 210 N·m | ||
| LSMB32 | Spline shaft dia.: 32 mm | Rated load C/C0: 20.5 / 34 kN | Bearing rated load Cr/C0r: 14.6 / 15.3 kN | Rated torque CT/C0T: 180 / 157 N·m | Permissible static torque: 290 N·m |
Need a different model, or a part not listed here? Send us your parts list →
