Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| RBSL1616 | Shaft dia.: 16 mm | Lead: 16 mm | Screw Ca/C0a: 4.2 / 7.2 kN | Spline rated torque CT/C0T: 44.7 / 68.8 N·m | Spline rated load C/C0: 8.6 / 13.2 kN | Permissible static torque: 77.2 N·m | ||
| RBSL2020 | Shaft dia.: 20 mm | Lead: 20 mm | Screw Ca/C0a: 6.5 / 12.7 kN | Spline rated torque CT/C0T: 76.5 / 130.4 N·m | Spline rated load C/C0: 11 / 18.8 kN | Permissible static torque: 146 N·m | ||
| RBSL2525 | Shaft dia.: 25 mm | Lead: 25 mm | Screw Ca/C0a: 8 / 14.4 kN | Spline rated torque CT/C0T: 125.3 / 207 N·m | Spline rated load C/C0: 15.9 / 26.2 kN | Permissible static torque: 228 N·m |
Need a different model, or a part not listed here? Send us your parts list →
