• KACON K16 Series Ø16 Mushroom Push Button Switches
1 1

KACON K16 Series Ø16 Mushroom Push Button Switches

KACON K16 Series Ø16 Mushroom Push Button Switches

KACON K16 Series Ø16 mm mushroom-head push button switches, round or square, momentary or maintained.

Key features

  • Ø16 mm panel mounting
  • Round and square mushroom heads
  • Momentary and maintained (H) action
  • Illuminated LED 6VDC, 12VDC, 24VDC, 220VAC
  • 1C or 2C contacts
  • Red, green and yellow

Specifications

Mounting Ø16 mm
LED voltage (illum.) 6VDC, 12VDC, 24VDC, 220VAC
Contact rating 1A 24VDC/120VAC, 0.5A 250VAC
Max. switching current 3A
Contact material Ag alloy (24K gold plate)
Insulation resistance Min. 100MΩ (500VDC)
Dielectric strength 2,000VAC 1 minute
Ambient temperature -25 to +55 °C
Degree of protection IP65
Termination #110 quick-fit / solder
Source KACON Buzzer catalogue, p. 5
K16-911R Action: Momentary | Illumination: Non-illuminated | Shape: Round | Contacts: 1C | Colour: Red
K16-911G Action: Momentary | Illumination: Non-illuminated | Shape: Round | Contacts: 1C | Colour: Green
K16-911Y Action: Momentary | Illumination: Non-illuminated | Shape: Round | Contacts: 1C | Colour: Yellow
K16-971R Action: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Red
K16-971G Action: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Green
K16-971Y Action: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Yellow
K16-972R Action: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Red
K16-972G Action: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Green
K16-972Y Action: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Yellow
K16-981R Action: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Red
K16-981G Action: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Green
K16-981Y Action: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Yellow
K16-982R Action: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Red
K16-982G Action: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Green
K16-982Y Action: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Yellow
K16-971RH Action: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Red
K16-971GH Action: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Green
K16-971YH Action: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Yellow
K16-972RH Action: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Red
K16-972GH Action: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Green
K16-972YH Action: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Yellow
K16-981RH Action: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Red
K16-981GH Action: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Green
K16-981YH Action: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Yellow
K16-982RH Action: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Red
K16-982GH Action: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Green
K16-982YH Action: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Yellow
Push Button SwitchesKACON
27 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KACON K16 Series Ø16 Mushroom Push Button Switches

Brand KACON·Push Button Switches

Available part numbers (27)

K16-911R, K16-911G, K16-911Y, K16-971R, K16-971G, K16-971Y, K16-972R, K16-972G, K16-972Y, K16-981R + 17 more — see full table ↓

How to order

Send the KACON part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
K16-911RAction: Momentary | Illumination: Non-illuminated | Shape: Round | Contacts: 1C | Colour: Red
K16-911GAction: Momentary | Illumination: Non-illuminated | Shape: Round | Contacts: 1C | Colour: Green
K16-911YAction: Momentary | Illumination: Non-illuminated | Shape: Round | Contacts: 1C | Colour: Yellow
K16-971RAction: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Red
K16-971GAction: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Green
K16-971YAction: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Yellow
K16-972RAction: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Red
K16-972GAction: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Green
K16-972YAction: Momentary | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Yellow
K16-981RAction: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Red
K16-981GAction: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Green
K16-981YAction: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Yellow
K16-982RAction: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Red
K16-982GAction: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Green
K16-982YAction: Momentary | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Yellow
K16-971RHAction: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Red
K16-971GHAction: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Green
K16-971YHAction: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 1C | Colour: Yellow
K16-972RHAction: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Red
K16-972GHAction: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Green
K16-972YHAction: Maintained | Illumination: Illuminated LED | Shape: Round | Contacts: 2C | Colour: Yellow
K16-981RHAction: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Red
K16-981GHAction: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Green
K16-981YHAction: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 1C | Colour: Yellow
K16-982RHAction: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Red
K16-982GHAction: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Green
K16-982YHAction: Maintained | Illumination: Illuminated LED | Shape: Square | Contacts: 2C | Colour: Yellow
