KACON T Series Metal Non-Illuminated Push Buttons (Ø16-Ø30)

KACON T Series Metal Non-Illuminated Push Buttons (Ø16-Ø30)

Full-metal non-illuminated push button switches of the KACON T Series in five mounting sizes.

Key features

  • Momentary and maintained action
  • Flush or extended head
  • 1C (1NO+1NC) or 2C (2NO+2NC) contacts
  • Mounting sizes Ø16, Ø19, Ø22, Ø25 and Ø30
  • Ag alloy contacts with 24K gold plating
  • Mechanical life min. 1,000,000 (momentary)

Specifications

Housing Full metal (stainless) bezel
Ambient temperature -25 to +55°C
Contact rating Max. 250VAC / 110VDC, 3A (5A T22 1C)
Terminal Quick-connect 2.8mm (solderable)
Contact material Ag alloy (24K gold plate)
Degree of protection IP67
Source KACON T Series Full Metal Control Switch catalogue, p. 4-17
T16-211P Size: Ø16 | Action: Momentary | Head: Flush | Contacts: 1C (1NO+1NC)
T16-212P Size: Ø16 | Action: Momentary | Head: Flush | Contacts: 2C (2NO+2NC)
T16-311P Size: Ø16 | Action: Maintained | Head: Flush | Contacts: 1C (1NO+1NC)
T16-312P Size: Ø16 | Action: Maintained | Head: Flush | Contacts: 2C (2NO+2NC)
T16-211HP Size: Ø16 | Action: Momentary | Head: Extended | Contacts: 1C (1NO+1NC)
T16-212HP Size: Ø16 | Action: Momentary | Head: Extended | Contacts: 2C (2NO+2NC)
T16-311HP Size: Ø16 | Action: Maintained | Head: Extended | Contacts: 1C (1NO+1NC)
T16-312HP Size: Ø16 | Action: Maintained | Head: Extended | Contacts: 2C (2NO+2NC)
T19-211P Size: Ø19 | Action: Momentary | Head: Flush | Contacts: 1C (1NO+1NC)
T19-212P Size: Ø19 | Action: Momentary | Head: Flush | Contacts: 2C (2NO+2NC)
T19-311P Size: Ø19 | Action: Maintained | Head: Flush | Contacts: 1C (1NO+1NC)
T19-312P Size: Ø19 | Action: Maintained | Head: Flush | Contacts: 2C (2NO+2NC)
T19-211HP Size: Ø19 | Action: Momentary | Head: Extended | Contacts: 1C (1NO+1NC)
T19-212HP Size: Ø19 | Action: Momentary | Head: Extended | Contacts: 2C (2NO+2NC)
T19-311HP Size: Ø19 | Action: Maintained | Head: Extended | Contacts: 1C (1NO+1NC)
T19-312HP Size: Ø19 | Action: Maintained | Head: Extended | Contacts: 2C (2NO+2NC)
T22-211P Size: Ø22 | Action: Momentary | Head: Flush | Contacts: 1C (1NO+1NC)
T22-212P Size: Ø22 | Action: Momentary | Head: Flush | Contacts: 2C (2NO+2NC)
T22-311P Size: Ø22 | Action: Maintained | Head: Flush | Contacts: 1C (1NO+1NC)
T22-312P Size: Ø22 | Action: Maintained | Head: Flush | Contacts: 2C (2NO+2NC)
T22-211HP Size: Ø22 | Action: Momentary | Head: Extended | Contacts: 1C (1NO+1NC)
T22-212HP Size: Ø22 | Action: Momentary | Head: Extended | Contacts: 2C (2NO+2NC)
T22-311HP Size: Ø22 | Action: Maintained | Head: Extended | Contacts: 1C (1NO+1NC)
T22-312HP Size: Ø22 | Action: Maintained | Head: Extended | Contacts: 2C (2NO+2NC)
T25-211P Size: Ø25 | Action: Momentary | Head: Flush | Contacts: 1C (1NO+1NC)
T25-212P Size: Ø25 | Action: Momentary | Head: Flush | Contacts: 2C (2NO+2NC)
T25-311P Size: Ø25 | Action: Maintained | Head: Flush | Contacts: 1C (1NO+1NC)
T25-312P Size: Ø25 | Action: Maintained | Head: Flush | Contacts: 2C (2NO+2NC)
T25-211HP Size: Ø25 | Action: Momentary | Head: Extended | Contacts: 1C (1NO+1NC)
T25-212HP Size: Ø25 | Action: Momentary | Head: Extended | Contacts: 2C (2NO+2NC)
T25-311HP Size: Ø25 | Action: Maintained | Head: Extended | Contacts: 1C (1NO+1NC)
T25-312HP Size: Ø25 | Action: Maintained | Head: Extended | Contacts: 2C (2NO+2NC)
T30-211P Size: Ø30 | Action: Momentary | Head: Flush | Contacts: 1C (1NO+1NC)
T30-212P Size: Ø30 | Action: Momentary | Head: Flush | Contacts: 2C (2NO+2NC)
T30-311P Size: Ø30 | Action: Maintained | Head: Flush | Contacts: 1C (1NO+1NC)
T30-312P Size: Ø30 | Action: Maintained | Head: Flush | Contacts: 2C (2NO+2NC)
T30-211HP Size: Ø30 | Action: Momentary | Head: Extended | Contacts: 1C (1NO+1NC)
T30-212HP Size: Ø30 | Action: Momentary | Head: Extended | Contacts: 2C (2NO+2NC)
T30-311HP Size: Ø30 | Action: Maintained | Head: Extended | Contacts: 1C (1NO+1NC)
T30-312HP Size: Ø30 | Action: Maintained | Head: Extended | Contacts: 2C (2NO+2NC)
