KACON T Series Metal Selector Switches (Ø16, Ø19, Ø22)

KACON T Series Metal Selector Switches (Ø16, Ø19, Ø22)

Full-metal 2- and 3-position selector switches of the KACON T Series, non-illuminated or LED illuminated.

Key features

  • 2-position (90°) and 3-position (45°/45°) operation
  • Non-illuminated or LED-illuminated knob
  • 1C or 2C contacts
  • Illuminated: red, green, yellow, blue, white at 24VDC or 220VAC
  • Mounting sizes Ø16, Ø19 and Ø22

Specifications

Housing Full metal (stainless) bezel
Illumination LED, approx. 10mA, 50,000 h
Ambient temperature -25 to +55°C
Contact rating Max. 250VAC / 110VDC, 3A (5A T22 1C)
Terminal Quick-connect 2.8mm (solderable)
Degree of protection IP54
Source KACON T Series Full Metal Control Switch catalogue, p. 6-13
T16-411P Size: Ø16 | Positions: 2-position | Illumination: None | Contacts: 1C (1NO+1NC) | Colour: N/A | Lamp voltage: N/A
T16-412P Size: Ø16 | Positions: 2-position | Illumination: None | Contacts: 2C (2NO+2NC) | Colour: N/A | Lamp voltage: N/A
T16-512P Size: Ø16 | Positions: 3-position | Illumination: None | Contacts: 2C (2NO+2NC) | Colour: N/A | Lamp voltage: N/A
T16-471PRD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Red | Lamp voltage: 24VDC
T16-471PRA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Red | Lamp voltage: 220VAC
T16-471PGD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Green | Lamp voltage: 24VDC
T16-471PGA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Green | Lamp voltage: 220VAC
T16-471PYD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Yellow | Lamp voltage: 24VDC
T16-471PYA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Yellow | Lamp voltage: 220VAC
T16-471PBD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Blue | Lamp voltage: 24VDC
T16-471PBA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Blue | Lamp voltage: 220VAC
T16-471PWD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: White | Lamp voltage: 24VDC
T16-471PWA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: White | Lamp voltage: 220VAC
T16-472PRD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 24VDC
T16-472PRA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 220VAC
T16-472PGD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 24VDC
T16-472PGA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 220VAC
T16-472PYD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 24VDC
T16-472PYA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 220VAC
T16-472PBD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 24VDC
T16-472PBA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 220VAC
T16-472PWD4 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 24VDC
T16-472PWA2 Size: Ø16 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 220VAC
T16-572PRD4 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 24VDC
T16-572PRA2 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 220VAC
T16-572PGD4 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 24VDC
T16-572PGA2 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 220VAC
T16-572PYD4 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 24VDC
T16-572PYA2 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 220VAC
T16-572PBD4 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 24VDC
T16-572PBA2 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 220VAC
T16-572PWD4 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 24VDC
T16-572PWA2 Size: Ø16 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 220VAC
T19-411P Size: Ø19 | Positions: 2-position | Illumination: None | Contacts: 1C (1NO+1NC) | Colour: N/A | Lamp voltage: N/A
T19-412P Size: Ø19 | Positions: 2-position | Illumination: None | Contacts: 2C (2NO+2NC) | Colour: N/A | Lamp voltage: N/A
T19-512P Size: Ø19 | Positions: 3-position | Illumination: None | Contacts: 2C (2NO+2NC) | Colour: N/A | Lamp voltage: N/A
T19-471PRD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Red | Lamp voltage: 24VDC
T19-471PRA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Red | Lamp voltage: 220VAC
T19-471PGD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Green | Lamp voltage: 24VDC
T19-471PGA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Green | Lamp voltage: 220VAC
T19-471PYD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Yellow | Lamp voltage: 24VDC
T19-471PYA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Yellow | Lamp voltage: 220VAC
T19-471PBD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Blue | Lamp voltage: 24VDC
T19-471PBA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Blue | Lamp voltage: 220VAC
T19-471PWD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: White | Lamp voltage: 24VDC
T19-471PWA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: White | Lamp voltage: 220VAC
T19-472PRD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 24VDC
T19-472PRA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 220VAC
T19-472PGD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 24VDC
T19-472PGA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 220VAC
T19-472PYD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 24VDC
T19-472PYA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 220VAC
T19-472PBD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 24VDC
T19-472PBA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 220VAC
T19-472PWD4 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 24VDC
T19-472PWA2 Size: Ø19 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 220VAC
T19-572PRD4 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 24VDC
T19-572PRA2 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 220VAC
T19-572PGD4 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 24VDC
T19-572PGA2 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 220VAC
T19-572PYD4 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 24VDC
T19-572PYA2 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 220VAC
T19-572PBD4 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 24VDC
T19-572PBA2 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 220VAC
T19-572PWD4 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 24VDC
T19-572PWA2 Size: Ø19 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 220VAC
T22-411P Size: Ø22 | Positions: 2-position | Illumination: None | Contacts: 1C (1NO+1NC) | Colour: N/A | Lamp voltage: N/A
T22-412P Size: Ø22 | Positions: 2-position | Illumination: None | Contacts: 2C (2NO+2NC) | Colour: N/A | Lamp voltage: N/A
T22-512P Size: Ø22 | Positions: 3-position | Illumination: None | Contacts: 2C (2NO+2NC) | Colour: N/A | Lamp voltage: N/A
T22-471PRD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Red | Lamp voltage: 24VDC
T22-471PRA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Red | Lamp voltage: 220VAC
T22-471PGD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Green | Lamp voltage: 24VDC
T22-471PGA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Green | Lamp voltage: 220VAC
T22-471PYD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Yellow | Lamp voltage: 24VDC
T22-471PYA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Yellow | Lamp voltage: 220VAC
T22-471PBD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Blue | Lamp voltage: 24VDC
T22-471PBA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: Blue | Lamp voltage: 220VAC
T22-471PWD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: White | Lamp voltage: 24VDC
T22-471PWA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 1C (1NO+1NC) | Colour: White | Lamp voltage: 220VAC
T22-472PRD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 24VDC
T22-472PRA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 220VAC
T22-472PGD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 24VDC
T22-472PGA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 220VAC
T22-472PYD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 24VDC
T22-472PYA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 220VAC
T22-472PBD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 24VDC
T22-472PBA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 220VAC
T22-472PWD4 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 24VDC
T22-472PWA2 Size: Ø22 | Positions: 2-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 220VAC
T22-572PRD4 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 24VDC
T22-572PRA2 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Red | Lamp voltage: 220VAC
T22-572PGD4 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 24VDC
T22-572PGA2 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Green | Lamp voltage: 220VAC
T22-572PYD4 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 24VDC
T22-572PYA2 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Yellow | Lamp voltage: 220VAC
T22-572PBD4 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 24VDC
T22-572PBA2 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: Blue | Lamp voltage: 220VAC
T22-572PWD4 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 24VDC
T22-572PWA2 Size: Ø22 | Positions: 3-position | Illumination: LED | Contacts: 2C (2NO+2NC) | Colour: White | Lamp voltage: 220VAC
Selector SwitchesKACON
99 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KACON T Series Metal Selector Switches (Ø16, Ø19, Ø22)

Brand KACON·Selector Switches

Available part numbers (99)

T16-411P, T16-412P, T16-512P, T16-471PRD4, T16-471PRA2, T16-471PGD4, T16-471PGA2, T16-471PYD4, T16-471PYA2, T16-471PBD4 + 89 more — see full table ↓
