KOINO KTM-3MN Multi-Mode Timing Relays (1.2 s-60 h, 14-pin)

KOINO KTM-3MN Multi-Mode Timing Relays (1.2 s-60 h, 14-pin)

KOINO KTM-3MN miniature multi-mode timing relay in a 14-pin relay housing, with 4 switchable time scales and 4 operation modes per model, 6 ordered time ranges, 8 supply voltages and 4-pin or 2-pin output versions.

Key features

  • Compact 14-pin timer mating with KOINO sockets KH-RS-14M / KH-RS-14N
  • 4 operation modes selected by DIP switch: ON DELAY, INTERVAL, FLICKER ON START, FLICKER OFF START
  • 4 time scales per model selected by DIP switch; time and mode changes take effect in real time
  • Time range ordered by code: 1 = 1.2 s-12 min, 3 = 3 s-30 min, 7 = 1.2 min-12 h, 9 = 3 min-30 h; codes 5 (6 s-60 min) and 6 (6 min-60 h) are made to order
  • Supply voltage by model: 100-120 / 200-230 / 240VAC or 12 / 24 / 48 / 110 / 125VDC
  • Output: 4-pin 4C (4a4b) 220VAC 3A or 2-pin 2C (2a2b) 220VAC 5A; red power/operation LED, yellow output LED

Specifications

Operation modes ON DELAY / INTERVAL / FLICKER ON START / FLICKER OFF START
Voltage tolerance +/-10% of rated
Power consumption AC approx. 3VA, DC approx. 1.5W
Reset time 100 ms max.
Set error +/-5%, 50 ms max. of full scale
Relay life Mechanical 10 million, electrical 200,000 ops
Dielectric strength 2,000VAC 50/60Hz for 1 min
Protection IP40
Operating temperature -10 to +50 C (no freezing), 35-85% RH
Housing Case ABS ivory, base PC glass; approx. 40 g
Source KOINO general catalog 5th ed., p. 559-587
KTM-3MN1A1 Time range: 1.2 s to 12 min | Supply voltage: 100-120VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN1A12 Time range: 1.2 s to 12 min | Supply voltage: 100-120VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN1A2 Time range: 1.2 s to 12 min | Supply voltage: 200-230VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN1A22 Time range: 1.2 s to 12 min | Supply voltage: 200-230VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN1A3 Time range: 1.2 s to 12 min | Supply voltage: 240VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN1A32 Time range: 1.2 s to 12 min | Supply voltage: 240VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN1D1 Time range: 1.2 s to 12 min | Supply voltage: 12VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN1D12 Time range: 1.2 s to 12 min | Supply voltage: 12VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN1D2 Time range: 1.2 s to 12 min | Supply voltage: 24VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN1D22 Time range: 1.2 s to 12 min | Supply voltage: 24VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN1D3 Time range: 1.2 s to 12 min | Supply voltage: 48VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN1D32 Time range: 1.2 s to 12 min | Supply voltage: 48VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN1D4 Time range: 1.2 s to 12 min | Supply voltage: 110VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN1D42 Time range: 1.2 s to 12 min | Supply voltage: 110VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN1D5 Time range: 1.2 s to 12 min | Supply voltage: 125VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN1D52 Time range: 1.2 s to 12 min | Supply voltage: 125VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN3A1 Time range: 3 s to 30 min | Supply voltage: 100-120VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN3A12 Time range: 3 s to 30 min | Supply voltage: 100-120VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN3A2 Time range: 3 s to 30 min | Supply voltage: 200-230VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN3A22 Time range: 3 s to 30 min | Supply voltage: 200-230VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN3A3 Time range: 3 s to 30 min | Supply voltage: 240VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN3A32 Time range: 3 s to 30 min | Supply voltage: 240VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN3D1 Time range: 3 s to 30 min | Supply voltage: 12VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN3D12 Time range: 3 s to 30 min | Supply voltage: 12VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN3D2 Time range: 3 s to 30 min | Supply voltage: 24VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN3D22 Time range: 3 s to 30 min | Supply voltage: 24VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN3D3 Time range: 3 s to 30 min | Supply voltage: 48VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN3D32 Time range: 3 s to 30 min | Supply voltage: 48VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN3D4 Time range: 3 s to 30 min | Supply voltage: 110VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN3D42 Time range: 3 s to 30 min | Supply voltage: 110VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN3D5 Time range: 3 s to 30 min | Supply voltage: 125VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN3D52 Time range: 3 s to 30 min | Supply voltage: 125VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN5A1 Time range: 6 s to 60 min (made to order) | Supply voltage: 100-120VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN5A12 Time range: 6 s to 60 min (made to order) | Supply voltage: 100-120VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN5A2 Time range: 6 s to 60 min (made to order) | Supply voltage: 200-230VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN5A22 Time range: 6 s to 60 min (made to order) | Supply voltage: 200-230VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN5A3 Time range: 6 s to 60 min (made to order) | Supply voltage: 240VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN5A32 Time range: 6 s to 60 min (made to order) | Supply voltage: 240VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN5D1 Time range: 6 s to 60 min (made to order) | Supply voltage: 12VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN5D12 Time range: 6 s to 60 min (made to order) | Supply voltage: 12VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN5D2 Time range: 6 s to 60 min (made to order) | Supply voltage: 24VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN5D22 Time range: 6 s to 60 min (made to order) | Supply voltage: 24VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN5D3 Time range: 6 s to 60 min (made to order) | Supply voltage: 48VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN5D32 Time range: 6 s to 60 min (made to order) | Supply voltage: 48VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN5D4 Time range: 6 s to 60 min (made to order) | Supply voltage: 110VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN5D42 Time range: 6 s to 60 min (made to order) | Supply voltage: 110VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN5D5 Time range: 6 s to 60 min (made to order) | Supply voltage: 125VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN5D52 Time range: 6 s to 60 min (made to order) | Supply voltage: 125VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN6A1 Time range: 6 min to 60 h (made to order) | Supply voltage: 100-120VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN6A12 Time range: 6 min to 60 h (made to order) | Supply voltage: 100-120VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN6A2 Time range: 6 min to 60 h (made to order) | Supply voltage: 200-230VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN6A22 Time range: 6 min to 60 h (made to order) | Supply voltage: 200-230VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN6A3 Time range: 6 min to 60 h (made to order) | Supply voltage: 240VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN6A32 Time range: 6 min to 60 h (made to order) | Supply voltage: 240VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN6D1 Time range: 6 min to 60 h (made to order) | Supply voltage: 12VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN6D12 Time range: 6 min to 60 h (made to order) | Supply voltage: 12VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN6D2 Time range: 6 min to 60 h (made to order) | Supply voltage: 24VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN6D22 Time range: 6 min to 60 h (made to order) | Supply voltage: 24VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN6D3 Time range: 6 min to 60 h (made to order) | Supply voltage: 48VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN6D32 Time range: 6 min to 60 h (made to order) | Supply voltage: 48VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN6D4 Time range: 6 min to 60 h (made to order) | Supply voltage: 110VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN6D42 Time range: 6 min to 60 h (made to order) | Supply voltage: 110VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN6D5 Time range: 6 min to 60 h (made to order) | Supply voltage: 125VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN6D52 Time range: 6 min to 60 h (made to order) | Supply voltage: 125VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN7A1 Time range: 1.2 min to 12 h | Supply voltage: 100-120VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN7A12 Time range: 1.2 min to 12 h | Supply voltage: 100-120VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN7A2 Time range: 1.2 min to 12 h | Supply voltage: 200-230VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN7A22 Time range: 1.2 min to 12 h | Supply voltage: 200-230VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN7A3 Time range: 1.2 min to 12 h | Supply voltage: 240VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN7A32 Time range: 1.2 min to 12 h | Supply voltage: 240VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN7D1 Time range: 1.2 min to 12 h | Supply voltage: 12VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN7D12 Time range: 1.2 min to 12 h | Supply voltage: 12VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN7D2 Time range: 1.2 min to 12 h | Supply voltage: 24VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN7D22 Time range: 1.2 min to 12 h | Supply voltage: 24VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN7D3 Time range: 1.2 min to 12 h | Supply voltage: 48VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN7D32 Time range: 1.2 min to 12 h | Supply voltage: 48VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN7D4 Time range: 1.2 min to 12 h | Supply voltage: 110VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN7D42 Time range: 1.2 min to 12 h | Supply voltage: 110VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN7D5 Time range: 1.2 min to 12 h | Supply voltage: 125VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN7D52 Time range: 1.2 min to 12 h | Supply voltage: 125VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN9A1 Time range: 3 min to 30 h | Supply voltage: 100-120VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN9A12 Time range: 3 min to 30 h | Supply voltage: 100-120VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN9A2 Time range: 3 min to 30 h | Supply voltage: 200-230VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN9A22 Time range: 3 min to 30 h | Supply voltage: 200-230VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN9A3 Time range: 3 min to 30 h | Supply voltage: 240VAC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN9A32 Time range: 3 min to 30 h | Supply voltage: 240VAC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN9D1 Time range: 3 min to 30 h | Supply voltage: 12VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN9D12 Time range: 3 min to 30 h | Supply voltage: 12VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN9D2 Time range: 3 min to 30 h | Supply voltage: 24VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN9D22 Time range: 3 min to 30 h | Supply voltage: 24VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN9D3 Time range: 3 min to 30 h | Supply voltage: 48VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN9D32 Time range: 3 min to 30 h | Supply voltage: 48VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN9D4 Time range: 3 min to 30 h | Supply voltage: 110VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN9D42 Time range: 3 min to 30 h | Supply voltage: 110VDC | Pin type: 2-pin plug-in (2C, 5A)
KTM-3MN9D5 Time range: 3 min to 30 h | Supply voltage: 125VDC | Pin type: 4-pin plug-in (4C, 3A)
KTM-3MN9D52 Time range: 3 min to 30 h | Supply voltage: 125VDC | Pin type: 2-pin plug-in (2C, 5A)
TimersKOINO
96 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KOINO KTM-3MN Multi-Mode Timing Relays (1.2 s-60 h, 14-pin)

Brand KOINO·Timers

Available part numbers (96)

KTM-3MN1A1, KTM-3MN1A12, KTM-3MN1A2, KTM-3MN1A22, KTM-3MN1A3, KTM-3MN1A32, KTM-3MN1D1, KTM-3MN1D12, KTM-3MN1D2, KTM-3MN1D22 + 86 more — see full table ↓

How to order

Send the KOINO part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
