• LS Electric 52EGR Beyond X Industrial Distribution Panel MCB/RCBO (Standard RCBO (BKE-series compatible), 50AF RCBO, 5kA @ 220V AC, 15, 30mA, 40~50A)
1 1

LS Electric 52EGR Beyond X Industrial Distribution Panel MCB/RCBO (Standard RCBO (BKE-series compatible), 50AF RCBO, 5kA @ 220V AC, 15, 30mA, 40~50A)

LS Electric 52EGR Beyond X Industrial Distribution Panel MCB/RCBO (Standard RCBO (BKE-series compatible), 50AF RCBO, 5kA @ 220V AC, 15, 30mA, 40~50A)

LS ELECTRIC Beyond X Industrial Distribution Panel MCB/RCBO 52EGR family. | Application: Industrial distribution panel (RCBO). | Frame: 50AF | Type: Standard RCBO (BKE-series compatible) | Trip method: Thermal + RCD | Trip curve: Thermal standard | Breaking capacity Icn: 5kA @ 220V AC | Ics: 100% Icn | Sensitivity (I△n): 15, 30mA | Rated current (In): 40A, 50A | Pole: 2P | Mounting: Screw or DIN rail | Uimp: 4kV | Voltage: AC 220V | Standard: KSC 4613 / — | 2 variants — see RFQ table for specific MPN.

Specifications

Frame 50AF
Type Standard RCBO (BKE-series compatible)
Pole 2P
Breaking capacity Icn 5kA @ 220V AC
Ics 100% Icn
Trip method Thermal + RCD
Trip curve Thermal standard
Sensitivity (I△n) 15, 30mA
Uimp 4kV
Mounting Screw or DIN rail
Voltage AC 220V
Standard KSC 4613 / —
52EGR/40/15, 30 EGR 52EGR — 52EGR 40A 2P (RCBO) | Frame: 50AF | Type: Standard RCBO (BKE-series compatible) | Rated current (In): 40A | Pole: 2P | Breaking capacity Icn: 5kA @ 220V AC | Ics: 100% Icn | Trip method: Thermal + RCD | Trip curve: Thermal standard | Sensitivity (I△n): 15, 30mA | Uimp: 4kV | Mounting: Screw or DIN rail | Voltage: AC 220V | Standard: KSC 4613 / — | Application: Industrial distribution panel (RCBO)
52EGR/50/15, 30 EGR 52EGR — 52EGR 50A 2P (RCBO) | Frame: 50AF | Type: Standard RCBO (BKE-series compatible) | Rated current (In): 50A | Pole: 2P | Breaking capacity Icn: 5kA @ 220V AC | Ics: 100% Icn | Trip method: Thermal + RCD | Trip curve: Thermal standard | Sensitivity (I△n): 15, 30mA | Uimp: 4kV | Mounting: Screw or DIN rail | Voltage: AC 220V | Standard: KSC 4613 / — | Application: Industrial distribution panel (RCBO)
Miniature Circuit BreakersLS Electric
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric 52EGR Beyond X Industrial Distribution Panel MCB/RCBO (Standard RCBO (BKE-series compatible), 50AF RCBO, 5kA @ 220V AC, 15, 30mA, 40~50A)

Brand LS Electric·Miniature Circuit Breakers

Available part numbers (2)

52EGR/40/15, 30, 52EGR/50/15, 30

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
52EGR/40/15, 30EGR 52EGR — 52EGR 40A 2P (RCBO) | Frame: 50AF | Type: Standard RCBO (BKE-series compatible) | Rated current (In): 40A | Pole: 2P | Breaking capacity Icn: 5kA @ 220V AC | Ics: 100% Icn | Trip method: Thermal + RCD | Trip curve: Thermal standard | Sensitivity (I△n): 15, 30mA | Uimp: 4kV | Mounting: Screw or DIN rail | Voltage: AC 220V | Standard: KSC 4613 / — | Application: Industrial distribution panel (RCBO)
52EGR/50/15, 30EGR 52EGR — 52EGR 50A 2P (RCBO) | Frame: 50AF | Type: Standard RCBO (BKE-series compatible) | Rated current (In): 50A | Pole: 2P | Breaking capacity Icn: 5kA @ 220V AC | Ics: 100% Icn | Trip method: Thermal + RCD | Trip curve: Thermal standard | Sensitivity (I△n): 15, 30mA | Uimp: 4kV | Mounting: Screw or DIN rail | Voltage: AC 220V | Standard: KSC 4613 / — | Application: Industrial distribution panel (RCBO)
