• LS Electric Metasol MC-65aSP Welder Contactor
1 1

LS Electric Metasol MC-65aSP Welder Contactor

LS Electric Metasol MC-65aSP Welder Contactor

LS ELECTRIC Metasol MC-65aSP Welder-Use Contactor. | Application: AC arc welder safety device (electric shock prevention for operator). | Pole: 1P main contact (1a) | Standard aux: none (optional 1a1b/2a2b) | Rated use current (AC 110/220): 220A | Carrying current: 500A | Switching frequency: ≥600/hour | Operating performance: ≥1.5×rated for closing/breaking (AC1) | Coil: AC 50/60Hz only | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Impact-resistant frame design | Mounting: screw/rail | See RFQ table for specific MPN.

Specifications

Model MC-65aSP
Pole 1P main (1a), aux optional 1a1b/2a2b
Rated use current (AC 110/220) 220A
Carrying 500A
Switching ≥600/hour
Application AC welder shock prevention
Life 50 ×10,000 operations elec / 500 ×10,000 operations mech
Mounting screw/rail
MC-65aSP/AC24V/50/60Hz MC-65aSP welder contactor, AC 24V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 24V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC48V/50/60Hz MC-65aSP welder contactor, AC 48V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 48V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC100V/50/60Hz MC-65aSP welder contactor, AC 100V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 100V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC110V/50/60Hz MC-65aSP welder contactor, AC 110V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 110V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC120V/50/60Hz MC-65aSP welder contactor, AC 120V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 120V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC200V/50/60Hz MC-65aSP welder contactor, AC 200V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 200V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC220V/50/60Hz MC-65aSP welder contactor, AC 220V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 220V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC230V/50/60Hz MC-65aSP welder contactor, AC 230V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 230V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC240V/50/60Hz MC-65aSP welder contactor, AC 240V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 240V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC380V/50/60Hz MC-65aSP welder contactor, AC 380V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 380V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC400V/50/60Hz MC-65aSP welder contactor, AC 400V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 400V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC440V/50/60Hz MC-65aSP welder contactor, AC 440V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 440V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC500V/50/60Hz MC-65aSP welder contactor, AC 500V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 500V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC550V/50/60Hz MC-65aSP welder contactor, AC 550V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 550V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
Magnetic ContactorsLS Electric
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Metasol MC-65aSP Welder Contactor

Brand LS Electric·Magnetic Contactors

Available part numbers (14)

MC-65aSP/AC24V/50/60Hz, MC-65aSP/AC48V/50/60Hz, MC-65aSP/AC100V/50/60Hz, MC-65aSP/AC110V/50/60Hz, MC-65aSP/AC120V/50/60Hz, MC-65aSP/AC200V/50/60Hz, MC-65aSP/AC220V/50/60Hz, MC-65aSP/AC230V/50/60Hz, MC-65aSP/AC240V/50/60Hz, MC-65aSP/AC380V/50/60Hz + 4 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MC-65aSP/AC24V/50/60HzMC-65aSP welder contactor, AC 24V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 24V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC48V/50/60HzMC-65aSP welder contactor, AC 48V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 48V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC100V/50/60HzMC-65aSP welder contactor, AC 100V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 100V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC110V/50/60HzMC-65aSP welder contactor, AC 110V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 110V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC120V/50/60HzMC-65aSP welder contactor, AC 120V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 120V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC200V/50/60HzMC-65aSP welder contactor, AC 200V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 200V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC220V/50/60HzMC-65aSP welder contactor, AC 220V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 220V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC230V/50/60HzMC-65aSP welder contactor, AC 230V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 230V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC240V/50/60HzMC-65aSP welder contactor, AC 240V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 240V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC380V/50/60HzMC-65aSP welder contactor, AC 380V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 380V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC400V/50/60HzMC-65aSP welder contactor, AC 400V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 400V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC440V/50/60HzMC-65aSP welder contactor, AC 440V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 440V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC500V/50/60HzMC-65aSP welder contactor, AC 500V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 500V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
MC-65aSP/AC550V/50/60HzMC-65aSP welder contactor, AC 550V 50/60Hz | Model: MC-65aSP | Pole: 1P main (1a), aux optional 1a1b/2a2b | Coil: AC 550V 50/60Hz | Rated use current (AC 110/220): 220A | Carrying: 500A | Switching: ≥600/hour | Application: AC welder shock prevention | Life: 50 ×10,000 operations elec / 500 ×10,000 operations mech | Mounting: screw/rail
