LS Electric Metasol MMS FX Top-mount Auxiliary Switch (1NO1NC, 2NO, 2NC)

LS Electric Metasol MMS FX Top-mount Auxiliary Switch (1NO1NC, 2NO, 2NC)

FX top-mounted auxiliary switch for Metasol MMS Manual Motor Starters. 2-pole contact block, single unit per MMS, top-mount installation.

Key features

  • Available in 1NO+1NC, 2NO, and 2NC contact configurations
  • Rated 5A @ 40°C / 3A @ 60°C
  • Compatible with all Metasol MMS frames (32AF, 63AF, 100AF)
  • NEMA A300 (AC) / R300 (DC)
  • Front cover must be removed before installation

Specifications

Type Auxiliary Switch (FX)
Mount Top-mount (single unit only)
Pole 2-Pole
Compatible MMS MMS-32S/H/HI, MMS-63S/H/HI, MMS-100S/H/HI
Rated Current (40°C) 5A
Rated Current (60°C) 3A
NEMA Rating AC: A300, DC: R300
AC-15 Rating 240V/3A
DC-13 Rating 24V/1A, 220V/0.1A
Backup Fuse 16A gG/gL
Weight 18g
Note Front cover must be removed before installation
FX-1NO1NC FX Top-mount Auxiliary Switch, 1NO + 1NC | Type: Auxiliary Switch (FX) | Mount: Top-mount (single unit only) | Contacts: 1 Normally Open + 1 Normally Closed | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI, MMS-63S/H/HI, MMS-100S/H/HI | Rated Current (40°C): 5A | Rated Current (60°C): 3A | NEMA Rating: AC: A300, DC: R300 | AC-15 Rating: 240V/3A | DC-13 Rating: 24V/1A, 220V/0.1A | Backup Fuse: 16A gG/gL | Weight: 18g | Note: Front cover must be removed before installation
FX-2NO FX Top-mount Auxiliary Switch, 2NO | Type: Auxiliary Switch (FX) | Mount: Top-mount (single unit only) | Contacts: 2 Normally Open | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI, MMS-63S/H/HI, MMS-100S/H/HI | Rated Current (40°C): 5A | Rated Current (60°C): 3A | NEMA Rating: AC: A300, DC: R300 | AC-15 Rating: 240V/3A | DC-13 Rating: 24V/1A, 220V/0.1A | Backup Fuse: 16A gG/gL | Weight: 18g | Note: Front cover must be removed before installation
FX-2NC FX Top-mount Auxiliary Switch, 2NC | Type: Auxiliary Switch (FX) | Mount: Top-mount (single unit only) | Contacts: 2 Normally Closed | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI, MMS-63S/H/HI, MMS-100S/H/HI | Rated Current (40°C): 5A | Rated Current (60°C): 3A | NEMA Rating: AC: A300, DC: R300 | AC-15 Rating: 240V/3A | DC-13 Rating: 24V/1A, 220V/0.1A | Backup Fuse: 16A gG/gL | Weight: 18g | Note: Front cover must be removed before installation
AccessoriesLS Electric
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Metasol MMS FX Top-mount Auxiliary Switch (1NO1NC, 2NO, 2NC)

Brand LS Electric·Accessories

Available part numbers (3)

FX-1NO1NC, FX-2NO, FX-2NC

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FX-1NO1NCFX Top-mount Auxiliary Switch, 1NO + 1NC | Type: Auxiliary Switch (FX) | Mount: Top-mount (single unit only) | Contacts: 1 Normally Open + 1 Normally Closed | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI, MMS-63S/H/HI, MMS-100S/H/HI | Rated Current (40°C): 5A | Rated Current (60°C): 3A | NEMA Rating: AC: A300, DC: R300 | AC-15 Rating: 240V/3A | DC-13 Rating: 24V/1A, 220V/0.1A | Backup Fuse: 16A gG/gL | Weight: 18g | Note: Front cover must be removed before installation
FX-2NOFX Top-mount Auxiliary Switch, 2NO | Type: Auxiliary Switch (FX) | Mount: Top-mount (single unit only) | Contacts: 2 Normally Open | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI, MMS-63S/H/HI, MMS-100S/H/HI | Rated Current (40°C): 5A | Rated Current (60°C): 3A | NEMA Rating: AC: A300, DC: R300 | AC-15 Rating: 240V/3A | DC-13 Rating: 24V/1A, 220V/0.1A | Backup Fuse: 16A gG/gL | Weight: 18g | Note: Front cover must be removed before installation
FX-2NCFX Top-mount Auxiliary Switch, 2NC | Type: Auxiliary Switch (FX) | Mount: Top-mount (single unit only) | Contacts: 2 Normally Closed | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI, MMS-63S/H/HI, MMS-100S/H/HI | Rated Current (40°C): 5A | Rated Current (60°C): 3A | NEMA Rating: AC: A300, DC: R300 | AC-15 Rating: 240V/3A | DC-13 Rating: 24V/1A, 220V/0.1A | Backup Fuse: 16A gG/gL | Weight: 18g | Note: Front cover must be removed before installation
