LS Electric Metasol MMS LA Any-Trip Alarm Switch for 32AF (1NO1NC, 2NO, 2NC)

LS Electric Metasol MMS LA Any-Trip Alarm Switch for 32AF (1NO1NC, 2NO, 2NC)

LA Any-Trip Alarm Switch — activates on any trip event (overload, short-circuit, phase-loss, or manual).

Key features

  • Specifically dimensioned for MMS-32AF frames. 2-pole, left side-mount. 10A @ 40°C / 6A @ 60°C
  • NEMA A600/Q300
  • When combined with LX auxiliary, LA must be installed first
  • Note: MMS-63 cannot use LX and LA simultaneously (different part: LA-63100)

Specifications

Type Any-Trip Alarm Switch (LA)
Activates On Any trip (overload, short-circuit, phase-loss, manual)
Mount Left side-mount
Pole 2-Pole
Compatible MMS MMS-32S/H/HI only
Rated Current (40°C) 10A
Rated Current (60°C) 6A
NEMA Rating AC: A600, DC: Q300
Weight 40g
Note When combined with LX, install LA first
Important Do not operate LA when handle is in TRIP position
LA-32-1NO1NC LA Any-Trip Alarm Switch for MMS-32AF, 1NO + 1NC | Type: Any-Trip Alarm Switch (LA) | Activates On: Any trip (overload, short-circuit, phase-loss, manual) | Mount: Left side-mount | Contacts: 1 Normally Open + 1 Normally Closed | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI only | Rated Current (40°C): 10A | Rated Current (60°C): 6A | NEMA Rating: AC: A600, DC: Q300 | Weight: 40g | Note: When combined with LX, install LA first | Important: Do not operate LA when handle is in TRIP position
LA-32-2NO LA Any-Trip Alarm Switch for MMS-32AF, 2NO | Type: Any-Trip Alarm Switch (LA) | Activates On: Any trip (overload, short-circuit, phase-loss, manual) | Mount: Left side-mount | Contacts: 2 Normally Open | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI only | Rated Current (40°C): 10A | Rated Current (60°C): 6A | NEMA Rating: AC: A600, DC: Q300 | Weight: 40g | Note: When combined with LX, install LA first | Important: Do not operate LA when handle is in TRIP position
LA-32-2NC LA Any-Trip Alarm Switch for MMS-32AF, 2NC | Type: Any-Trip Alarm Switch (LA) | Activates On: Any trip (overload, short-circuit, phase-loss, manual) | Mount: Left side-mount | Contacts: 2 Normally Closed | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI only | Rated Current (40°C): 10A | Rated Current (60°C): 6A | NEMA Rating: AC: A600, DC: Q300 | Weight: 40g | Note: When combined with LX, install LA first | Important: Do not operate LA when handle is in TRIP position
AccessoriesLS Electric
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Metasol MMS LA Any-Trip Alarm Switch for 32AF (1NO1NC, 2NO, 2NC)

Brand LS Electric·Accessories

Available part numbers (3)

LA-32-1NO1NC, LA-32-2NO, LA-32-2NC

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
LA-32-1NO1NCLA Any-Trip Alarm Switch for MMS-32AF, 1NO + 1NC | Type: Any-Trip Alarm Switch (LA) | Activates On: Any trip (overload, short-circuit, phase-loss, manual) | Mount: Left side-mount | Contacts: 1 Normally Open + 1 Normally Closed | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI only | Rated Current (40°C): 10A | Rated Current (60°C): 6A | NEMA Rating: AC: A600, DC: Q300 | Weight: 40g | Note: When combined with LX, install LA first | Important: Do not operate LA when handle is in TRIP position
LA-32-2NOLA Any-Trip Alarm Switch for MMS-32AF, 2NO | Type: Any-Trip Alarm Switch (LA) | Activates On: Any trip (overload, short-circuit, phase-loss, manual) | Mount: Left side-mount | Contacts: 2 Normally Open | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI only | Rated Current (40°C): 10A | Rated Current (60°C): 6A | NEMA Rating: AC: A600, DC: Q300 | Weight: 40g | Note: When combined with LX, install LA first | Important: Do not operate LA when handle is in TRIP position
LA-32-2NCLA Any-Trip Alarm Switch for MMS-32AF, 2NC | Type: Any-Trip Alarm Switch (LA) | Activates On: Any trip (overload, short-circuit, phase-loss, manual) | Mount: Left side-mount | Contacts: 2 Normally Closed | Pole: 2-Pole | Compatible MMS: MMS-32S/H/HI only | Rated Current (40°C): 10A | Rated Current (60°C): 6A | NEMA Rating: AC: A600, DC: Q300 | Weight: 40g | Note: When combined with LX, install LA first | Important: Do not operate LA when handle is in TRIP position
