Magapo 324-0159 Long Center Drill

Magapo 324-0159 Long Center Drill

Magapo Long Center Drill is a precision cutting tool designed to create accurate centering points for subsequent drilling or turning operations, sourced direct from Korea.

Key features

  • Extended-length center drills like this are commonly used in lathe and milling setups where standard-length tools cannot reach recessed or deep workpiece locations
324-0159 1.0MM (4.0*1.0*120) | Spec: 1.0 | Overall Length: 120 | Shank Diameter: 4
324-0186 1.5MM (5.0*1.5*150) | Spec: 1.5 | Overall Length: 150 | Shank Diameter: 5
324-0201 2.5MM (8.0*2.5*120) | Spec: 2.5 | Overall Length: 120 | Shank Diameter: 8
324-0265 3.0MM (8.0*3.0*120) | Spec: 3.0 | Overall Length: 120 | Shank Diameter: 8
324-0274 3.0MM (8.0*3.0*150) | Spec: 3.0 | Overall Length: 150 | Shank Diameter: 8
324-0308 4.0MM (10.0*4.0*120) | Spec: 4.0 | Overall Length: 120 | Shank Diameter: 10
324-0317 4.0MM (10.0*4.0*150) | Spec: 4.0 | Overall Length: 150 | Shank Diameter: 10
324-0733 1.0MM (4.0*1.0*150) | Spec: 1.0 | Overall Length: 150 | Shank Diameter: 4
324-0751 4.0MM (12.0*4.0*150) | Spec: 4.0 | Overall Length: 150 | Shank Diameter: 12
Center DrillsMagapo
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Magapo 324-0159 Long Center Drill

Brand Magapo·Center Drills

Available part numbers (9)

324-0159, 324-0186, 324-0201, 324-0265, 324-0274, 324-0308, 324-0317, 324-0733, 324-0751
