Mitsubishi Electric - B-N65 Main Circuit NC Magnetic Contactor (AC Operated, 80A Ith, 2a2b Aux)

Mitsubishi Electric MS-T/N series B-N65 magnetic contactor with normally closed b-contact main circuit, for DC motor starting resistor short-circuiting, AC motor slow-start duty, dynamic braking and AC or DC source changeover in lighting circuits.

Key features

AC operated coil, main contact configuration 1a2b standard and 3b optional, 2a2b twin auxiliary contacts rated down to 20V 5mA
Open thermal current 80A, coil power consumption 2.8W
Phase barriers fitted as standard on the main circuit; charged-part protection cover units UN-CV and UN-CZ are applicable
Mechanical durability 5,000,000 operations, electrical durability 500,000 operations at 1200 operations per hour
Compliant with JIS C8201-4-1, JEM1038 and JIS C8201-5-1
AC operated DC excited electromagnet eliminates coil humming and provides a wide-input common rating coil with built-in surge absorption

Specifications

Type	Main circuit NC (b-contact) magnetic contactor
Frame	B-N65
Operation	AC operated
Aux Contact	2a2b
DC Rated Current DC2 DC4 Class	20A (50A) at DC100-110V, 3A (20A) at DC200-220V
DC Rated Current DC1 Class	30A (65A) at DC100-110V, 10A (30A) at DC200-220V
AC Rated Current	50A at 200-220V, 35A at 380-440V (3-phase b-contact)
Open Thermal Current Ith	80A
Coil Power Consumption	2.8W
Coil Inrush	210VA
Coil Sealed Input	23VA
Switching Frequency	1200 operations/h

B-N65 AC24V		B-N65 NC main contact contactor, AC24V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC24V \| Coil Rating: 24V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC24V 3B		B-N65 NC main contact contactor, AC24V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC24V \| Coil Rating: 24V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC48V		B-N65 NC main contact contactor, AC48V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC48V \| Coil Rating: 48-50V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC48V 3B		B-N65 NC main contact contactor, AC48V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC48V \| Coil Rating: 48-50V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC100V		B-N65 NC main contact contactor, AC100V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC100V \| Coil Rating: 100-127V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC100V 3B		B-N65 NC main contact contactor, AC100V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC100V \| Coil Rating: 100-127V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC200V		B-N65 NC main contact contactor, AC200V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC200V \| Coil Rating: 200-240V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC200V 3B		B-N65 NC main contact contactor, AC200V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC200V \| Coil Rating: 200-240V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC300V		B-N65 NC main contact contactor, AC300V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC300V \| Coil Rating: 260-350V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC300V 3B		B-N65 NC main contact contactor, AC300V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC300V \| Coil Rating: 260-350V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC400V		B-N65 NC main contact contactor, AC400V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC400V \| Coil Rating: 380-440V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC400V 3B		B-N65 NC main contact contactor, AC400V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC400V \| Coil Rating: 380-440V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC500V		B-N65 NC main contact contactor, AC500V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC500V \| Coil Rating: 460-550V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
B-N65 AC500V 3B		B-N65 NC main contact contactor, AC500V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC500V \| Coil Rating: 460-550V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1

Magnetic ContactorsMitsubishi Electric

14 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - B-N65 Main Circuit NC Magnetic Contactor (AC Operated, 80A Ith, 2a2b Aux)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (14)

B-N65 AC24V, B-N65 AC24V 3B, B-N65 AC48V, B-N65 AC48V 3B, B-N65 AC100V, B-N65 AC100V 3B, B-N65 AC200V, B-N65 AC200V 3B, B-N65 AC300V, B-N65 AC300V 3B + 4 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	B-N65 AC24V	B-N65 NC main contact contactor, AC24V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC24V \| Coil Rating: 24V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC24V 3B	B-N65 NC main contact contactor, AC24V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC24V \| Coil Rating: 24V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC48V	B-N65 NC main contact contactor, AC48V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC48V \| Coil Rating: 48-50V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC48V 3B	B-N65 NC main contact contactor, AC48V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC48V \| Coil Rating: 48-50V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC100V	B-N65 NC main contact contactor, AC100V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC100V \| Coil Rating: 100-127V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC100V 3B	B-N65 NC main contact contactor, AC100V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC100V \| Coil Rating: 100-127V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC200V	B-N65 NC main contact contactor, AC200V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC200V \| Coil Rating: 200-240V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC200V 3B	B-N65 NC main contact contactor, AC200V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC200V \| Coil Rating: 200-240V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC300V	B-N65 NC main contact contactor, AC300V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC300V \| Coil Rating: 260-350V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC300V 3B	B-N65 NC main contact contactor, AC300V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC300V \| Coil Rating: 260-350V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC400V	B-N65 NC main contact contactor, AC400V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC400V \| Coil Rating: 380-440V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC400V 3B	B-N65 NC main contact contactor, AC400V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC400V \| Coil Rating: 380-440V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC500V	B-N65 NC main contact contactor, AC500V coil, 1a2b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 1a2b \| Coil Designation: AC500V \| Coil Rating: 460-550V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
	B-N65 AC500V 3B	B-N65 NC main contact contactor, AC500V coil, 3b main contacts \| Type: Main circuit NC (b-contact) magnetic contactor \| Frame: B-N65 \| Operation: AC operated \| Main Contact: 3b \| Coil Designation: AC500V \| Coil Rating: 460-550V 50/60Hz \| Aux Contact: 2a2b \| DC Rated Current DC2 DC4 Class: 20A (50A) at DC100-110V, 3A (20A) at DC200-220V \| DC Rated Current DC1 Class: 30A (65A) at DC100-110V, 10A (30A) at DC200-220V \| AC Rated Current: 50A at 200-220V, 35A at 380-440V (3-phase b-contact) \| Open Thermal Current Ith: 80A \| Coil Power Consumption: 2.8W \| Coil Inrush: 210VA \| Coil Sealed Input: 23VA \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 5,000,000 operations, Electrical 500,000 operations \| Standards: JIS C8201-4-1, JEM1038, JIS C8201-5-1
