Mitsubishi Electric - CD-52 Heavy Duty Magnetic Contactor (2-pole, 80A Ith, 30kW at 380-440V)

Mitsubishi Electric - CD-52 Heavy Duty Magnetic Contactor (2-pole, 80A Ith, 30kW at 380-440V)

Mitsubishi Electric MS-T/N series CD-52 heavy duty magnetic contactor of European construction, suited to control of cranes, rolling mills and similar heavy industrial machinery. 2-pole main circuit, rated insulation voltage 660V at 50/60Hz, rated operational current 80A at 200-220V, 65A at 380-440V, 50A at 500-550V under AC-3 class and 80A at 200-220V, 65A at 380-440V, 65A at 500-550V under AC-2 class, rated capacity 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V under AC-3 class, rated carrying current 80A.

Key features

  • Mounting dimensions are modularised in integer multiples of 50mm for easy combination into prefabricated panels, and the LI type auxiliary contact is common across the whole range and can be changed between a contact and b contact on a single unit
  • Auxiliary contacts 4 poles maximum, 2a2b standard
  • Switching frequency 1200 operations/h
  • Operating circuit accepts DC100V, DC110V, DC200V and DC220V; the rectifier equipped RF variant is not manufactured for this frame, with a tolerance of 85 to 110 percent of rated operating voltage
  • Reversing type is available as CD-2X52
  • Compliant with JEM1038

Specifications

Type Heavy duty magnetic contactor, European style
Frame CD-52
Poles 2-pole
Rectifier DC source with DC operation
Operating Voltage Tolerance 85 to 110 percent of rated operating voltage
Rated Insulation Voltage 660V
Rated Frequency 50/60Hz
Rated Operational Current AC-3 Class 80A at 200-220V, 65A at 380-440V, 50A at 500-550V
Rated Operational Current AC-2 Class 80A at 200-220V, 65A at 380-440V, 65A at 500-550V
Rated Operational Current AC-1 Class 80A at 550V
Rated Capacity AC-3 Class 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V
Rated Capacity AC-2 Class 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V
CD-52 DC100V CD-52 heavy duty contactor, DC100V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X52 DC100V CD-2X52 heavy duty contactor, DC100V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-52 DC110V CD-52 heavy duty contactor, DC110V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.5A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X52 DC110V CD-2X52 heavy duty contactor, DC110V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.5A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-52 DC200V CD-52 heavy duty contactor, DC200V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.28A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X52 DC200V CD-2X52 heavy duty contactor, DC200V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.28A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-52 DC220V CD-52 heavy duty contactor, DC220V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.25A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X52 DC220V CD-2X52 heavy duty contactor, DC220V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.25A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
Magnetic ContactorsMitsubishi Electric
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - CD-52 Heavy Duty Magnetic Contactor (2-pole, 80A Ith, 30kW at 380-440V)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (8)

CD-52 DC100V, CD-2X52 DC100V, CD-52 DC110V, CD-2X52 DC110V, CD-52 DC200V, CD-2X52 DC200V, CD-52 DC220V, CD-2X52 DC220V

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CD-52 DC100VCD-52 heavy duty contactor, DC100V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X52 DC100VCD-2X52 heavy duty contactor, DC100V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-52 DC110VCD-52 heavy duty contactor, DC110V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.5A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X52 DC110VCD-2X52 heavy duty contactor, DC110V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.5A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-52 DC200VCD-52 heavy duty contactor, DC200V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.28A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X52 DC200VCD-2X52 heavy duty contactor, DC200V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.28A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-52 DC220VCD-52 heavy duty contactor, DC220V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.25A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X52 DC220VCD-2X52 heavy duty contactor, DC220V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-52 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.25A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 80A at 200-220V, 65A at 380-440V, 50A at 500-550V | Rated Operational Current AC-2 Class: 80A at 200-220V, 65A at 380-440V, 65A at 500-550V | Rated Operational Current AC-1 Class: 80A at 550V | Rated Capacity AC-3 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Capacity AC-2 Class: 19kW at 200-220V, 30kW at 380-440V, 30kW at 500-550V | Rated Carrying Current Ith: 80A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
