Mitsubishi Electric - CD-802 Heavy Duty Magnetic Contactor (2-pole, 800A Ith, 400kW at 380-440V)

Mitsubishi Electric - CD-802 Heavy Duty Magnetic Contactor (2-pole, 800A Ith, 400kW at 380-440V)

Mitsubishi Electric MS-T/N series CD-802 heavy duty magnetic contactor of European construction, suited to control of cranes, rolling mills and similar heavy industrial machinery. 2-pole main circuit, rated insulation voltage 660V at 50/60Hz, rated operational current 800A at 200-220V, 750A at 380-440V, 600A at 500-550V under AC-3 class and 800A at 200-220V, 800A at 380-440V, 800A at 500-550V under AC-2 class, rated capacity 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V under AC-3 class, rated carrying current 800A.

Key features

  • Mounting dimensions are modularised in integer multiples of 50mm for easy combination into prefabricated panels, and the LI type auxiliary contact is common across the whole range and can be changed between a contact and b contact on a single unit
  • Auxiliary contacts 4 poles maximum, 2a2b standard
  • Switching frequency 1200 operations/h
  • Operating circuit accepts DC100V, DC110V, DC200V and DC220V, and the RF variant adds a built-in rectifier for AC100V, AC110V, AC200V and AC220V sources, with a tolerance of 85 to 110 percent of rated operating voltage
  • Reversing type is available as CD-2X802
  • Compliant with JEM1038

Specifications

Type Heavy duty magnetic contactor, European style
Frame CD-802
Poles 2-pole
Operating Voltage Tolerance 85 to 110 percent of rated operating voltage
Rated Insulation Voltage 660V
Rated Frequency 50/60Hz
Rated Operational Current AC-3 Class 800A at 200-220V, 750A at 380-440V, 600A at 500-550V
Rated Operational Current AC-2 Class 800A at 200-220V, 800A at 380-440V, 800A at 500-550V
Rated Operational Current AC-1 Class 800A at 550V
Rated Capacity AC-3 Class 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V
Rated Capacity AC-2 Class 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V
Rated Carrying Current Ith 800A
CD-802 DC100V CD-802 heavy duty contactor, DC100V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.2A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802 DC100V CD-2X802 heavy duty contactor, DC100V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.2A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802 DC110V CD-802 heavy duty contactor, DC110V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.1A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802 DC110V CD-2X802 heavy duty contactor, DC110V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.1A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802 DC200V CD-802 heavy duty contactor, DC200V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.6A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802 DC200V CD-2X802 heavy duty contactor, DC200V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.6A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802 DC220V CD-802 heavy duty contactor, DC220V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802 DC220V CD-2X802 heavy duty contactor, DC220V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802-RF AC100V CD-802-RF heavy duty contactor, AC100V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.2A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802-RF AC100V CD-2X802-RF heavy duty contactor, AC100V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.2A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802-RF AC110V CD-802-RF heavy duty contactor, AC110V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.1A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802-RF AC110V CD-2X802-RF heavy duty contactor, AC110V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.1A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802-RF AC200V CD-802-RF heavy duty contactor, AC200V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.6A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802-RF AC200V CD-2X802-RF heavy duty contactor, AC200V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.6A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802-RF AC220V CD-802-RF heavy duty contactor, AC220V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802-RF AC220V CD-2X802-RF heavy duty contactor, AC220V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
Magnetic ContactorsMitsubishi Electric
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - CD-802 Heavy Duty Magnetic Contactor (2-pole, 800A Ith, 400kW at 380-440V)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (16)

CD-802 DC100V, CD-2X802 DC100V, CD-802 DC110V, CD-2X802 DC110V, CD-802 DC200V, CD-2X802 DC200V, CD-802 DC220V, CD-2X802 DC220V, CD-802-RF AC100V, CD-2X802-RF AC100V + 6 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CD-802 DC100VCD-802 heavy duty contactor, DC100V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.2A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802 DC100VCD-2X802 heavy duty contactor, DC100V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.2A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802 DC110VCD-802 heavy duty contactor, DC110V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.1A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802 DC110VCD-2X802 heavy duty contactor, DC110V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.1A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802 DC200VCD-802 heavy duty contactor, DC200V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.6A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802 DC200VCD-2X802 heavy duty contactor, DC200V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.6A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802 DC220VCD-802 heavy duty contactor, DC220V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802 DC220VCD-2X802 heavy duty contactor, DC220V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: DC source with DC operation | Operating Circuit Voltage: DC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802-RF AC100VCD-802-RF heavy duty contactor, AC100V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.2A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802-RF AC100VCD-2X802-RF heavy duty contactor, AC100V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC100V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.2A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802-RF AC110VCD-802-RF heavy duty contactor, AC110V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.1A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802-RF AC110VCD-2X802-RF heavy duty contactor, AC110V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC110V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 1.1A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802-RF AC200VCD-802-RF heavy duty contactor, AC200V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.6A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802-RF AC200VCD-2X802-RF heavy duty contactor, AC200V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC200V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.6A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-802-RF AC220VCD-802-RF heavy duty contactor, AC220V operating circuit, non-reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Non-reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
CD-2X802-RF AC220VCD-2X802-RF heavy duty contactor, AC220V operating circuit, reversing | Type: Heavy duty magnetic contactor, European style | Frame: CD-802 | Poles: 2-pole | Configuration: Reversing | Rectifier: AC source with DC operation, built-in rectifier | Operating Circuit Voltage: AC220V | Operating Voltage Tolerance: 85 to 110 percent of rated operating voltage | Operating Circuit Current: 0.55A at 20 degrees C cold with rated voltage applied | Rated Insulation Voltage: 660V | Rated Frequency: 50/60Hz | Rated Operational Current AC-3 Class: 800A at 200-220V, 750A at 380-440V, 600A at 500-550V | Rated Operational Current AC-2 Class: 800A at 200-220V, 800A at 380-440V, 800A at 500-550V | Rated Operational Current AC-1 Class: 800A at 550V | Rated Capacity AC-3 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Capacity AC-2 Class: 200kW at 200-220V, 400kW at 380-440V, 400kW at 500-550V | Rated Carrying Current Ith: 800A | Switching Frequency: 1200 operations/h | Aux Contact: 4 poles maximum, 2a2b standard | Aux Contact Rating: LI type auxiliary contact common to all models, a single unit can be changed between a contact and b contact, rated insulation voltage AC660V, rated operational current AC-15 class 10A at 220V and 6A at 440V and 5A at 550V, DC-13 class 5A at 55V and 3A at 110V and 1A at 220V, contact thermal current 15A | Standards: JEM1038
