Mitsubishi Electric - DU-N260 DC Magnetic Contactor (AC Operated, 2a1b Main, 45kW at DC220V)

Mitsubishi Electric - DU-N260 DC Magnetic Contactor (AC Operated, 2a1b Main, 45kW at DC220V)

Mitsubishi Electric MS-T/N series DU-N260 DC magnetic contactor for DC motor control and general DC circuit switching at DC440V and below, including variable speed drive applications and dynamic braking.

Key features

  • AC operated coil with 2a1b main contacts and 2a2b twin auxiliary contacts applicable down to DC20V 5mA
  • Rated capacity 30kW at DC110V, 45kW at DC220V, 55kW at DC440V in two-pole series connection, open thermal current 360A, rated insulation voltage 660V, coil power consumption 6.1W
  • Reversing type DU-2XN260 is available on the same frame
  • Auxiliary contact units UN-AX and charged-part protection cover units UN-CZ from the MS-N series are applicable
  • Mechanical durability 2,500,000 operations, electrical durability 500,000 operations at 1200 operations per hour
  • Compliant with JEM1038 DC2 and DC4 class and JIS C8201-5-1

Specifications

Type DC magnetic contactor for DC440V or less
Frame DU-N260
Operation AC operated
Main Contact 2a1b
Aux Contact 2a2b
Breaking Capacity 2-Pole Series 1400A at DC110V, 1040A at DC220V, 700A at DC440V
Closing Current Capacity 1400A
Open Thermal Current Ith 360A
Rated Insulation Voltage 660V
Coil Power Consumption 6.1W
Switching Frequency 1200 operations/h
Durability Mechanical 2,500,000 operations, Electrical 500,000 operations
DU-N260 AC48V DU-N260 DC contactor, AC48V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC48V DU-2XN260 DC contactor, AC48V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC100V DU-N260 DC contactor, AC100V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC100V DU-2XN260 DC contactor, AC100V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC200V DU-N260 DC contactor, AC200V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC200V DU-2XN260 DC contactor, AC200V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC300V DU-N260 DC contactor, AC300V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC300V DU-2XN260 DC contactor, AC300V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC400V DU-N260 DC contactor, AC400V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC400V DU-2XN260 DC contactor, AC400V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC500V DU-N260 DC contactor, AC500V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC500V DU-2XN260 DC contactor, AC500V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
Magnetic ContactorsMitsubishi Electric
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - DU-N260 DC Magnetic Contactor (AC Operated, 2a1b Main, 45kW at DC220V)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (12)

DU-N260 AC48V, DU-2XN260 AC48V, DU-N260 AC100V, DU-2XN260 AC100V, DU-N260 AC200V, DU-2XN260 AC200V, DU-N260 AC300V, DU-2XN260 AC300V, DU-N260 AC400V, DU-2XN260 AC400V + 2 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
DU-N260 AC48VDU-N260 DC contactor, AC48V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC48VDU-2XN260 DC contactor, AC48V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC48V | Coil Rating: 48-50V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC100VDU-N260 DC contactor, AC100V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC100VDU-2XN260 DC contactor, AC100V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC100V | Coil Rating: 100-127V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC200VDU-N260 DC contactor, AC200V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC200VDU-2XN260 DC contactor, AC200V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC200V | Coil Rating: 200-240V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC300VDU-N260 DC contactor, AC300V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC300VDU-2XN260 DC contactor, AC300V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC300V | Coil Rating: 260-350V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC400VDU-N260 DC contactor, AC400V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC400VDU-2XN260 DC contactor, AC400V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC400V | Coil Rating: 380-440V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-N260 AC500VDU-N260 DC contactor, AC500V coil, 2a1b main contacts, non-reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Non-reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DU-2XN260 AC500VDU-2XN260 DC contactor, AC500V coil, 2a1b main contacts, reversing | Type: DC magnetic contactor for DC440V or less | Frame: DU-N260 | Configuration: Reversing | Operation: AC operated | Main Contact: 2a1b | Coil Designation: AC500V | Coil Rating: 460-550V 50/60Hz | Aux Contact: 2a2b | Rated Capacity General DC Motor 2-Pole Series: 30kW at DC110V, 45kW at DC220V, 55kW at DC440V | Rated Current General DC Motor 2-Pole Series: 350A at DC110V, 260A at DC220V, 175A at DC440V | Rated Current Variable Speed Control 2-Pole Series: 360A at DC110V, 360A at DC220V, 360A at DC440V | Breaking Capacity 2-Pole Series: 1400A at DC110V, 1040A at DC220V, 700A at DC440V | Closing Current Capacity: 1400A | Open Thermal Current Ith: 360A | Rated Insulation Voltage: 660V | Coil Power Consumption: 6.1W | Switching Frequency: 1200 operations/h | Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations | Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
