Mitsubishi Electric - DUD-N30 DC Magnetic Contactor (DC Operated, 2a Main, 5.5kW at DC220V)

Mitsubishi Electric MS-T/N series DUD-N30 DC magnetic contactor for DC motor control and general DC circuit switching at DC440V and below, including variable speed drive applications and dynamic braking.

Key features

DC operated coil with 2a main contacts and 2a2b twin auxiliary contacts applicable down to DC20V 5mA
Rated capacity 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V in two-pole series connection, open thermal current 60A, rated insulation voltage 660V, coil power consumption 18W
Reversing type DUD-2XN30 is available on the same frame
Auxiliary contact units UN-AX and charged-part protection cover units UN-CZ from the MS-N series are applicable
Mechanical durability 2,500,000 operations, electrical durability 500,000 operations at 1200 operations per hour
Compliant with JEM1038 DC2 and DC4 class and JIS C8201-5-1

Specifications

Type	DC magnetic contactor for DC440V or less
Frame	DU-N30
Operation	DC operated
Main Contact	2a
Aux Contact	2a2b
Breaking Capacity 2-Pole Series	160A at DC110V, 120A at DC220V, 80A at DC440V
Closing Current Capacity	160A
Open Thermal Current Ith	60A
Rated Insulation Voltage	660V
Coil Power Consumption	18W
Switching Frequency	1200 operations/h
Durability	Mechanical 2,500,000 operations, Electrical 500,000 operations

DUD-N30 DC12V		DUD-N30 DC contactor, DC12V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC12V \| Coil Rating: DC12V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-2XN30 DC12V		DUD-2XN30 DC contactor, DC12V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC12V \| Coil Rating: DC12V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-N30 DC24V		DUD-N30 DC contactor, DC24V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC24V \| Coil Rating: DC24V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-2XN30 DC24V		DUD-2XN30 DC contactor, DC24V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC24V \| Coil Rating: DC24V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-N30 DC48V		DUD-N30 DC contactor, DC48V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC48V \| Coil Rating: DC48V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-2XN30 DC48V		DUD-2XN30 DC contactor, DC48V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC48V \| Coil Rating: DC48V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-N30 DC100V		DUD-N30 DC contactor, DC100V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC100V \| Coil Rating: DC100V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-2XN30 DC100V		DUD-2XN30 DC contactor, DC100V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC100V \| Coil Rating: DC100V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-N30 DC110V		DUD-N30 DC contactor, DC110V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC110V \| Coil Rating: DC110V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-2XN30 DC110V		DUD-2XN30 DC contactor, DC110V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC110V \| Coil Rating: DC110V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-N30 DC125V		DUD-N30 DC contactor, DC125V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC125V \| Coil Rating: DC120-125V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-2XN30 DC125V		DUD-2XN30 DC contactor, DC125V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC125V \| Coil Rating: DC120-125V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-N30 DC200V		DUD-N30 DC contactor, DC200V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC200V \| Coil Rating: DC200V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-2XN30 DC200V		DUD-2XN30 DC contactor, DC200V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC200V \| Coil Rating: DC200V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-N30 DC220V		DUD-N30 DC contactor, DC220V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC220V \| Coil Rating: DC220V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
DUD-2XN30 DC220V		DUD-2XN30 DC contactor, DC220V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC220V \| Coil Rating: DC220V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1

Magnetic ContactorsMitsubishi Electric

16 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Mitsubishi Electric - DUD-N30 DC Magnetic Contactor (DC Operated, 2a Main, 5.5kW at DC220V)

Brand Mitsubishi Electric·Magnetic Contactors

Available part numbers (16)

DUD-N30 DC12V, DUD-2XN30 DC12V, DUD-N30 DC24V, DUD-2XN30 DC24V, DUD-N30 DC48V, DUD-2XN30 DC48V, DUD-N30 DC100V, DUD-2XN30 DC100V, DUD-N30 DC110V, DUD-2XN30 DC110V + 6 more — see full table ↓

How to order

Send the Mitsubishi Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	DUD-N30 DC12V	DUD-N30 DC contactor, DC12V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC12V \| Coil Rating: DC12V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-2XN30 DC12V	DUD-2XN30 DC contactor, DC12V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC12V \| Coil Rating: DC12V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-N30 DC24V	DUD-N30 DC contactor, DC24V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC24V \| Coil Rating: DC24V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-2XN30 DC24V	DUD-2XN30 DC contactor, DC24V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC24V \| Coil Rating: DC24V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-N30 DC48V	DUD-N30 DC contactor, DC48V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC48V \| Coil Rating: DC48V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-2XN30 DC48V	DUD-2XN30 DC contactor, DC48V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC48V \| Coil Rating: DC48V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-N30 DC100V	DUD-N30 DC contactor, DC100V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC100V \| Coil Rating: DC100V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-2XN30 DC100V	DUD-2XN30 DC contactor, DC100V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC100V \| Coil Rating: DC100V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-N30 DC110V	DUD-N30 DC contactor, DC110V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC110V \| Coil Rating: DC110V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-2XN30 DC110V	DUD-2XN30 DC contactor, DC110V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC110V \| Coil Rating: DC110V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-N30 DC125V	DUD-N30 DC contactor, DC125V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC125V \| Coil Rating: DC120-125V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-2XN30 DC125V	DUD-2XN30 DC contactor, DC125V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC125V \| Coil Rating: DC120-125V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-N30 DC200V	DUD-N30 DC contactor, DC200V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC200V \| Coil Rating: DC200V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-2XN30 DC200V	DUD-2XN30 DC contactor, DC200V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC200V \| Coil Rating: DC200V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-N30 DC220V	DUD-N30 DC contactor, DC220V coil, 2a main contacts, non-reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Non-reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC220V \| Coil Rating: DC220V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
	DUD-2XN30 DC220V	DUD-2XN30 DC contactor, DC220V coil, 2a main contacts, reversing \| Type: DC magnetic contactor for DC440V or less \| Frame: DU-N30 \| Configuration: Reversing \| Operation: DC operated \| Main Contact: 2a \| Coil Designation: DC220V \| Coil Rating: DC220V \| Aux Contact: 2a2b \| Rated Capacity General DC Motor 2-Pole Series: 3.7kW at DC110V, 5.5kW at DC220V, 7.5kW at DC440V \| Rated Current General DC Motor 2-Pole Series: 40A at DC110V, 30A at DC220V, 20A at DC440V \| Rated Current Variable Speed Control 2-Pole Series: 50A at DC110V, 50A at DC220V, 40A at DC440V \| Breaking Capacity 2-Pole Series: 160A at DC110V, 120A at DC220V, 80A at DC440V \| Closing Current Capacity: 160A \| Open Thermal Current Ith: 60A \| Rated Insulation Voltage: 660V \| Coil Power Consumption: 18W \| Switching Frequency: 1200 operations/h \| Durability: Mechanical 2,500,000 operations, Electrical 500,000 operations \| Standards: JEM1038 DC2 and DC4 class, JIS C8201-5-1
